Synthesisers

Notes: Inspired by the RSF Polykobol, the mighty Kijimi is a serious analogue synth, packing eight voices of two-VCO architecture and SSI2140-based filters. MK2 upgrade features more powerful firmware, extensive LFO options and neat wooden end panels.

Supplier's Notes:
KIJIMI MK2 is crafted to be one of the most powerful polysynths ever built, all behind intuitive front-panel controls, from its continuous timbral variation to its exhaustive modulation matrix. The Black Corporation original features planetary-sized analog sound, inspired by the best of rare and classic synths, but unique to our own parallel galaxy.

Continuous analogue timbral control

Instead of fixed waveforms, KIJIMI's voltage-controlled oscillators can morph continuously through waveform types. Sine, triangle, sawtooth, and variable pulse waves are smoothly variable, with pulse width as you turn to the far right. It's a scheme that provides unique, independent timbral over each of the eight voices.

Deep 8-voice architecture

Each of KIJIMI 's 8 voices features 2 analogue oscillators each with a square sub-bass oscillator, for buttery timbres with extensive sound design options. The sub-oscillator produces an octave lower than the combined VCO1 and VCO2 outputs, meaning you can tune two sub-pitches. Hard sync is available in VCO sync and VCO1->2 and 2->1 configurations for maximum flexibility. There's also a noise source for adding bite and percussion components. A rich lowpass filter is built around the legendary 2140 chip and the ability to frequency-modulate it via VCO2, creates a full range of sounds from metallic and aggressive to subtle. Both filter cutoff and resonance are available as modulation destinations.

Unique envelope functionality with dedicated controls

Two ADSR envelopes come with independent rate multipliers, keyboard control of attack rate, and versatile routing. Engage the CYCLE button for a cycling trapezoidal mode, similar to that on vintage instruments like the EMS Synthi. Few polysynths offer this level of detailed control, let alone with front-panel controlsino menu diving needed.

Endless modulation programmability

Modulation possibilities set the KIJIMI apart from other polysynths. Two LFOs can be routed independently to up to eight destinations, directly on front-panel buttons, controlling frequency and waveform modulation, sub-oscillator amount, filter cutoff and frequency, and amplitude modulation. Each LFO includes multiple waveform options (sine, triangle, saw, ramp, square, random) and separate attack and decay knobs in addition to rate. ADSR2 sports four independent destinations, also via front-panel push buttons and knobs. Even velocity and aftertouch get their own dedicated control section for applying velocity or aftertouch to each parameter (LFO rate, waveform morph, sub, pitch bend, and VCA). Dedicated knobs let you apply your aftertouch and poly-aftertouch, to taste, right where you want it. You'll rarely use the menus, and when you do, it'll only be to unlock even more advanced functionality (like multiple LFO features!). KIJIMI is a rare case of fusing straightforward one-control-per-feature design with unrestricted possibilities.

Full MIDI and expressive control, tuning support

Combine all the elements, and KIJIMI is an instrument that's playable like no other. Each note you play separately triggers modulation, independently on each voice, with full control via aftertouch. Add in full MIDI control, complete MIDI polyphonic expression (MPE) support, advanced tuning capabilities (including microtuning via SCALA and 128 memory locations for tuning settings), and velocity polyphonic aftertouch, each with up to six more destinations with its own bipolar settings. KIJIMI finally brings a synthesizer architecture that can unlock the possibilities of your expressive controller of choice.

Updated package

The MK2 version of KIJIMI includes all the acclaimed sonic power and character of its predecessor, in an improved package. Updated firmware now includes the ability to assign different LFO settings (rate, waveform, envelope, and depth) to each individual destination. In addition to 128 factory and 1152 user presets, we've included user banks by Mathew Jonson, Richard Devine, and Paul Schilling. All this comes in a compact, 2.71kg/5.97 lb device with wood panels attached (or the option of metal rack ears instead). DIN MIDI and isolated USB are onboard.

Notes: A complete system which really showcases Make Nose's experimental approach, the Resynthesizer features Make Noise classics like the Spectraphon and Morphagene and hands-on control via the PrssPnt, alll housed in a 4 Zone CV Bus Case.

Supplier's Notes:
The ReSynthesizer can trace its origins to Spring 2023, with Walker and Rodent putting together a collection of modules to announce and demonstrate the Soundhack Spectraphon at Superbooth '23. These modules would need to complement Spectraphon in a way that would show its true capabilities. As such, this specialized layout comprised a single-system overview of the last 8 years of Make Noise module designs.

After Superbooth, Walker and Peter continued to use a similar system configuration in videos for Make Noise's Youtube and Instagram Channels, prompting some folks to speculate if it was to be Make Noise's new 7U system. At that time there were no plans for a new system; in fact, this layout had been intended as temporary all along, but it was made a useful layout in almost all cases. (The layout even gained the popular unofficial moniker "System X" thanks to the speculative work of Cinematic Laboratory and others.) Choices like the unusual placement of the Morphagene, adjacent to Spectraphon, which was initially assumed would be mainly for a very specific use-case, quickly became second nature to patch. The Spectraphon and Morphagene work together to ReSynthesize raw materials into lush soundscapes, microsound manipulations, or wherever the path leads.

In early 2024, Make Noise announced DXG for the easy mixdown of mono or stereo signals, and PrssPnt to add physical touch interaction. With these pieces in place, the ReSynthesizer is born. Pairing the Spectraphon with the Morphagene and the core Make Noise CV generation suite, and housed in the powerful and portable 4 Zone CV Bus Case, the ReSynthesizer is an open design blackboard ready for experimentation and discovery.

Make Noise put this collection through its paces and have found it to hold up to any test thrown at it!

Specifications

Size: 7U
Total HP: 208 @ 3U, 104 @ 1U
Dimensions: 22.25" x 14" x 7.25" w/ lid

Notes: A serious, serious synth. PPG-esque wavetable synthesis with huge 24-voice polyphony, dual analogue filters and four-part multitimbrality. Incredible sound, incredible versatility.

Supplier's Notes:
The 3rd Wave is a powerhouse wavetable synth with 24-voice polyphony and 4-part multi-timbral capability that's like having four independent synthesizers at your fingerprints.

Each of its 3 oscillators per voice can be:

A classic PPG-era wavetable
A high-resolution complex wavetable
An analogue-modelled waveform
Create up to 64 custom wavetables of your own using the built-in Wavemaker. With sample-to-wavetable capability, you can connect an audio source to the audio input and generate a wavetable at the touch of a button.

Classic legacy; modern sound

While the 3rd Wave has roots in the classic digital wavetable synths of the past, it takes that concept into the 21st century with a lush, expansive sound that's a product of its expanded wavetables and warm, organic-sounding analogue filters

It boasts not only a punchy, Dave Rossum-designed 2140 analogue low-pass filter with variable saturation, but a second, SEM-style state-variable filter (low-pass, high-pass, notch, and band-pass) for additional tone-sculpting. Run both filters in series for harmonically complex textures.

4-part; multi-timbral

With 24-voices, the 3rd Wave has enough power for the most note-intensive performances.

And that polyphony really comes into play with its ability to layer up to 4 independent parts or split zones - each with a completely different sound, sequence, and dual effect.

Each stereo part has independent panning, volume, and a dedicated stereo physical output.

Modulation Matrix

The secret weapon of any synth is its mod matrix, and the 3rd Wave doesn't disappoint.

With 16 assignable slots, 12 additional fixed-source slots, 27 sources, and 114 destinations, it has the flexibility of a modular.

And all of this power is per multipart. That means up to 4 independent layers of sound, each with its own mod matrix.

Sequence notes; songs & params

The 3rd Wave's sequencer is an inspiring tool for both composers and sound designers because it is pattern-based and can sequence notes, songs, and parameter changes.

For composing and performing, enter notes and chords in real time with or without quantization for maximum groove and arrange up to 24 patterns of up to 32 measures in length into songs just as easily.

Specs

Sound Engine

3 High-resolution Digital Oscillators Per Voice
64 total user wavetable positions with 48 wavetables that contain 64 waveforms per table (32 legacy PPG waves with room for another 16 of this type)
32 original 8 bit wavetables from the PPG 2 series instruments with room for 16 more user created 8 bit wavetables
7 high-resolution modelled analogue waveforms (sine, saw, triangle, supersaw, pulse, white noise, pink noise)

VCO sync

Linear FM
6-stage wave envelope per oscillator with variable time and position that can be looped
Optional wave flow section that allows for no wavetable as well as no waveform interpolation
Upper wavetable mode as with the original PPG 2 series
Unison mode and chord mode with variable voice count

1 Analogue Low-pass Filter

Dave Rossum designed, classic, 2140 low-pass resonant filter
24 db per octave slope
variable saturation amount
optional resonance compensation

1 State-Variable Filter

12 db per octave slope
Continuously variable between low-pass, notch, and high-pass, operation with optional band-pass mode

4 ADSR+ Delay Envelopes

Filter, Amplifier, plus 2 additional envelopes switchable between exponential and vintage PPG-style response
Freely assignable to multiple modulation destinations

4 Low-Frequency Oscillators

Triangle, sawtooth, reverse sawtooth, square, pulse 1, pulse 2, pulse 3, and random (S&H)
Variable delay
Note reset
Syncable to master clock BPM

2 Digital Effects

BBD, stereo delay, tape delay, chorus, phaser, flanger, distortion pedal, rotating speaker, ring mod, room reverb, hall reverb, super plate reverb - most modelled on famous hardware devices
Syncable to master clock BPM
Parameters modulatable via mod matrix

Wavemaker Tool: Built-In Custom Wavetable Maker

"Sample-to-wave" functionality. Connect an audio source to the 3rd Wave's Audio In port, press "Make Waves" and the synth samples the audio to create a custom wavetable
Samples to convert can also be brought in as a 96 kHz wav file through USB
Store up to 32 custom wavetables
64 waveforms per wavetable
Accepts pitched or un-pitched material as input
96 kHz sampling rate
16-bit resolution
1024 cycles per waveform, converted automatically to cover entire keyboard range
Flexible wave-sampling length
Imports Serum wavetables

Sequencer: Performs both Note and Parameter Sequencing

4 parts per sequence
24 sequences per preset
Up to 32 measures per sequence
Variable quantization resolution per sequence (32nd, 16th, 8th, quarter, half, whole note, or quantization off), that is settable in real time
Variable swing

Arpeggiator: 1 Arp per Multi-part
Up, down, up/down, and assign modes
Variable range (1, 2, or 3 octaves)

Mod Matrix: 16-slot Modulation Matrix Per Multi-Part

16 slot modulation matrix with 27 mod sources and 114 mod destinations
12 additional fixed-source mod paths
Modulation assignment buttons enable quick and easy modulation routing
Mod Matrix runs at audio rates
Sequencer can record and play mod parameter changes in real time

Controls

77 knobs and 39 buttons enable deep, comprehensive editing with minimal menu diving
Pitch and Mod Wheels
Full-sized, five-octave, semi-weighted, premium Fatar keyboard with velocity and aftertouch

Programs

500 factory programs. User rewritable

In/out

4 Stereo outputs (2x 1/4" phone jack per part)
Headphone out (stereo 1/4" phone jack)
MIDI In, MIDI Out, and MIDI Thru
USB port for bidirectional MIDI communication
Audio Input for creating user wavetables from external audio source (1/4" phone jack)
Audio Input can also route audio through the filters, output chain, and effects
Sustain/footswitch input
Volume pedal input
Expression pedal input

Power

1 universal IEC AC power inlet for internal power supply
Operates worldwide on voltages between 100-240v, 50-60 Hz, 65 watts maximum power consumption

Dimensions

Shipping Box Dimensions: 44 x 20 x 13 inches, 35 lbs
Synth Dimensions: 38.5 x 14.25 x 5 inches, 27 lbs

Notes: Celebrating the 50th anniversary of this truly iconic synth, the 'modern' take on the classic Buchla Music Easel doesn't mess with a winning formula, paring the 208C sound source with 218e touch-sensitive keyboard.

Supplier's Notes:
The Buchla Music Easel was one of the first truly portable electronic music instruments. Fifty years ago, in 1973, only a few dozen were made. Unlike many iconic technologies, the influence was not grown through force of scale, but rather the force of the ideas. The Music Easel made available virtually every musical dimension: timbre, melody, rhythm, and time; how these dimensions intersected was no longer the court of acoustics and material, but signals and voltage. The 208 Stored Program Sound Source engendered "a new functional organization [with a] particularly rapid system of patching and program storage via plug-in cards."

Taking cues from the then-recent discipline of cybernetics, the 218 touch plate was for "real-time communication" to help realize the "potential vocabulary" of the Easel, rather than exploiting existing modes of musical virtuosity. The Stored Program Cards ensured rapid repeatability and repertoire on its own terms. The battery terminals made sure the music was as portable as any acoustic instrument. And the name let you know it was designed for art rather than science.

Buchla is ecstatic to revive the Music Easel for its third run in 50 years. Buchla first released the updated 208 Stored Program Sound Source, dubbed the Easel Command, with expanded MIDI and USB capability. Next came the update of the Easel Program Manager - a complete kit for storing and recalling sounds sources, even more rapidly than imagined in 1973. The new 218 Touch Activated Voltage Source provides the optimal input facility, as originally envisioned. It is now all together in a rugged case and the advanced EMBIO module that unifies all the audio and control inputs and outputs for integration with the rest of your musical world.

More than a retro novelty, the Music Easel still speaks to a future we strive for. A technology that invites conversation, not chats, and controls that engage expression, not work. There are many new worlds to explore in this instrument created at the crossroads of the jazz and computer ages. Designed as "an integrated assemblage of functions", rather than a collection of modules, the Music Easel's colour coding, comfortable access to controls, and solid patch connections allow for satisfying sessions of sonic discovery.

The Music Easel is available for pre-order starting June 16 at Buchla.com and your favourite Buchla Dealer. Delivery of the Music Easel (modern) is expected fall 2023.

Stored Program Sound Source Model 208C

The sound source of the Music Easel is the 208C, which includes a complex oscillator and a modulation oscillator (which can also serve as another voice), each with independent switchable waveforms, as well as a noise generator, allowing for rich and intricate sound design. The 208C also features a five-stage sequencer, envelope generator, pulser and modulation source - with switchable triggers - allowing for complex patterns and evolving textures. The dual low pass gate provides dynamic control over the tone and amplitude of the sound, as well as natural-sounding decay and sustain. The 208C has a number of modulation sources, including a random voltage generator, the envelope generator, modulation oscillator, and an envelope detector. These sources can be used to modulate various parameters via the extensive patchfield - creating movement, texture, and complexity. The 208C also includes a mixer section with spring reverb.

Touch Activated Voltage Source Model 218e (v3)

The first design appeared in the 1973 release of the Buchla Music Easel and named for the spacecraft that delivered astronauts to the moon. Providing the familiar piano key layout for this early mobile music machine, the additional controls and capabilities were an interface for exploring uncharted musical territory. With the new version 3, it's been elevated with a new foundation of stable, modern electronics with incredible sensitivity and accuracy - the lightest touch will produce triggers and control voltages. The adjustable sensor has the dynamic range and durability to handle your playing. The new texture not only improves the sensing, but provides a satisfying tactile experience. As always, pressure is an expressive output, adding an extra dimension to the control. MIDI outputs velocity and polyphony, as well as channel pressure, making the 218e a uniquely expressive controller. The 218e includes portamento and an arpeggiator, which can be driven by external inputs and are allowed to interact with the automated notes to make patterns more complex. Additional controls allow you to blend different patterns and randomness to easily change from the expected to the surprising. The classic preset voltage knobs offer several possible ways to shift your sounds into new territory. Not only can the knobs be used for quick access to voltages for your patch, they can control arpeggiation modes and octave shifting. Pads output pulses for additional control. The 218e also gives you a unique interface to playing your existing MIDI gear and soft synths. Each touch outputs note name, channel pressure, and velocity for every note, along with sustain controls from a pedal. Polyphonic MIDI mode lets you play chords. The touchstrip can act as a pitch bend control, or as a mod wheel for additional expressive control. Easily configured using the front panel controls, you can send notes and controls on any MIDI channel.

Electric Music Box Input/Output (EMBIO)

Maintaining the spirit, sound, and process from the original, the new Music Easel adds a variety of new features. Buchla's latest renditions of the Stored Program Sound Source and Touch Activated Voltage Source are tied together with the Electric Music Box Input/Output (EMBIO) module. This of course provides MIDI out (mini jack and USB) and CV out from the 218, MIDI in to the 208, and the audio out from the 208C. Additional creative control comes from the Audio Mixer, for integration with other Buchla modules and systems, and the CV conditioners and controls. The slew control can turn your sequencer into a wavy modulator, or soften up a square LFO. The attenuator and crossfader gives you the opportunity to find new levels and combinations of voltages from existing ones. The pulse converter offers new rhythms to trigger. And a simple LFO provides another valuable modulator when you just can't quite let yourself flip that Mod Osc switch from "high" to "low."

Notes: Celebrating the 50th anniversary of this truly iconic synth, the 'modern' take on the classic Buchla Music Easel doesn't mess with a winning formula, paring the 208C sound source with 218e touch-sensitive keyboard.

Supplier's Notes:
The Buchla Music Easel was one of the first truly portable electronic music instruments. Fifty years ago, in 1973, only a few dozen were made. Unlike many iconic technologies, the influence was not grown through force of scale, but rather the force of the ideas. The Music Easel made available virtually every musical dimension: timbre, melody, rhythm, and time; how these dimensions intersected was no longer the court of acoustics and material, but signals and voltage. The 208 Stored Program Sound Source engendered "a new functional organization [with a] particularly rapid system of patching and program storage via plug-in cards."

Taking cues from the then-recent discipline of cybernetics, the 218 touch plate was for "real-time communication" to help realize the "potential vocabulary" of the Easel, rather than exploiting existing modes of musical virtuosity. The Stored Program Cards ensured rapid repeatability and repertoire on its own terms. The battery terminals made sure the music was as portable as any acoustic instrument. And the name let you know it was designed for art rather than science.

Buchla is ecstatic to revive the Music Easel for its third run in 50 years. Buchla first released the updated 208 Stored Program Sound Source, dubbed the Easel Command, with expanded MIDI and USB capability. Next came the update of the Easel Program Manager - a complete kit for storing and recalling sounds sources, even more rapidly than imagined in 1973. The new 218 Touch Activated Voltage Source provides the optimal input facility, as originally envisioned. It is now all together in a rugged case and the advanced EMBIO module that unifies all the audio and control inputs and outputs for integration with the rest of your musical world.

More than a retro novelty, the Music Easel still speaks to a future we strive for. A technology that invites conversation, not chats, and controls that engage expression, not work. There are many new worlds to explore in this instrument created at the crossroads of the jazz and computer ages. Designed as "an integrated assemblage of functions", rather than a collection of modules, the Music Easel's colour coding, comfortable access to controls, and solid patch connections allow for satisfying sessions of sonic discovery.

The Music Easel (retro) is available for pre-order starting in June 16 at Buchla.com and your favorite Buchla Dealer with delivery expected in winter 2023.

Stored Program Sound Source Model 208C

The sound source of the Music Easel is the 208C, which includes a complex oscillator and a modulation oscillator (which can also serve as another voice), each with independent switchable waveforms, as well as a noise generator, allowing for rich and intricate sound design. The 208C also features a five-stage sequencer, envelope generator, pulser and modulation source - with switchable triggers - allowing for complex patterns and evolving textures. The dual low pass gate provides dynamic control over the tone and amplitude of the sound, as well as natural-sounding decay and sustain. The 208C has a number of modulation sources, including a random voltage generator, the envelope generator, modulation oscillator, and an envelope detector. These sources can be used to modulate various parameters via the extensive patchfield - creating movement, texture, and complexity. The 208C also includes a mixer section with spring reverb.

Touch Activated Voltage Source Model 218e (v3)

The first design appeared in the 1973 release of the Buchla Music Easel and named for the spacecraft that delivered astronauts to the moon. Providing the familiar piano key layout for this early mobile music machine, the additional controls and capabilities were an interface for exploring uncharted musical territory. With the new version 3, it's been elevated with a new foundation of stable, modern electronics with incredible sensitivity and accuracy - the lightest touch will produce triggers and control voltages. The adjustable sensor has the dynamic range and durability to handle your playing. The new texture not only improves the sensing, but provides a satisfying tactile experience. As always, pressure is an expressive output, adding an extra dimension to the control. MIDI outputs velocity and polyphony, as well as channel pressure, making the 218e a uniquely expressive controller. The 218e includes portamento and an arpeggiator, which can be driven by external inputs and are allowed to interact with the automated notes to make patterns more complex. Additional controls allow you to blend different patterns and randomness to easily change from the expected to the surprising. The classic preset voltage knobs offer several possible ways to shift your sounds into new territory. Not only can the knobs be used for quick access to voltages for your patch, they can control arpeggiation modes and octave shifting. Pads output pulses for additional control. The 218e also gives you a unique interface to playing your existing MIDI gear and soft synths. Each touch outputs note name, channel pressure, and velocity for every note, along with sustain controls from a pedal. Polyphonic MIDI mode lets you play chords. The touchstrip can act as a pitch bend control, or as a mod wheel for additional expressive control. Easily configured using the front panel controls, you can send notes and controls on any MIDI channel.

Electric Music Box Input/Output (EMBIO)

Maintaining the spirit, sound, and process from the original, the new Music Easel adds a variety of new features. Buchla's latest renditions of the Stored Program Sound Source and Touch Activated Voltage Source are tied together with the Electric Music Box Input/Output (EMBIO) module. This of course provides MIDI out (mini jack and USB) and CV out from the 218, MIDI in to the 208, and the audio out from the 208C. Additional creative control comes from the Audio Mixer, for integration with other Buchla modules and systems, and the CV conditioners and controls. The slew control can turn your sequencer into a wavy modulator, or soften up a square LFO. The attenuator and crossfader gives you the opportunity to find new levels and combinations of voltages from existing ones. The pulse converter offers new rhythms to trigger. And a simple LFO provides another valuable modulator when you just can't quite let yourself flip that Mod Osc switch from "high" to "low."

Notes: Originally released in 1970, Minimoog Model D was the world's first portable synthesizer and served as the archetype for all electronic keyboards that followed. The all-analog instrument gained acclaim for combining the colossal sound of the 1960s Moog modular synthesizers with the accessibility of pre-wired modulesimeaning that it could be played instantly and intuitively with no patch cables required. It was quickly embraced by a diverse roster of performers, with artists like Herbie Hancock, Kraftwerk, Rick Wakeman, Sun Ra, Piero Umiliani, Giorgio Moroder, Bernie Worrell, and Gary Numan all shaping unique sounds and forging new musical genres using the instrument.

More than a half-century since its invention, Minimoog Model D is back in production at the Moog factory in Asheville, North Carolina. An exceptional sonic tool and one of the most beloved and iconic synthesizers ever designed, it returns to the hands of synthesists of all kinds and serves as inspiration for the next generation of electronic musicians.

The three-oscillator, monophonic, analog synthesizer is securely housed in a locally sourced Appalachian cherry cabinet and hand-finished aluminum chassis. Sounding as vibrant and deep as ever, its legendary low-pass ladder filter, powerful oscillators, and rich saturating mixer retain the exact component placement and through-hole design of a 1970s-era Minimoog Model D.

While no changes have been made to the original sound engine or audio signal path, the 2022 Minimoog Model D includes a series of popular functional modifications that expand this legendary instrument's sonic capabilities. These modifications include a dedicated analog LFO with triangle and square waveshapes, a premium Fatar keybed with velocity and after pressure available via top panel CV jacks with onboard trimpots, MIDI integration, and a mixer feedback modification which allows the Minimoog Model D to overdrive and scream with the turn of a knob. And, for the first time in its history, the Minimoog Model D now features a spring-loaded pitch wheel with center deadband, allowing for improved playability and wild performance flourishes. This newest edition also includes updates to the MIDI functionality, allowing for improved modern studio integration.

SPECS
NUMBER OF KEYS
44
KEYBOARD RANGE
F0 to C4
KEYBOARD ACTION
Synthesizer (Spring)
NOTE PRIORITY
(Low, High, Last): User Selectable
SOUND SOURCES
3x Oscillators, Noise Generator and External Audio Input
OSCILLATOR FREQUENCY RANGE
0.1 to 20 kHz (In Six Overlapping Ranges)
OSCILLATOR STABILITY
(short term) > 0.25 %
OSCILLATOR WAVEFORMS
Triangle, Triangle-Sawtooth (Oscillator-1, Oscillator-2), Reverse Sawtooth (Oscillator-3), Sawtooth, Rectangle, Wide Pulse and Narrow Pulse.

Notes: Serious synth options here, with a 24-voice polyphonic, four-part multi-timbral design based on the iconic PPG wavetable approach, updated and blended with analogue filters. An absolute powerhouse of an instrument.

Supplier's Notes:
The 3rd Wave desktop module a powerhouse wavetable synth with 24-voice polyphony and 4-part multi-timbral capability that's like having four independent synthesizers at your fingerprints.

It has all of the power, all of the polyphony, all of the multipart capability, all of the I/O, and all of the awesome sound quality of the full keyboard version.

Each of its 3 oscillators per voice can be any of these 3 choices:
A classic PPG 8-bit wavetable with all the original processing
A high-resolution anti-aliased 96KHz wavetable
Analogue modelled waveforms with spline interpolation

Create up to 64 custom wavetables of your own using the built-in Wavemaker. With the sample-to-wavetable capability, you can connect an audio source to the audio input and generate a wavetable at the touch of a button.

Classic legacy, modern sound

While the 3rd Wave has roots in the classic digital wavetable synths of the past, it takes that concept into the 21st century with a lush, expansive sound that's a product of its expanded wavetables and warm, organic-sounding analogue filters, 4 independent parts, and 24 voices.

It boasts not only a punchy, Dave Rossum-designed 2140 analogue low-pass filter with variable saturation, but a second, SEM-style state-variable filter (low-pass, high-pass, notch, and band-pass) for additional tone-sculpting. Run both filters in series for harmonically complex textures.

4-part multi-timbral

With 24-voices, the 3rd Wave has enough power for the most note-intensive performances.

And that polyphony really comes into play with its ability to layer up to 4 independent parts or split zones -- each with a completely different sound, sequence, and dual effects.

Each part has independent panning, volume, and a dedicated stereo physical output. Use the multiple outputs and part placement to create spatial audio mixes.

Modulation matrix

The secret weapon of any synth is its mod matrix, and the 3rd Wave doesn't disappoint.

With 16 assignable slots, 12 additional fixed-source slots, 27 sources, and 114 destinations, it has the flexibility of a modular.

And all of this power is per multipart. That means up to 4 independent layers of sound, each with its own mod matrix.

Sequence notes, songs and parameters

The 3rd Wave's sequencer is an inspiring tool for both composers and sound designers because it is pattern-based and can sequence notes, songs, and parameter changes.

For composing and performing, enter notes and chords in real time with or without quantization for maximum groove and arrange up to 24 patterns of up to 32 measures in length into songs just as easily.

Sound engine

3 High-resolution Digital Oscillators Per Voice

64 total user wavetable positions with 48 wavetables that contain 64 waveforms per table (32 legacy PPG waves with room for another 16 of this type)
32 original 8-bit wavetables from the PPG 2 series instruments with room for 16 more user created 8 bit wavetables
7 high-resolution modelled analogue waveforms (sine, saw, triangle, supersaw, pulse, white noise, pink noise)
VCO sync
Free-running oscillators
Linear FM
6-stage wave envelope per oscillator with variable time and position that can be looped
Optional wave flow section that allows for no wavetable as well as no waveform interpolation
Upper wavetable mode as with the original PPG 2 series
Unison, poly unison, and chord unison mode with variable voice count

Analog Low-pass Filter (per voice)

Dave Rossum designed, classic, 2140 low-pass resonant filter
24 dB per octave slope
variable saturation amount
optional resonance compensation

State-Variable Filter (per voice)
12 dB per octave slope
Continuously variable between low-pass, notch, and high-pass, operation with optional band-pass mode

4 ADSR+ Delay Envelopes
Filter, Amplifier, plus 2 additional envelopes switchable between exponential and vintage PPG-style response
Freely assignable to multiple modulation destinations

4 Low-Frequency Oscillators
Triangle, sawtooth, reverse sawtooth, square, pulse 1, pulse 2, pulse 3, and random (S&H)
Variable delay
Note reset
Syncable to master clock BPM

2 Digital Effects
BBD, stereo delay, tape delay, chorus, phaser, flanger, distortion pedal, rotating speaker, ring mod, room reverb, hall reverb, super plate reverb - most modelled on famous hardware devices
Syncable to master clock BPM
Parameters modulatable via mod matrix

Wave maker tool

Built-In Custom Wavetable Maker

"Sample-to-wave" functionality. Connect an audio source to the 3rd Wave's Audio In port, press "Make Waves" and the synth samples the audio to create a custom wavetable
Samples to convert can also be brought in as a 96 kHz wav file through USB
Store up to 32 custom wavetables
64 waveforms per wavetable
Accepts pitched or un-pitched material as input
96 kHz sampling rate
16-bit resolution
1024 cycles per waveform, converted automatically to cover entire keyboard range
Flexible wave-sampling length

Sequencer

Performs both Note and Parameter Sequencing
1 song per multi-part
24 sequences per song
32 measures per sequence
Variable quantization resolution per sequence (32nd, 16th, 8th, quarter, half, whole note, or quantization off)
Swing

Arepggiator

1 Arp per Multi-part
Up, down, up/down, and assign modes
Variable range (1, 2, or 3 octaves)

Mod matrix

16-slot Modulation Matrix Per Multi-Part

16 slot modulation matrix with 27 mod sources and 114 mod destinations
12 additional fixed-source mod paths
Modulation assignment buttons enable quick and easy modulation routing
Mod Matrix runs at audio rates
Sequencer can record and play mod parameter changes in real time

Controls

77 knobs and 39 buttons enable deep, comprehensive editing with minimal menu diving
Pitch and Mod Wheels
Full-sized, five-octave, semi-weighted, premium Fatar keyboard with velocity and aftertouch

Programs

500 factory programs. User rewritable

In/out

4 Stereo outputs (2x 1/4" phone jack per part)
Headphone out (stereo 1/4" phone jack)
MIDI In, MIDI Out, and MIDI Thru
USB port for bidirectional MIDI communication
Audio Input for creating user wavetables from external audio source (1/4" phone jack)
Sustain/footswitch input
Volume pedal input
Expression pedal input

Power

1 universal IEC AC power inlet for internal power supply

Notes: Moog enter a fresh chapter with a huge new synth. Full-on eight-voice bi-timbral analogue goodness, featuring selected highlights of Moog's iconic synth circuits from over the decades. Classic Moog sound, updated and bigger than ever.

Supplier's Notes:
Meet Muse, an eight-voice analogue bi-timbral polyphonic synthesiser - the culmination of over 5 years of dreams, design, and passion. Muse is an intuitive and powerful instrument built on the rich history of Moog that simultaneously gazes boldly into the future. This studio or performance centrepiece is driven by eight analogue voices, each with two VCOs, modulation VCO, dual VCFs, and a stereo VCA - all with that recognizable, kinetic analogue quality.

Muse represents a melting pot of classic Moog designs paired with forward-thinking controls in one complete instrument. Moog have selected the very best of vintage Moog circuits to create Muse - inspired by Moog Voyager oscillators, MF-102 Ring Modulator, CP3 Mixer, 902 VCA module, and a 904a Filter.

With 16 banks of 16 patches, you'll encounter beautiful pads, organic FM plucks, attention-grabbing leads, subterranean basses, stage-oriented key splits, as well as 2 banks reserved for your own sonic discoveries. Explore and express yourself endlessly with cutting-edge digital controls for powerful modulation capabilities, dedicated macro control, customizable envelopes, and multiple flexible LFOs. Shaping sound with Muse is a pleasure - the synthesizer and synthesist grow as one as the adventure continues for years to come.

Muse was created for, and by, modern musicians, producers, and sound designers who appreciate performance-oriented controls, intuitive knob per function layout, and "More" menus for every module. Built for stage and studio with a 61-key Fatar keyboard with velocity and channel aftertouch, a left-hand controller with pitch and mod wheels, and a programmable Macro knob makes the experience of interacting with Muse inspiring, intriguing, and innately playable.

A hypnotic stereo Diffusion Delay processor was inspired by golden era vintage digital rack delays with a unique and powerful set of diffusion, multi-tap, and filter behaviours. Craft complex echoes and diffused tonal smears that add dimension and depth to any patch.

In addition to Muse's creative immediacy, the powerful arpeggiator invites you to generate melodic ideas with compelling patterns and rhythms. With Muse's deep sequencer, you'll unravel unique patterns and gestures - further develop these discoveries with parameter recording, generative/probabilistic functions, and detailed editing of every note in the sequence - Moog Muse is a limitless canvas of musical exploration.

Moog Muse Specs:
Synthesiser type - Polyphonic, Bi-timbral Analog Synthesizer
Sound engine - Analogue
Polyphony - 8 Voices
Keybed - 61 full-size semi-weighted Fatar keybed with Velocity and channel Aftertouch
Controllers - Pitch Wheel, Modulation Wheel, Macro Knob, Keyboard Octave switch, Hold switch, Sustain Pedal input, Expression Pedal input - all pedal functions are assignable
Panel controls - 44 knobs, 16 sliders, 129 buttons - OLED screen
Analogue voltage-controlled oscillators - (x2) Selectable Triangle/Sawtooth mix, variable width Pulse wave, Octave (16', 8', 4', 2'), Frequency (+/- 7 Semitones), Wave Mix (blends Triangle/Sawtooth with variable Pulse wave), FM routing and amount, Hard sync
Analogue ring modulator - Ring modulation between Oscillators 1 and 2
Analogue voltage-controlled modulation oscillator - Selectable waveform (Sine, Sawtooth, Reverse Sawtooth, Square, Noise), Audio range toggle switch, Keyboard tracking, Keyboard reset, Unipolar switch, Pitch Modulation routing and amount, Filter Modulation routing and amount, Pulse Width Modulation routing and amount, VCA Modulation amount, Panning switch
Analogue noise generator - White noise
Analogue voltage-controlled mixer - Independent level control for OSC 1, OSC 2, RING, MOD OSC, and NOISE. Overall OVERLOAD control
Analogue voltage-controlled filters - (x2) Moog transistor ladder filters (1 with highpass/lowpass modes), Cutoff Frequency, Resonance, KB Tracking Amount, Envelope Amount, Linked Operation, Routing (Series, Parallel, Stereo)
Envelopes - (x2) Attack, Decay, Sustain, Release, variable curves per stage, Multi-trig, Loop, Velocity
Analogue voltage-controlled amplifier - Volume per Timbre, Pan position per Timbre, Pan Spread per timbre
Diffusion Delay™ - Configurable stereo signal processor, Delay Time Left, Delay Time Right, Feedback, Character, Mix, analogue bypass switches (to maintain 100% analogue signal path)
Output section - Master Volume, Headphones Volume, Low Cut EQ
LFO - (x2) Rate, Amplitude, Waveform selection (Triangle, Sawtooth, Square, Sample-and-Hold, User customizable), Keyboard Reset
Pitch LFO - Rate, Ramp Down through Triangle to Ramp Up Shape control, One-Shot Envelope toggle, Keyboard Reset, Pitch Modulation routing and amount
Glide - Selectable glide type (LCR, LCT, EXP), Glide amount
Clock - Clock rate, Tap Tempo
Arpeggiator - Per-timbre with Clock Division, Octave range, Pattern, Direction, Gate time, Rhythmic programming, etc.
Sequencer - 64-step sequencer with Clock Division, Transport controls, Sequence chaining, Step editing, Modulation capabilities, and memory capacity of 16 banks of 16 sequences
Programmer - Browser via OLED screen with 16 banks of 16 patches, Mod Map, Arpeggiator settings, Sequencer with per-step settings, Global settings, etc.
Voice control - Mono or poly voice count per timbre, Unison/Mono, Detune, Timbre editing, Voice stealing configuration
Chord memory - Chord memory with per-key functionality
MOD MAP - 16 modulation slots per timbre per patch with controllers and mathematical transform functions

Rear panel

Audio outputs - Main Left, Main Right (14" TRS)
Headphones - Stereo 1/4" (located on the front edge of the Left Hand Controller)
Pedal inputs - Sustain, Expression (1/4" TRS; Configurable through Mod Map or for use as 1/4" TS CV inputs)
Control voltage inputs - CV IN 1, CV IN 2 (1/8" TS)
Control voltage outputs - CV OUT 1, CV OUT 2 (1/8" TS)
Analogue clock input - CLOCK IN (1/8" TS)
Analogue clock output - CLOCK OUT (1/8" TS)
MIDI - 5 Pin DIN MIDI IN, OUT, THRU; MIDI over USB
USB B - USB-B connector for interfacing with a computer or other host MIDI device
USB A (HOST) - USB-A connector for connecting to other instruments with Muse as the MIDI host

Power
Style IEC Cable
Input: 100 - 240VAC; 50 Hz - 60 Hz

In the box

Moog Muse 8-Voice Polyphonic Analog Synthesizer
IEC Cable
Quick Start Guide
Registration Card
Safety & Warranty Manual

Weights & dimensions

Product Only
Weight: 14.55 (kg), 32 (lbs)
Dimensions (W x D x H): 99 x 42 x 11 (cm), 39 x 17 x 4.5 (inches)
Product In Box
Weight 18.92 (kg), 43.92 (lbs)
Dimensions (W x D x H): 116.7 x 55.2 x 24.7 (cm), 45.96 x 21.72 x 9.72 (inches)

Notes: One of the best synths money can buy. Hugely expressive PolyBrute engine expands to 12 voices with the same beguiling combination of FullTouch keyboard, Morphee control and ribbon strip. Immense

Supplier's Notes:
Unleashing the full power of PolyBrute

Continuing the legacy of its predecessor as one of the most powerful and expressive analogue synths ever made, PolyBrute 12 goes a step further.

A multi-faceted tool for musical expression, PolyBrute 12 lets you seamlessly evolve and control any parameters while playing. The input-perfect sensitivity of the keyboard, the bi-timbral morphing presets, the multi-axis Morphee controller, the Ribbon controller - all work in perfect harmony so you can breathe vitality and intricate dynamics into your sound.

PolyBrute's in-the-moment sonic display would not be possible without the raw energy of its Brute oscillators and dual enhanced classic filters. This, combined with its intuitive interface, elegant modulation Matrix and advanced software companion make PolyBrute 12 a synth for the ages - a matrimony of Brute force and human touch.

Full touch, full control

Discover a next-generation keybed and new aftertouch modes that bring you into a direct and tactile connection with your sound.

PolyBrute's patented FullTouch keyboard provides the exact position of every key across the entire range of movement. This not only allows for precise and dynamic aftertouch expression but it also puts versatility at PolyBrute's core - allowing you to go from regular playing modes to exceptional aftertouch and envelope control at the touch of a button.

You can also use PolyBrute 12 to control any MPE-compatible VST. If you don't have a MPE compatible DAW, you can still record expressively using MIDI 1.0, although at a lower resolution.

Mono Aftertouch

In this mode, the note is triggered by regular keyboard velocity and the classic aftertouch area corresponds to an assignable aftertouch signal, where all the voices receive the same level and amount of expression. Great for applying a unified modulation effect to a chord or phrase.

Morph between sonic worlds

Seamlessly blend from one patch to another and find that perfect middle ground

Each preset is made up of two sonic states, A & B. A dedicated Morph knob lets you seamlessly explore a continuum of sound between them. This, combined with the Morphee controller and PolyBrute's keyboard, paves the way for endless patch evolution and expressivity.

Analogue heart, seismic sound

PolyBrute's sound begins with two analogue VCOs sharing much of the same sonic architecture that has made the Brute family renowned.

Each oscillator generates sawtooth, triangle and square waves simultaneously, and you can mix between them to shape just the right signal source and timbre.

Dial in VCO 1's Metalizer wavefolding to escalate from pure to punchy. Bring in VCO 2's sub-oscillator to add an extra lower octave and some added rumble.

Dial in edgy FM effects by modulating VCO 1's frequency with VCO 2, or subtly alter a continuous range of harmonics with soft or hard sync.

1 VCF 1 Steiner

A 2-pole 12db/octave Steiner filter design with continuous sweepable slope types, as seen across the Brute range. The addition of the proprietary Brute Factor feedback control lets you add anything from subtle warmth to a electrified growl.

2 VCF 1 Ladder

Inspired by Dr. Bob Moog's legendary 4-pole 24db/octave ladder design. A low-pass classic, with added gain compensation and asymmetrical distortion to add upfront grit to your polyphonic patches.

Modern modulation sources

Modulation has always been essential in animating synth sounds.

PolyBrute weaves a web of envelopes and LFOs that's intricate and unpredictable in equal measure - a dynamic display of sonic motion.

Three Envelope Generators

PolyBrute's VCF and VCA have velocity-sensitive ADSR envelopes hardwired outside the Matrix for instant gratification. The third Envelope Generator features a delay stage (DADSR) and can be assigned to sculpt any Matrix modulation targets. Use the various repeat and loop modes to add complex movement to your patches.

Three Envelope Generators

PolyBrute's VCF and VCA have velocity-sensitive ADSR envelopes hardwired outside the Matrix for instant gratification. The third Envelope Generator features a delay stage (DADSR) and can be assigned to sculpt any Matrix modulation targets. Use the various repeat and loop modes to add complex movement to your patches.

Three LFOs

PolyBrute's three syncable LFOs span an extremely wide range - facilitating anything from beautiful evolving soundscapes to clangorous audio-range modulation. Options for waveshaping, polarity and retriggering let you take your sound way outside the box. Experiment with Matrix routing and tempo/MIDI sync for hyper-rhythmic effects.

Enter the matrix

The flexibility of modular patching combined with digital precision and analogue richness makes for a transcendent polysynth experience.

32 target parameters, 64 connections in total. Rearrange PolyBrute's signal chain with the touch of a single button. Dial in positive or negative amounts, intuitively assign one or more destinations via any relevant controls, instantly route PolyBrute's array of performance controllers and advanced modulation sources to influence just about anything in the instrument's chain - all without a convoluted array of wires.

But the Matrix doesn't just take care of PolyBrute's all-encompassing modulation routing - it's the centrepiece of every aspect of its architecture. In Presets mode, use the Matrix to select any of the 768 patch memory locations. Morph mode accesses advanced morph state editing. Sequencer mode transforms the Matrix into an intuitive visual pattern editor.

Main Features

61-keys with FullTouchr MPE Technology keyboard
Pitch Bend, Mod Wheel, Ribbon controllers
Morphee touch and pressure sensitive 3D controller
Osc and Noise Mixer with Filter routing
12dB/Oct Steiner Parker Filter

Continuous LP>Notch>HP>BP morphing
Cutoff, Resonance, Brute Factor

24dB/Oct Ladder Filter with Distortion
Three Envelopes
Looping capability
Two ADSR
One DADSR
Three stereo digital effects
Modulation FX : Chorus, Phaser, Flanger, Ring Modulation
Delay : 9 algorithms including BBD, Digital delay
Reverb : 9 algorithms including Hall, Plate, Spring, Shimmer
Distortions : Subtle Tape, Classic Distortion, Soft Clip, Worn Out Tape, Germanium, BitCrusher, DownSampler
Arpeggiator, Matrix Arpeggiator, Sequencer
Stereo audio output
2 expression and 1 sustain pedal inputs
Two Analogue VCO's
Saw
Triangle + Metalizer
Square + Pulse Width
Sub
Linear FM
Hard Sync
Noise Generator
Continuous tone from rumble noise to white noise
Three LFOs
LFO1 and LFO2 with waveform selection
LFO3 with waveform shaping using Shape and Symmetry
Rate control & Tempo Sync
Various retrig options
480 presets and 768 preset slots
12x32 Modulation Matrix
Notes, Accent, Slide per step
3 tracks of automation
MIDI and USB I/O + analogue clock I/O

Platform specifications

Windows
Win 10+ (64bit)
4 GB RAM
4 cores CPU, 3.4 GHz (4.0 GHz Turbo-boost)
3GB free hard disk space
OpenGL 2.0 compatible GPU
ARM processors not supported on Windows

Apple
Mac OS 11+
4 GB RAM
4 cores CPU, 3.4 GHz (4.0 GHz Turbo-boost) or M1 CPU
3GB free hard disk space
OpenGL 2.0 compatible GPU

Required configuration
Works in Standalone, VST, AAX, Audio Unit.

Work with ASC
An elegant and simple solution to help you install, activate, and update your Arturia software instruments.

What's in the box

Box content

PolyBrute 12 Unit
Power Cord
User Manual
Registration Card

Instrument dimensions
Size : 38.3 x 17.1 x 6.1 inches (972 x 435 x 156mm)
Weight : 50.7lbs (23kg)

Notes: Latest incarnation of Buchla's legendary modular synth. Massively creative with incredible sound and history stretching all the way back to the 1960s.

Supplier notes:
The evolution of the legendary modular analog synthesizer by Don Buchla. The Buchla Easel Command is the newly updated 208C in a standalone desktop form with MIDI and CV control.

Buchla's own Joel Davel led the charge to create a new version of the legendary Music Easel instrument with more modular flexibility and independence, while also providing the means to easily interface with more devices, such as the various DAWs like Ableton and MIDI controllers, including the very expressive Sensel Morph. It's still fully analog in its default configuration and provides the unique and exquisite Buchla experience with greater functionality at a lower cost.

Notes: The world first heard the instantly recognizable sounds of the Mellotron on hits from the Moody Blues ("Nights in White Satin") and the Beatles ("Strawberry Fields Forever") in the 1960s. In 2010, Mellotron reintroduced the iconic tape-based machine in a compact digital version, the Mellotron M4000D, that retains the authentic sound, look and feel of the original keyboard while adding some significant improvements.

The M4000D has been used onstage and in the studio by artists, musicians and producers including Foo Fighters, Red Hot Chili Peppers, Smashing Pumpkins, Wilco, Incubus, Queens of the Stone Age, Eels, Jackson Browne, Bruno Mars, Band of Horses, Fleet Foxes, Sean Lennon, Brendan Benson, Air, Kooks, Train, Elbow, Michael Beinhorn, Bob Rock, Raphael Saadiq, Noel Gallagher and Gotye.

Specifications

100 instantly accessible Mellotron and Chamberlin sounds, captured from original tape sources at 24-bits, uncompressed
Expansion slot for 100 additional sounds
A and B sound banks simultaneously accessible, with mix control
Controls for volume, tone, normal/half-speed play and pitch adjustment
A, B and Master outputs available on gold plated balanced XLR and gold plated unbalanced 1/4-in line connectors
1/4-in connectors for sustain, expression, and volume pedals, and for headphones
MIDI in, out, and thru
Dimensions: 34 in (W) x 19.5 in (D) x 5.25 in (H); weight: 38.5 pounds

Notes: The iconic Synclavier brand returns with this digital powerhouse, based around FM synthesis but also offering additive and subtractive methods. Super versatile, with up to 98-voice polyphony and MPE support.

Supplier's Notes:
The new buck in the Synclavier stable

Synclavier Regen is the newest in an auspicious line of Digital FM synthesizers. Designed for desktop use, it contains the power of the Synclavier II DSP engine, enhanced and optimised. Full colour screen, liquid-like touch controls, high fidelity audio output coupled with a sound design powerhouse makes this the synth you always dreamed of.

Regen supports additive synthesis for full control of 24 harmonics. Synclavier have now added subtractive synthesis to the Synclavier synthesis engine, especially for Regen, allowing creation of super saws, PCM square waves, and noise generation. Or you can use samples for your carrier waveform.

And these different waveform generators can be mixed. You have up to 12 partials to use in your sound design creation with crossfades assignable to inputs such as velocity, pressure, mod wheel, and of course, keyboard.

Regen is loaded with content to get you inspired fast. There are over 550 timbre presets across 10 newly commissioned timbre libraries. On top of that, there are over 2000 royalty-free samples built-in, including over 350 selected original samples from the NED era and 2 exclusive artist sample libraries.

When you're done exploring the factory content, you'll have fun with the sound design possibilities. You can layer up to 12 partials with different sound generators (additive, subtractive, samples) then apply dynamic effects per partial. It's truly an expressive instrument, both to program and to play. Polyphonic aftertouch and MPE is fully supported and there's a sophisticated modulators section where you can apply responsive curves to properties driven by pressure, velocity, mod wheel position, and so on.

Synclavier Regen is a desktop unit measuring 310mm wide by 260mm tall and 42mm deep.

Housed in aluminium, finished with a sand-textured black and Synclavier red surround. It has rubberized plinths.

User interface consists of many silicone buttons with multi-colour backlighting, a virtual knob capacitive-touch slider with epoxy-coating. A VK display is included as well as a main modal display that shows current parameters, user settings, timbre library, etc.

Over 40 years of synth design has led to this product. It's a sound-designer's dream in a timeless desktop package.

Sound-design Capabilities

Advanced DSP synth engine, as used on Synclavier II, has been extended for Regen.
12 separate tracks of multi-timbrality, assignable to MIDI tracks and keyboard ranges.
Up to 98 simultaneous voices. Voice count is dependent on system load and is likely to be much higher in typical scenarios.
12 partials per timbre. Each partial can be 1 of 3 oscillator synth modes: additive, subtractive, or samples.
Additive mode supports coefficient and phase control of 24 harmonics.
In samples mode, up to 128 samples can be placed on the partial's patchlist.
Subtractive can have a noise generator or up to 9 de-tunable continuous sawtooth waveforms.
Hybrid (resynthesized samples)
Timbre-level effects, including:
Stereo reverb algorithm with pre-delay and library of presets.
Highly-optimised multi-mode filter with sophisticated filter envelope.
Bit-crusher (for use with additive, sample, and hybrid modes).
Frequency modulation (FM) controllable per partial (all modes) with envelope.
Sophisticated modulation system that allows many Regen parameters to be controlled via MIDI, LFOs (24 per timbre), or driven by envelopes (24 per timbre).
Approx 300MB of sample space in memory = 100 mins @ 48Khz 24-bit mono shared across all active tracks and partials.

Hardware

Balanced stereo output through XLR connections at pro-level 4dBu. Designed for studio and home use. These are DC-coupled for maximum bass impact.
Single-ended TS stereo outputs, also DC-coupled.
Convenient headphones TRS jack for monitoring master audio with independent volume
control. For headphones in range 32O - 300O.
DAC circuit is designed for ultra-low noise floor. 11dB of headroom over nominal level. A
measured 130dB of dynamic range. 24-bit, 50kHz sample rate, as per Synclavier II.
Hybrid sound design engine: original Synlcavier II hardware is modelled in software.
High quality audio components throughout, including a precision temperature compensated crystal oscillator for jitter-free digital audio.
Two glorious full-colour sunken displays.
Responsive silicon back-lit parameter buttons.
The vertical value swiper is touch accurate to 128 levels of resolution for precise control
of every parameter.
12 selector buttons are touch-sensitive and can handle gestures to quickly select
multiple partials or tracks.
SD Card reader for unlimited user timbre and sample libraries.
4 USB accessory ports for MIDI keyboards, sequencers, and audio interfaces. Plus 1 USB Host port for connecting to a computer for MIDI input from a DAW.
Take it on the road. Rugged, full metal enclosure.

Notes: Like a greatest hits of recent Analogue Solutions synths, the Ample combines sound elements from the Fusebox with jack patch points, a patch pin matrix, plus sequencer and CV touch pads from the Generator, creating something new and unique.

Supplier's Notes:
Ample combines the best elements of several of Analogue Solutions' recent products.

The sound elements of Fusebox
Jack patch points of Concussor Eurorack
Patch pin matrix of Vostok
Echo from Dr Strangelove
Sequencer and CV touch pads of Generator

It shares all this yet still has its own sound!

Ample can be as complex or as simple as you want it to be

This synth has been given a large and diverse number of controls, that along side the patch sockets, will give even the best and experienced synthesist endless possibilities.

This synth presents the controls in a user friendly and familiar synth layout that, together with this manual and other resources, enable even the new guy to get great sounds.

Synth - Percussion - Audio Processor

Ample is a compact analogue synthesizer. Analogue - as in really analogue. Aside from the MIDI chip (which has to be digital), everything else is totally analogue using real transistors and op-amps. There are no CPU stabilised and quantised circuits, no DCOs, no digital LFOs and no digital EGs, as found on other so called analogue synths. The circuitry is based on designs dating back to the mid-1970s. So Ample has a genuine old sound.

Circuits included

3x Analogue Oscillators

There are three analogue VCOs - each providing a wealth of features and modulation choices. VCO3 can easily be utilised as a LFO.

2x Analogue Low Frequency Oscillator

LFO2(/Sync) has a triangle wave output. VCO3 can be used as an LFO and has Saw, Triangle and Square wave modulation signals.

Analogue Filter

Ample uses a four pole 24bB per octave low pass filter.

Analogue Amplifier

The VCA can be set to THRU so it is always 'open'. This allows Ample to be used as an effects processor.

2x Analogue Envelopes

There are two EGs - each having full control over ATTACK, DECAY, SUSTAIN, and RELEASE.

Modulation

Great thought has been placed into modulation route choices, allowing a wide range of sounds to be produced, including percussion and 'modular' sounds further extended by patching with the jack sockets and pin matrix.

MIDI

MIDI is intentionally kept simple - so you can concentrate on making new sounds and making music - not getting tied up with SYSEX programming.

You get the all important control over filter cut-off using MIDI Velocity.

Patchable External CV Control Sockets

Ample has many input and output audio and CV sockets - to allow the synth to be effectively re-wired to make new sounds.

The sockets also enable it to be easily used with Eurorack and other modular systems. They can be patched together.

Sequencer

Ample has a vintage style 16 step sequencer.

Touch Keys

There are 6 touch keys that each output a set voltage. Use this to play the pitch or as modulation signals. A great tool for inspiration!

Pin Matrix

A neat way to patch the synth.

Echo

Nice lo-fi echo / delay.

Notes: Gorgeous experimental system based around Make Noise's brilliant Maths, Morphagene, QPAS and Mimeophon modules. Capture and process sounds in stereo and warp them into new dimensions.

Supplier's Notes:
The Tape & Microsound Music Machine music synthesizer is a small stereo system devoted to capturing external sounds and sculpting them into new ones. The Morphagene operates as a recorder that also allows the artist to mulch, layer and rearrange the sound and manipulate the speed and direction of playback. The Mimeophon repeats sounds and subjects them to further manipulation, and when combined with the Quad Peak Animation System (QPAS), incredible stereo sculpting of the spectrum. The Wogglebug and MATHS work to animate these effects, and the XOH provides a final stereo mix and line level or headphone outputs for monitoring and/or performance.

Notes: Discover the perfect harmony of our top-of-the-line modules with our ORACLE system - a meticulously crafted 66hp stereo desktop instrument that seamlessly integrates our selection of eurorack modules: a full-featured system that offers a vast array of capabilities in a compact form factor. With ORACLE, you can dig into unorthodox sequencing, interactive modulation, and innovative stereo sounds- spanning styles ranging from ambient to techno, as well as experimental soundscapes and sound design.

At the heart of the system is our renowned module Chaos; within this compact ecosystem, it can unleash its full potential and seamlessly integrate with the other modules.

Chaos can produce control signals quickly and creatively with minimal user input. It can be used as a rhythmic or melodic sequencer, as a random or deterministic source of modulation: A random stream of data that you can manipulate at your linking and then loop.

Our ORACLE system is, indeed, built on the fundamental concept of loops, a powerful and versatile technique used in many forms of audio production. While loops are traditionally used to repeat audio samples, our system, ORACLE, expands on this concept by allowing you to loop various elements, including gestural movements, waveforms, note progressions, and beats from random sources.

With Thererec, our sketchable dual-channel function generator, you can experiment with your system's interaction differently. Move your hands over the sensors and loop your movements to create intricate voltage patterns, envelopes, or LFOs. With Thererec, you can unlock a new level of creativity in your system design.

One of the key features that sets our system apart is our advanced stereo oscillator, Proteo. With its innovative approach, it can convert any voltage source into high-quality audio waveforms and put them in a loop.Waveforms can be frozen or left in a constantly evolving state, giving Proteo an unheard distinctive sound. With Proteo, you can explore new territories and experiment with different audio sources, allowing you to create truly unique stereo sounds.

Axis includes all the classic blocks for audio amplitude management, such as a dual-function generator, dual VCA, a crossfader, channel volume, AM modulation, and dynamic control capabilities like velocity.The idea is to manipulate a sound over three axes: its length, its volume, and its place inside the stereo field.

At the end of the chain, Endline is our ultimate solution for your summing and outputs needs. This high-quality module offers four stereo channels of summing, sub-mix capabilities, two sends and returns, a headphone output, and transformer-balanced outputs.

Notes: A true powerhouse of a synth, packaging the Quantum synth engine into a more manageable four-octave design. Five synthesis modes, powerful stereo filters, performance features and outstanding playability.

Supplier's Notes:
Waldorf Iridium has made the impossible possible. The mighty synth engine from Quantum is now available in a compact form. Tracing the footsteps of its bigger brother, Iridium features all the synthesis elements of Quantum as well in a rack-compatible format. The combination of the powerful engine, incredible flexibility and detailed sound shaping facilities creates sheer endless possibilities of sound. Yet, the comprehensive layout and easy-to-understand structure lets you design your own sounds in no time. Sporting a solid metal casing and the same high level of craftsmanship like Quantum, Iridium is now ready to take over studios and stages throughout the world.

Contributing another entry in Waldorf's rich history, Iridium joins the family as a direct descendant of the PPG Wave. Though, Iridium offers much more than its ancestor. Five different synthesis models are provided by Iridium for each of the three oscillators:

Wavetable
Waveform (Virtual Analog)
Particle (Sampling and Granular Sampling)
Resonator
Kernels

Kernel mode has been introduced with the OS 2.0 of Quantum. This huge upgrade allows one oscillator to be turned into up to six sub oscillators. These can be interlinked through FM at audio rate and arranged in user-definable constellations. Just this upgrade alone would have provided enough additional features to create a synthesizer on its own. Now, all those functions have been integrated into Iridium as well.

Up to 7000 patches can be saved in Iridium. Patches from Quantum can be loaded in Iridium and vice-versa.

Iridium features three digital filters per voice. Two in the Dual Filter section and another one in the Digital Former. Several types are available to choose from:
12 or 24dB and Lowpass/Highpass/Bandpass with optional saturation or dirtiness.
Various filter models are available including those from Waldorf Nave, Largo and PPG 3V.
The Dual Filter section can be controlled independently or together in several different link modes.

The Digital Former offers all the filter types and models from the Dual Filter plus unusual models like Comb, Drive, Bitcrusher and more in addition.

All filters retain a true stereo signal throughout the entire structure of the instrument.

Specifications
16-voice polyphony, duo-timbral
Compatible with the Waldorf Quantum synth engine

3 Oscillators
Oscillator Modes:
Wavetable
Waveform (VA)
Particle (Sampling and Granular Sampling)
Resonator
Kernels (up to 6 sub-oscillators which can be interlinked through FM at audio rate)

3 Stereo Filters per voice
True stereo path
Dual Digital Filter:
Two filters with independable modes
12/24dB LP/HP/BP in all combinations
Nave, Largo, PPG, Quantum and StateVariable models
Digital Former:
Filter models from Waldorf Nave, Largo and PPG in HP/LP/BP/Notch
Comb filter
Bitcrusher
Drive
RingMod
StateVariable mode
Analyzer displayed in Filter view
Filter curve moves when modulated (optional)
Sophisticated filter routing options with modulatable panning and levels

Modulators:
6 Envelopes
6 LFOs
Komplex Modulator (LFO/Envelope combination with user-definable shape)

Mod Matrix:
40 slots
Fast assign mode
One additional control amount per slot
Identical Sources and Destinations can be used multiple times until the matrix is full

Pads:
4x4 silicon pad matrix with RGB backlights
Pads can play notes, chords, arpeggios and sequences
Latch mode

Performance features:
Arpeggiator
Step sequencer with up to 32 steps for notes and parameters
Favourites screen for quick patch recall
Onscreen Mod Wheel, Pitch Bend and Aftertouch

Screen:
Industrial-grade highly responsive touch screen

Patches:
Over 1000 factory sounds
Capacity of 7000 patch memory slots (numbers 0000-9999 can be used)
Patches from Quantum can be loaded and vice-versa
Category filter for patch list
2GB user sample flash memory

Connections:
2x TS output
2x TS input
Headphones output with Gain control
DIN MIDI In/Out/Thru
USB MIDI
USB host for storage and MIDI devices
MicroSD slot
Kensingtonr lock

CV connections:
4 CV inputs plus Gate In, Trigger In, Clock In, Clock Out
Inputs can be used as modulation sources in the Mod Matrix

Overall:
Sturdy metal case with aluminium knobs

Dimensions: 440mm wide by 305mm depth by 85mm height (including controls)
Weight: 5.4kg
19" rack assembly parts available

Notes: Discover the perfect harmony of our top-of-the-line modules with our ORACLE system - a meticulously crafted 66hp stereo desktop instrument that seamlessly integrates our selection of eurorack modules: a full-featured system that offers a vast array of capabilities in a compact form factor. With ORACLE, you can dig into unorthodox sequencing, interactive modulation, and innovative stereo sounds- spanning styles ranging from ambient to techno, as well as experimental soundscapes and sound design.

At the heart of the system is our renowned module Chaos; within this compact ecosystem, it can unleash its full potential and seamlessly integrate with the other modules.

Chaos can produce control signals quickly and creatively with minimal user input. It can be used as a rhythmic or melodic sequencer, as a random or deterministic source of modulation: A random stream of data that you can manipulate at your linking and then loop.

Our ORACLE system is, indeed, built on the fundamental concept of loops, a powerful and versatile technique used in many forms of audio production. While loops are traditionally used to repeat audio samples, our system, ORACLE, expands on this concept by allowing you to loop various elements, including gestural movements, waveforms, note progressions, and beats from random sources.

With Thererec, our sketchable dual-channel function generator, you can experiment with your system's interaction differently. Move your hands over the sensors and loop your movements to create intricate voltage patterns, envelopes, or LFOs. With Thererec, you can unlock a new level of creativity in your system design.

One of the key features that sets our system apart is our advanced stereo oscillator, Proteo. With its innovative approach, it can convert any voltage source into high-quality audio waveforms and put them in a loop.Waveforms can be frozen or left in a constantly evolving state, giving Proteo an unheard distinctive sound. With Proteo, you can explore new territories and experiment with different audio sources, allowing you to create truly unique stereo sounds.

Axis includes all the classic blocks for audio amplitude management, such as a dual-function generator, dual VCA, a crossfader, channel volume, AM modulation, and dynamic control capabilities like velocity.The idea is to manipulate a sound over three axes: its length, its volume, and its place inside the stereo field.

At the end of the chain, Endline is our ultimate solution for your summing and outputs needs. This high-quality module offers four stereo channels of summing, sub-mix capabilities, two sends and returns, a headphone output, and transformer-balanced outputs.

Notes: Tracing the footsteps of its bigger brother, Iridium features all the synthesis elements of Quantum as well in a rack-compatible format. The combination of the powerful engine, incredible flexibility and detailed sound shaping facilities creates sheer endless possibilities of sound. Yet, the comprehensive layout and easy-to-understand structure lets you design your own sounds in no time. Sporting a solid metal casing and the same high level of craftsmanship like Quantum, Iridium is now ready to take over studios and stages throughout the world.

Contributing another entry in Waldorf's rich history, Iridium joins the family as a direct descendant of the PPG Wave. Though, Iridium offers much more than its ancestor. Five different synthesis models are provided by Iridium for each of the three oscillators:

Wavetable
Waveform (Virtual Analog)
Particle (Sampling and Granular Sampling)
Resonator
Kernels

Kernel mode has been introduced with the OS 2.0 of Quantum. This huge upgrade allows one oscillator to be turned into up to six sub oscillators. These can be interlinked through FM at audio rate and arranged in user-definable constellations. Just this upgrade alone would have provided enough additional features to create a synthesizer on its own. Now, all those functions have been integrated into Iridium as well.

Up to 7000 patches can be saved in Iridium. Patches from Quantum can be loaded in Iridium and vice-versa.

Iridium features three digital filters per voice. Two in the Dual Filter section and another one in the Digital Former. Several types are available to choose from:

12 or 24dB and Lowpass/Highpass/Bandpass with optional saturation or dirtiness.
Various filter models are available including those from Waldorf Nave, Largo and PPG 3V.
The Dual Filter section can be controlled independently or together in several different link modes.
The Digital Former offers all the filter types and models from the Dual Filter plus unusual models like Comb, Drive, Bitcrusher and more in addition.

All filters retain a true stereo signal throughout the entire structure of the instrument.

Up and down, back and forth
6 Envelopes, 6 LFOs and many more are just waiting for being used as sources in the 40 slots of the Modulation Matrix. Each slot has one additional control amount. Modulations can be directed to almost every numerical value in Iridium. All sources and destinations can be used as many times as desired until the Modulation Matrix is full. If you ever happen to run out of LFOs or Envelopes, you can use the Komplex Modulator for generating a custom shape LFO or Envelope.

Even though Iridium features a staggering amount of parameters to control, everything is organized in a logic structure which is easy to master. The major controls have their own dedicated knob, while the rest is accessible through the touch screen and the encoders around. There are no long menus keeping you from doing what you had planned. Instead, you will find a workflow which you will soon miss on other synthesizers.

Embedded in the front panel, a 4x4 silicon pad matrix invites you to launch notes, chords, arpeggios and sequences with up to 32 steps for notes and multiple parameter lines. Direct access to the parameters is granted by the seven encoders to the left and the right hand side of the touch screen.

Iridium's large color touch screen keeps you informed at all times. Upon moving a knob, Iridium gives you an optical feedback of your changes in real-time. Filter curves move, Particle grain sizes change, Envelopes warp and much more:

Komplex Modulator curves can be drawn with your finger
Envelopes show at which point the voices currently are
Wavetables are displayed in comprehensive view modes
VU meters show which voices are used and the individual voice levels
Different Analyzers show the audio signal at different points

Two Audio Outputs allow you to listen to Iridium, while two Inputs allow Iridium to process external signals. 4 CV inputs plus Gate In and Trigger In are ready to forward external signals to the Mod Matrix. Furthermore, Clock In and Clock Out will get your gear in sync. MIDI connections can be made through USB and DIN MIDI. Iridium is also equipped with a USB Host port for MIDI devices. This port also handles data exchange, in addition to the MicroSD card slot.

Once again, Waldorf have underlined their status with a new and exciting synthesizer.

Notes: Reinventing the virtual analogue synth for the 21st century, the Vibes is a digital demon. True stereo signal path, resonant oscillators, Serum-compatible wavetables and heaps of creative potential.

Supplier's Notes:
Small form, big heart

True Stereophonic Digital Synthesiser with 24 Stereo Voices

With its 24 stereo voices, powerful XVA Engine, full Audio Mixer, improved Clip Launcher, comprehensive Drum Engine and the new Resonator Oscillator, Vibes becomes a new class of synthesizer, that helps you to reach your full creative potential.

True stereo

The true stereo signal path allows for sounds, that have never been possible before.

Oscillators that resonate

The new Resonator Oscillator together with the existing Wavetable Oscillator open up a new world of sonic potential.

Sketching, writing performing

The only synthesiser you need for writing and performing your compositions.

Mix it all together!

Mix internal sounds and stereo input with the Digital Audio Mixer integrated into the Vibes!

One preset, eight different flavours

Store your ideas and recall them in an instant with Variants

Engine specs

Based on Mayer EMI's powerful XVA Audio Engine the Vibes is preset compatible with the MD900 and comes with the following feature set:

24 shared Stereo Voices
4 Synth-Parts + 14 Drum Instruments

Stereo structure per voice

2x Oscillator with 3 different models

Algorithm Oscillator

8 different Waveforms (PD_SIN, VA_SWEEP, and more)
Morphing and Modulation capabilities

Wavetable Oscillator

More than 50 preset wavetables
Wavetables consisting of up to 256 single-cycle waveforms with 2048 samples per cycle (Serum format compatible)
Spectral effects (spectral morph, harmonic shift, ... and more)
Up to 4x stereo unison

Resonator (physical modelling)

64 bands
Attack/Decay based exciter
Different Algorithms to define Band Profile

1x Sample / Noise Oscillator
Configurable loop modes and loop points
Single- or Multi-Samples

2x Stereo Multimode Filter with more than 10 different Models
4x ADSR Envelopes
3x LFOs (MIDI synchronized, standard & user defined shapes)
1x Waveform Shaper with different Algorithms
Modulation Matrix with 24 slots (25 source and 40 destination options)
Oscillator Mix and Filter Routing

ARPEGGIATOR and STEP SEQUENCER per Synth Part

Clip launcher

7 tracks (4 Synth-Parts, Drum Track, 2 Midi Tracks for external Instruments) with up to 8 clips per track
Polyphonic MIDI Sequencer with recording and quantization capabilities
Drum Pattern and Sequence Editor
Support of external Performance Controllers (e.g. Launchpad, APKmini) via USB

Synth and live effect stacks

4x Stereo Multi Effect Stack (1x for each Synth Part)
2x Stereo Live Multi Effect Stack in the Audio Mixer
Reverb, Stereo Delay (midi synchronized), Compressor, JChorus6, ... and more)

Digital audio mixer

19 Stereo Input Channels, 2 Stereo Output Channels
Bus, Headphone and Effect Send
Balance, Pan, Limiter functionality

MIDI connectivity

MIDI Control, Note On-Off, Pitchwheel, Polyphonic Aftertouch
Transport Send/Receive
Clock Send/Receive

Webinterface

Up-/ Download of user defined Presets, Performances, Wavetables, Samples, Sequences
Accessible via Wi-Fi or Ethernet

Others

14 GB internal Memory available for Presets, Wavetables, Samples, Performances and MIDI Sequences

Hardware specs

Control elements

5" Colour capacitive Touch-Screen (Resolution 800×480 pixel)
4 display related and 1 Main Encoder
20 Navigation and Menu Buttons
One Knob Section (morphing of multiple parameters together)
3 Synth-Part related Macro Encoder (Multicolour LED Rings)
3 Filter related Encoder (Multicolour LED Rings for Filter CutOff, Resonance and Amount)

Housing

Size (W x D x H): 322mm x 174mm x 76mm
Weight: 2kg
Metal Housing with walnut wood front and back
75mm x 75mm VESA Mount

Inputs/outputs

Power Switch
Power In 12VDC, 2.5A
3x USB-A Port (max. 500mA)
Ethernet (100Mbit)
Sustain Pedal-In: 6,3 mm TR Jack
Expression Pedal In: 6,3 mm TR Jack
DIN MIDI In / Through / Out
Stereo Line-In: 6,3 mm TRS Jack (24bit, 48Khz)
Stereo Line-Out: 6,3mm TRS Jack (24bit, 48Khz)
Stereo Headphone Out: 6,3 mm TRS Jack (16bit, 48Khz)
2,4/5GHz Wifi

Package contents

Vibes MD850
Power Supply 12VDC (including Plugs for EU, UK, US, AUS)
Quick Start Manual

Notes: SOLAR 42F is a unique experimental electro-music instrument, an analogue microtonal ambient drone machine. It will inspire you to find a new and spontaneous approach to composing music. It gives you the ability to create a multi-layered, massive sound. The instrument is oriented for live performances, creating film soundtracks, theatre soundtracks, atmospheric sounds, microtonal and background music.

It is an improved version of the older SOLAR 50 model. The instrument was inspired by early electronic musical instruments of the 1920s and 1950s, notably Leo Theremin's "Harmonium" instrument, as well as science fiction film soundtracks.

The new version of the Solar 42F has added a LIN/EXP CV switch, sub oscillators in volt octave voices and a band pass and stereo distortion mode to the filter. Other quality of life improvements include modified graphics - inputs have been labeled in black and outputs in red for convenience - bypasses for each channel of the effector and a LED indication in the joystick unit.

Notes: SOLAR 42F is a unique experimental electro-music instrument, an analogue microtonal ambient drone machine. It will inspire you to find a new and spontaneous approach to composing music. It gives you the ability to create a multi-layered, massive sound. The instrument is oriented for live performances, creating film soundtracks, theatre soundtracks, atmospheric sounds, microtonal and background music.

It is an improved version of the older SOLAR 50 model. The instrument was inspired by early electronic musical instruments of the 1920s and 1950s, notably Leo Theremin's "Harmonium" instrument, as well as science fiction film soundtracks.

The new version of the Solar 42F has added a LIN/EXP CV switch, sub oscillators in volt octave voices and a band pass and stereo distortion mode to the filter. Other quality of life improvements include modified graphics - inputs have been labeled in black and outputs in red for convenience - bypasses for each channel of the effector and a LED indication in the joystick unit.

Notes: SOLAR 42F is a unique experimental electro-music instrument, an analogue microtonal ambient drone machine. It will inspire you to find a new and spontaneous approach to composing music. It gives you the ability to create a multi-layered, massive sound. The instrument is oriented for live performances, creating film soundtracks, theatre soundtracks, atmospheric sounds, microtonal and background music.

It is an improved version of the older SOLAR 50 model. The instrument was inspired by early electronic musical instruments of the 1920s and 1950s, notably Leo Theremin's "Harmonium" instrument, as well as science fiction film soundtracks.

The new version of the Solar 42F has added a LIN/EXP CV switch, sub oscillators in volt octave voices and a band pass and stereo distortion mode to the filter. Other quality of life improvements include modified graphics - inputs have been labeled in black and outputs in red for convenience - bypasses for each channel of the effector and a LED indication in the joystick unit.

Notes: SOLAR 42F is a unique experimental electro-music instrument, an analogue microtonal ambient drone machine. It will inspire you to find a new and spontaneous approach to composing music. It gives you the ability to create a multi-layered, massive sound. The instrument is oriented for live performances, creating film soundtracks, theatre soundtracks, atmospheric sounds, microtonal and background music.

It is an improved version of the older SOLAR 50 model. The instrument was inspired by early electronic musical instruments of the 1920s and 1950s, notably Leo Theremin's "Harmonium" instrument, as well as science fiction film soundtracks.

The new version of the Solar 42F has added a LIN/EXP CV switch, sub oscillators in volt octave voices and a band pass and stereo distortion mode to the filter. Other quality of life improvements include modified graphics - inputs have been labeled in black and outputs in red for convenience - bypasses for each channel of the effector and a LED indication in the joystick unit.

Notes: SOLAR 42F is a unique experimental electro-music instrument, an analogue microtonal ambient drone machine. It will inspire you to find a new and spontaneous approach to composing music. It gives you the ability to create a multi-layered, massive sound. The instrument is oriented for live performances, creating film soundtracks, theatre soundtracks, atmospheric sounds, microtonal and background music.

It is an improved version of the older SOLAR 50 model. The instrument was inspired by early electronic musical instruments of the 1920s and 1950s, notably Leo Theremin's "Harmonium" instrument, as well as science fiction film soundtracks.

The new version of the Solar 42F has added a LIN/EXP CV switch, sub oscillators in volt octave voices and a band pass and stereo distortion mode to the filter. Other quality of life improvements include modified graphics - inputs have been labeled in black and outputs in red for convenience - bypasses for each channel of the effector and a LED indication in the joystick unit.

Notes: Updated version of Erica's superb EMS-inspired synth, featuring a powerful dual oscillator synth architecture, piano roll sequencer, modulation matrix and recordable joystick.

Supplier's Notes:
Based on lessons learned from the SYNTRX, Erica Synths decided to create an instrument that would integrate even deeper into contemporary electronic and experimental music setups and cover sonic territory from daunting drones to powerful basslines and glitched noisescapes - the SYNTRX II is a new dark horse for experimental sonic rides.

The SYNTRX II is the culmination of Erica Synths' analogue sound design circuits - two perfectly stable main oscillators with waveshapers, a modulation oscillator with 1V/oct tracking, a versatile multimode filter, supercharged external instrument inputs with an envelope follower, a unique, great-sounding ring modulator, a recordable joystick, built-in piano roll sequencer and stepped modulation sources, all arranged around Erica Synths' signature matrix mixer and topped off with powerful FX on their new DSP platform.

"The SYNTRX 2 is awesome, a very different instrument from V1. My first synths were the VCS3 and the AKS and are still among my favorites today. The Syntrx 2 is pushing the boundaries of possibilities & experimentations much beyond the original analogue version. The Syntrx 2 is an instant classic". - Jean Michel Jarre

Features

Two perfectly stable main oscillators with CV-controlled waveforms
Modulation oscillator with variable waveforms
Highpass and Lowpass filters in series
Free running or gate synced sample and hold circuit
Multi-colour noise generator
DC coupled instrument inputs with signal inversion and envelope follower
Ring modulator of unique design
Looping trapezoid envelope generator and VCA
Two output VCAs
Signal meter with a dedicated audio/CV output
FX section with great sounding Delay and Reverb developed in collaboration with 112db.com
Recordable Joystick
Analogue patch matrix with 3 attenuation levels in each patch point
254 patch memory
Piano roll sequencer and two stepper modulation sources
DIN5 MIDI Input and MIDI Thru
Two assignable outputs
Headphone output
Dimensions: 309mm x 457mm x 115mm (with the joystick in centre position)
Weight: 3.9 kg

Notes: Typically creative stuff from Pittsburgh Modular, the updated Voltage Lab is the pinnacle of the brand's synth output. Dual oscillator design with a 16-note touch controller, built-in sequencer and MIDI control.

Supplier's Notes:
The Pittsburgh Modular Voltage Lab 2 is a cutting edge synthesis laboratory that offers a new palette of analogue textures and waveforms to sonic researchers. Newly developed wave shaping capabilities paired with powerful synthesis tools, and a deep, performance oriented controller join together to create a complete sound design laboratory. This instrument has a very physical sound. The tones it creates feel natural and alive, with traditional waveforms becoming the seeds of unique new shapes and sounds that shift between analogue physical modeling and more unfamiliar, abstract timbres.

Laboratory Oscillator 1

Voltage Lab 2 includes a pair of Laboratory Oscillators. Each with a unique set of newly invented waveshaping tools designed to expand the sonic potential of analogue synthesis. Laboratory Oscillator 1 introduces Center Clipping to analogue synthesis. Center clipping unlocks independent control over the top and bottom of the waveform, allowing for detailed manipulation of harmonics and timbre without affecting pitch. It does this by processing waveforms from the center out as opposed to traditional methods which work from the peaks inwards.

Laboratory Oscillator 2

Laboratory Oscillator 2 introduces a host of new sonic possibilities with two new waveshapers. Pulse Symmetry and Reflection. Pulse Symmetry creates a new species of pulse wave that adds a step between the top and bottom of the waveform. The resulting wave looks like a set of stairs where the depth of the center step can be adjusted in addition to the pulse width. Wave Reflection takes the bottom half of the waveform and reflects it onto the top half. Each waveshape responds to this differently. For example, a saw wave morphs into a triangle while triangle and sine waves lose their fundamental harmonic and jump up an octave.

Pittsburgh Dynamics Controllers

The new Dynamics technology imparts Voltage Lab 2 with a uniquely organic depth and presence. By simultaneously managing both amplitude and harmonic content, the Pittsburgh Dynamics Controller expands beyond the one dimensional VCA found in other synthesizers. It does this by utilizing new advancements from traditional low pass gates to add additional definition and dimension to the voices of the Voltage Lab 2.

When used in low pass gate mode, sounds shed harmonic content and become warmer as they decrease in volume. This mimics how sound waves react to their environment. Because of this connection, the Voltage Lab 2 sounds more natural or complex compared to other instruments.

Touch Controller 2

The Touch Controller 2 enables artists to blend traditional pitched performances with the freedom to openly experiment, creating a flexible playground for music creation. Two independent channels offer a combination of real time, expressive playing and in-depth sequencing. Assignable scales, step conditions, jumps, chance effects, generative sequencing, and a host of other tools, come together allowing musicians to both create and interact with complex systems.

A Florist and Echos

The Voltage Lab 2 includes a set of analogue time based effects, Florist and Echos. The Florist is a flanger/chorus hybrid that focuses on brighter, short time shifts with highly controlled feedback allowing for maximum ringing before self oscillation. Echos is a more traditional, darker analogue BBD delay that also utilizes highly controlled feedback to provide a larger number of repeats before falling into self oscillation. Both effects are perfect for traditional workflows and unconventional experimentation.

Complete Set of Modular Tools

The Voltage Lab 2 includes a host of fully modular, analogue and digital synthesis tools to support and enhance it's core functionality. Analog tools include flexible mixers, a pair of complex function generators, noise, sample and hold, and an LFO. Digital tools cover external MIDI, arpeggiator, and a robust chance sequencer. The Voltage Lab 2 toolset is deep enough for all types of sonic experiments.

Notes: Part of Teenage Engineering's high-end Field series, the OP-XY is best seen as a pro groovebox, combining polyphonic synthesis, sampling and sequencing. More music-focussed than its OP-Z predecessor, the OP-XY represents a new flagship for TE.

Supplier's Notes:
No-compromise, dual-CPU boosted and fully rebuilt sequencer, sampler, and performance instrument, based on the much-loved workflow of the OP-Z. Now including built-in cv, effect sends, and a best-in-class DAC. with 8 individual instrument tracks and 8 auxiliary tracks for controlling any external synthesizer, modular or otherwise, and adding effects. It's probably the most complete, portable sequencer ever built. It's here. It's real. it's black.

And it's got so much more than you've wished for.

The exterior is all black, and matches the exact dimensions of OP-1 field. A distinct grayscale gradient is at its centre, making it clear that OP-XY is all about serious sequencing. Hands-on graphics on the high-resolution display are all grayscale, with a bright red to indicate recording and parameter locks. all vital keys have LEDs to stay in full control.

Experience the ultra fast sequencing workflow. Punch-in FX lets you add quick, rapid-firing, unique, live variations and adding individual step components creates an extra dimension and deep rhythmic patterns. randomize note timing, velocity and pitch, or use live automation to alter filters. Use brain to create chord progressions, generating tracks that reinvent themselves. Literally.

Run every track, independently, at different speeds and lengths to form powerful polyrhythms. create new sequences every time with step components, variations that can be added to any step on the sequencer, controlling everything from altering pitch to bending, skipping or even multiplying steps.

Main audio-out

Multi-out, featuring:
MIDI
CV/gate
Sync
Aux audio
MIDI IN
AUDIO IN
USB-C

The 2 Vrms main output drives any sound system, real loud. Keep everything locked in sync and sequenced with the multi-out and take control with MID IN. process and sample external audio with the audio-in. control, record and charge with the audio/midi host over USB-C, plus a complete wireless experience with midi over Bluetooth LE -keine bedingungen [no strings attached].

Compose your album, head off to the gig, plug and play immediately, then keep everything locked-in with all the I/O you could ask for. 16-hour, battery-powered freedom lets you perform for hours on-end. create, produce and perform anywhere. Mit allen bedingungen [all strings attached]

The bottom left side features a pressure sensitive pitchbend

Instrument tracks:

8 individually sequenceable instrument tracks
8 unique synth engines
3 samplers
independent send levels per track

Step components
14 unique step components for advanced step sequencing
Apply up to all 14 to every step screen
480 x 222px IPS TFT display

Patterns
9 patterns per track
up to 64 bars per pattern
spread across 4 pages
presets per pattern

Effects: reverb, delay, chorus, distortion, lo-fi, phaser

Hardware
Dual blackfin processing cores
Dual DDR memory
Triple-core dsp co-processor
2x controller MCU's for wireless & low power IO domain

Sensors: 6-axis IMU accelerometer

Microphone: immediate, high quality sampling with the built-in microphone.

Connectors: 3.5 mm stereo line-out with headset mic support
3.5 mm multi-out
3.5 mm midi in
3.5 mm stereo line-in

Tactile input
2 octave musical keyboard
68 ultra low profile mechanical buttons
Pressure sensitive pitch bend
4 x multi purpose grayscale encoders

USB
USB type C connector
USB MIDI host & device
USB audio host & device

Notes: The M4000D Mini Mellotron was developed to meet the needs of keyboardists who want an even smaller and lighter Digital Mellotron. The Mini is also designed to fit perfectly on top of the regular M4000D to make a great looking dual manual Mellotron. Instead of the M4000D's wooden keyboard, it includes a high-quality, semi-weighted Fatar piano-style keyboard with velocity sensitivity, and mono aftertouch.

Specifications

100 instantly accessible Mellotron and Chamberlin sounds, captured from original tape sources at 24-bits, uncompressed
Expansion slot for 100 additional sounds
A and B sound banks simultaneously accessible, with mix control
Controls for volume, tone, normal/half-speed play and pitch adjustment
A, B and Master outputs available on unbalanced 1/4-in. line connectors
1/4-in. connectors for sustain, expression, and volume pedals, and for headphones
MIDI in, out, and thru
Dimensions: 32 in (W) x 13 in (D) x 3 in (H); weight: 21 pounds

Notes: The excellent Bullfrog synth gets a new bigger brother in the form of the XL, an expanded and enhanced version of this collaborative analogue instrument, featuring built-in speakers, oscilloscope and plenty of new synth options.

Supplier's Notes:
Bullfrog invites you to unlock your musicality while combining the thrill of electronic music production with a comprehensive learning experience. Bullfrog XL is designed specifically for teachers to use in front of the classroom and it expands the concept of the regular Bullfrog by inflating its size by a factor of 3 (literally!). With its expanded size and built-in oscilloscope, Bullfrog XL isn't just for classrooms but will be a great addition to any studio.

Features

Fully analogue design
Highly accurate voltage controlled oscillator (VCO) that tracks great over 8 octaves
Manually adjustable and voltage controlled waveshapes - sine-shark fin and pulse wave with pulse width modulation (PWM)
Zener diode-based noise generator
Resonant lowpass voltage controlled filter (VCF)
Voltage controlled amplifier (VCA) with adjustable offset
Delay effect with adjustable delay time and feedback amount
Two looping attack-sustain-release envelope generators (EG)
Sample & Hold circuit with an individual clock
Attenuverter
Slew processor with adjustable slew time
Two buffered splitter circuits
Two channel oscilloscope
6.3 mm jack sockets
Manual gate button
Gate and Trigger out
Voice card slot
Built in speakers
DIN5 MIDI input
USB connector
Keyhole slots on the rear panel
Dimensions (mm): 820x505x65 (250 with the side panels)
Mass: 8.3 kg

What's included:

BULLFROG XL synthesizer with side panels
Universal 12VDC wall wart adapter with the power cable
User manual
12 1/4" patch cables
Sequencer, Sampler/Looper, Acid Bassline, Hi-pass filter, LFO and Electric Organ Voice cards
3 DIY voice cards

Created by Erica Synths & Richie Hawtin, Bullfrog is an educational electronic music instrument designed to captivate and inspire both youth and professionals alike. Bullfrog invites you to unlock musicality while combining the thrill of electronic music production with a comprehensive learning experience.

In order to provide a well-rounded understanding of the functionality of this synthesizer and sound synthesis in general, a comprehensive user manual is created to accompany the learning process.

Notes: A massive semi-modular system in a small case with the footprint of a laptop. Cascadia has MIDI in/out/thru/USB, Eurorack compatible signal levels and pro-level audio I/O to interface with the rest of your studio or get your studio started.

Modern Analogue Architecture

Cascadia is packed with a mix of classic East and West Coast synthesizer blocks. Normalized connections let you get straight to the sounds inside. Or, let your imagination run wild and patch any of the modules together however you choose. Make small tweaks to the architecture, or re-route the entire synth to your liking- the choice is yours!

Summary:
Cascadia semi-modular synthesizer.
101 patch points, 34 sliders, 16 knobs, 28 switches, 5 push buttons, and 36 leds.
14 Patch cables - 4×10cm, 4×15cm, 4×30cm, 2×45cm.
USB-C to A cable.
International AC Adaptor.
Intellijel cable tie.

Two Precision Analogue VCOs
VCO A is Thru-zero FM-ready with a dedicated Index VCA, Sub Oscillator, PWM and Soft/hard sync.
VCO B is a combo VCO/LFO with 4 simultaneous outputs
Six Channel Waveform Mixer
Two patchable (normalled) inputs
Noise generator with multiple algorithms.
Optional asymmetric soft clipping on the mix output.
Liquid-Sounding, Cascaded 4-Pole Multimode Filter
Eight Modes: LP1, LP2, LP4, BP2, BP4, HP4, NT2, Phazor.
Additional dedicated outputs for LP4 and HP4.
Input Level Knob for fine control of filter input and resonance balance and added drive.
Multiple FM inputs and a QM input, all with attenuators.
Wavefolder Circuit
West Coast-style parallel wavefolder.
Normalled into the auxiliary input on the VCA in parallel with the filter.
Dual Digital Envelopes
ENV A is a versatile east coast style ADSR / AHDSR envelope generator with a hold function and dynamic level/time control. Normalled to the VCA to instantly shape your sound.
ENV B is a complex, multimode function generator with a West Coast style AR/ASR/Cycling AR, a beat syncable LFO, Burst generator modes, and the Entropic Sequence Generator (added in 1.3). Normalled to the filter for instant FM without patching.
VCA A and Output Path
VCA A is a linear VCA with auxiliary input.
Global Output Mixer with overdrive circuit and bypassable asymmetric soft clipping.

Expansive Utilities Sections
Cascadia also features a whole host of utilities for getting the most out of your patches.

The Utility Row
Sample and hold circuit with white noise normalled to the input.
Slew/Envelope follower.
Attenuverter/Mixer with multiple outputs.
Triple triangle LFO with rate control, rate input and divided outputs.
Triple buffered multiple.
Precision adder.
Signal inverter.
Bi-polar > Unity level shifter.
Expression level control for modulation the TRS expression input on an FX pedal.
Ring Modulator.
VCA B / LPF (LPG) - Auxiliary VCA and 4-Pole Diode Ladder VCF combination for additional dynamics.
The Top Row
Easy to access Pitch, Gate, and Velocity CV inputs.
Pedal Send and Return FX loop with Wet/Dry control, phase inverter and Line/Pedal level switches.
Output Mixer with Overdrive.
Eurorack Level Main output with level control for interfacing with other modular gear.

The Outside world - MIDI, Pedal and Audio I/O
Cascadia is equipped with a ton of I/O to get it connected to the rest of your gear.

Rear Panel

1/4" Stereo Headphone jack.
1/4" Balanced Output Jack.
1/4" Balanced Input routed to a slider and output on the main panel for patching anywhere into Cascadia.
1/4" TS Pedal FX Send Return and 14" TRS Expression Out.
MIDI DIN In/Out/Thru and USB-MIDI all routed to the MIDI > CV Interface on the top panel.
MIDI > CV Interface
Deeper MIDI configuration is available with the Intelljel Config App (link below). MPE Support has been added in v1.4 and supports the Ableton Live 12 Tuning systems. Dual Mono mode (added in 1.3) allows an additional channel to send its own Pitch/Gate signal on the CC/MOD outputs. All modes support MIDI Portamento.

MIDI Pitch / Velocity Outputs and Learn Button
MIDI Gate / Trig Outputs
MIDI CC / Mod - Learnable and assignable to any CC or Channel Pressure
MIDI LFO - Multimode LFO synced with MIDI or Tap Clock
MIDI CLK - Dividable MIDI clock with alternate Tap Clock functionality.
Cascadia comes ready to play.

The normalization behind the panel allows for a ton of exploration without ever adding a patch cable; there is years of material to explore in Cascadia and years more when you start patching. There is everything you need to get started: 14 assorted patch cables, USB-A to USB-C cable, and an international power supply.

Expand and Customize

In addition to additional patch cables, there are additional options for swapping the wooden cheeks for metal side cheeks or a rackmount kit with a storage tray - great for an effects pedal or patch cables.

Specs

In the Box: Cascadia Semi-modular Synthesizer
14 Patch cables - 4×10cm, 4×15cm, 4×30cm, 2×45cm
USB-C to A cable
Intellijel cable tie
15V/1.2A AC Adaptor (Euro/American prongs included)

Height: 66mm (from rubber foot to top of knobs)
Width: 348mm (including wood end cheeks)
Depth: 246mm (front to rear jacks).
Power: 15V DC/1.0 A (minimum), centre-pin-positive.

Notes: White fog version of Intellijel's brilliant Cascadia, one of our favourite synths of recent years. A huge range of semi-modular circuits combine to create a hands-on instrument with its own distinctive character.

Supplier's Notes:
A massive semi-modular system in a small case with the footprint of a laptop. Cascadia has MIDI in/out/thru/USB, Eurorack compatible signal levels and pro-level audio I/O to interface with the rest of your studio or get your studio started.

Modern Analogue Architecture

Cascadia is packed with a mix of classic East and West Coast synthesizer blocks. Normalized connections let you get straight to the sounds inside. Or, let your imagination run wild and patch any of the modules together however you choose. Make small tweaks to the architecture, or re-route the entire synth to your liking- the choice is yours!

Two Precision Analogue VCOs
VCO A is Thru-zero FM-ready with a dedicated Index VCA, Sub Oscillator, PWM and Soft/hard sync.
VCO B is a combo VCO/LFO with 4 simultaneous outputs
Six Channel Waveform Mixer
Two patchable (normalled) inputs
Noise generator with multiple algorithms.
Optional asymmetric soft clipping on the mix output.
Liquid-Sounding, Cascaded 4-Pole Multimode Filter
Eight Modes: LP1, LP2, LP4, BP2, BP4, HP4, NT2, Phazor.
Additional dedicated outputs for LP4 and HP4.
Input Level Knob for fine control of filter input and resonance balance and added drive.
Multiple FM inputs and a QM input, all with attenuators.

Wavefolder Circuit

West Coast-style parallel wavefolder.

Normalled into the auxiliary input on the VCA in parallel with the filter.

Dual Digital Envelopes

ENV A is a versatile east coast style ADSR / AHDSR envelope generator with a hold function and dynamic level/time control. Normalled to the VCA to instantly shape your sound.

ENV B is a complex, multimode function generator with a West Coast style AR/ASR/Cycling AR, a beat syncable LFO, Burst generator modes, and the Entropic Sequence Generator (added in 1.3). Normalled to the filter for instant FM without patching.

VCA A and Output Path

VCA A is a linear VCA with auxiliary input.
Global Output Mixer with overdrive circuit and bypassable asymmetric soft clipping.

Expansive Utilities Sections
Cascadia also features a whole host of utilities for getting the most out of your patches.

The Utility Row
Sample and hold circuit with white noise normalled to the input.

Slew/Envelope follower.
Attenuverter/Mixer with multiple outputs.

Triple triangle LFO with rate control, rate input and divided outputs.
Triple buffered multiple.

Precision adder.

Signal inverter.

Bi-polar > Unity level shifter.
Expression level control for modulation the TRS expression input on an FX pedal.

Ring Modulator.
VCA B / LPF (LPG) - Auxiliary VCA and 4-Pole Diode Ladder VCF combination for additional dynamics.

The Top Row
Easy to access Pitch, Gate, and Velocity CV inputs.
Pedal Send and Return FX loop with Wet/Dry control, phase inverter and Line/Pedal level switches.

Output Mixer with Overdrive.
Eurorack Level Main output with level control for interfacing with other modular gear.

The Outside world i MIDI, Pedal and Audio I/O
Cascadia is equipped with a ton of I/O to get it connected to the rest of your gear.

Rear Panel

1/4" Stereo Headphone jack.
1/4" Balanced Output Jack.
1/4" Balanced Input routed to a slider and output on the main panel for patching anywhere into Cascadia.
1/4" TS Pedal FX Send Return and 14" TRS Expression Out.
MIDI DIN In/Out/Thru and USB-MIDI all routed to the MIDI > CV Interface on the top panel.
MIDI > CV Interface
Deeper MIDI configuration is available with the Intelljel Config App. MPE Support has been added in v1.4 and supports the Ableton Live 12 Tuning systems. Dual Mono mode (added in 1.3) allows an additional channel to send it's own Pitch/Gate signal on the CC/MOD outputs. All modes support MIDI Portamento.

MIDI Pitch / Velocity Outputs and Learn Button
MIDI Gate / Trig Outputs
MIDI CC / Mod - Learnable and assignable to any CC or Channel Pressure
MIDI LFO - Multimode LFO synced with MIDI or Tap Clock
MIDI CLK - Dividable MIDI clock with alternate Tap Clock functionality.
Cascadia comes ready to play.
The normalization behind the panel allows for a ton of exploration without ever adding a patch cable; there is years of material to explore in Cascadia and years more when you start patching. Everything you need to get started is included: 14 assorted patch cables, USB-A to USB-C cable, and an international power supply.

Expand and Customize
In addition to additional patch cables, there are great additional options for swapping the wooden cheeks for metal side cheeks or a rackmount kit with a storage tray- great for an effects pedal or patch cables.

Specs

In the Box: Cascadia Semi-modular Synthesizer
14 Patch cables - 4×10cm, 4×15cm, 4×30cm, 2×45cm
USB-C to A cable
Intellijel cable tie
15V/1.2A AC Adaptor (Euro/American prongs included)

Height: 66mm (from rubber foot to top of knobs)
Width: 348mm (including wood end cheeks)
Depth: 246mm (front to rear jacks).
Power: 15V DC/1.0 A (minimum), centre-pin-positive.

Notes: The new PerFourMer is a real analog synthesizer, through its simple control surface and very flexible sound production it is able to offer a near inexhaustible variety of Bass, Lead, Pad and Effect sounds. Additionally, with its total of six filter inputs, the PerFourMer is also perfectly suited as a complex filter-bank. Even though the PerFourMer is not considered a modular system, it can still be described as a modular or at the very least a semi-modular. The basic concept is reminiscent of classics such as the Oberheim 4 Voice or the Korg Monopoly.

The PerFourMer is a 4 voice synthesizer, consisting of completely independent synthesizers, which can be adjusted and played independently from each other. These four synthesizer channels can be linked with each other and be played in 3 different operating modes.

Next to the already mentioned filter inputs, each channel has a single output, which can also be used as an insert for external effect devices, and make it possible to easily integrate the PerFourMer with already established equipment. It is also possible to transmit the unedited VCO signal. Additionally the opportunities of the PerFourMer can be expanded through internal patching between the channels, for example; you can route a VCO through multiple filters and VCAs, or use 2 channels to create 1 voice with 2 ADSR envelopes (1 for VCA and 1 for VCF). Use the PerFourMer as a filter-bank and the slope envelope can be doubled by interconnecting the filter in series. The PerFourMer is controlled via MIDI and additionally via CV/gate (1V/octave) inputs for every synthesizer channel.

Notes: The Subsequent 37 is a (2-note) paraphonic analogue synthesizer that builds upon the award-winning design of the ultra-powerful Sub 37 Tribute Edition. Its control panel is home to 40 knobs and 74 switches, placing a vast array of analogue sound-design tools and onboard sequencing options immediately at your command. The Subsequent 37 improves upon its source through the implementation of a number of user-requested sonic and functional enhancements. Each enhancement maintains the magic and character of its predecessor while also providing access to new dimensions of sound and improved playability.

The SUBSEQUENT 37 mixer section has double the headroom of that in the Sub 37 Tribute Edition. This provides access to a new range of classic clean tones in both mono and duo performance modes. Leveraging the mixer's newfound flexibility, gain-staging in the Ladder filter has been reshaped to boost harmonic saturation and analogue compression, resulting in an overall richer low end. Completing the sonic evolution of the SUBSEQUENT 37 is a re-tuned Multidrive circuit that extends well beyond the grit and growl of the original Sub 37.

"We are really excited to incorporate community feedback into the evolution of an instrument. Adding CV interconnectivity was the starting point, but we have also increased the headroom in the mixer and significantly extended the range of Multidrive, giving the Subsequent 37 CV expanded sonic capability and modular control." - Cyril Lance, Moog Chief Engineer

In addition to the sound engine augmentation, each SUBSEQUENT 37 comes with an upgraded keybed for improved playability, a high-powered headphone amplifier strong enough to drive the most demanding headphones, and a software plugin/editor for both Windows and Mac platforms.

Specifications

Sound engine: Analogue
Polyphony: Selectable monophonic or paraphonic (can be poly-chained)
Keybed: 37 note semi-weighted with after pressure
LCD: 128 x 64 pixel LCD with white backlight
Controllers: Pitch bend, mod wheel, after pressure, velocity
Sound sources: 2 variable waveshape oscillators, 1 square wave sub oscillator, 1 analogue noise generator, 1 external input/filter feedback
Oscillator calibration range: 22hz-6.8khz. Note range at 8' = 18 - 116
Glide module: Assign to osc1/osc2/both. Type - LCR, LCT, EXP, gated, legato

Notes: This is a special one. Seven-voice, four-part multitimbral analogue goodness from this boutique Argentinian brand. Stunning sound and depth, combining vintage fatness with contemporary precision.

Supplier's Notes:
The GS e7 is a subtractive synthesis polyphonic analogue synthesizer. The sound generation is carried out in a total analogue way. Each voice has two voltage controlled oscillators (VCO), a noise source, a mixer, a voltage controlled filter (VCF) and a voltage controlled amplifier (VCA). The control signals are digitally generated by a microcontroller, which is capable of processing three low frequency oscillators (LFO) and two envelopes (EG) of the ADSR type. In addition, it incorporates an effects processor with chorus and delay.

The GS e7 interface was designed to be simple and intuitive.

It also has MIDI connections, USB, balanced stereo audio outputs, headphone output and CV inputs.

*** Please note: This synthesiser comes with a US type A mains lead with UK plug adapter. ***

Specs

Polyphony: 7
Multitimbral: 4 parts
Oscillators: 2 voltage controlled analog oscillators (VCO) with sub-oscillators. Hard sync.
Oscillator Waveforms: Triangular, Saw-Tri, Sawtooth, Pulse with PWM. It is possible to mix the pulse with the other waveforms.
Filter (VCF): 24dB / Oct low pass filter (4 poles) with resonance control.
Envelopes: 2 (Attack, Decay, Sustain, Release), Velocity to Attack
LFO: 3
LFO waveforms: Triangular, Ascending ramp, Descending ramp, Square, Sample and Hold
Effects: Chorus, Delay
Presets: 512 programmes, 128 multi
Conennections: MIDI IN, MIDI OUT, MIDI Thru, USB, Pitch CV, Cutoff CV, Gain CV, Ext input, Audio Out (L/Mono, R, 1/4" TRS balanced), Headphones
Power supply: DC 12V 3A
Dimensions: 520mm x 190mm x 108mm
Dimensions (with packaging): 620mm x 290mm x 230mm
Weight: 4.6 kg (estimated)

Notes: This is a special one. Seven-voice, four-part multitimbral analogue goodness from this boutique Argentinian brand. Stunning sound and depth, combining vintage fatness with contemporary precision.

Supplier's Notes:
The GS e7 is a subtractive synthesis polyphonic analogue synthesizer. The sound generation is carried out in a total analogue way. Each voice has two voltage controlled oscillators (VCO), a noise source, a mixer, a voltage controlled filter (VCF) and a voltage controlled amplifier (VCA). The control signals are digitally generated by a microcontroller, which is capable of processing three low frequency oscillators (LFO) and two envelopes (EG) of the ADSR type. In addition, it incorporates an effects processor with chorus and delay.

The GS e7 interface was designed to be simple and intuitive.

It also has MIDI connections, USB, balanced stereo audio outputs, headphone output and CV inputs.

*** Please note: This synthesiser comes with a US type A mains lead with UK plug adapter. ***

Signal path

The signal path is completely analog, featuring two VCO per voice, a white noise source, a mixer, a 4-pole low pass VCF and a VCA. The control voltages are digitally generated, including 3 LFO, 2 ADSR-type envelope generators. Finally, it has a stereo digital effects processor with Delay and Chorus. LFO 1, LFO2 and the delay can be synced with the MIDI clock using a user selectable subdivision.

Oscillators

It features two VCO plus sub oscillator per voice. Each oscillator has 3 different waveforms: triangle, sawtooth and saw-tri (triangle+sawtooth). There is a fine-tuning adjustment and a transpose option, allowing tune adjustment up to +/- 2 octaves. Tuning can also be modulated with any of the three LFOs and EG1

Furthermore, each oscillator has a pulse wave that can be turned on or off, which is mixed with the other waveforms. Its pulse width can be modulated with LFO1 and/or EG1.

Oscillators can be hard synced, with oscillator 1 being the master and oscillator 2 the slave.

The autotuning algorithm takes about 2 seconds to complete. All the voices are tuned in parallel, making a lot faster than usual.

Mixer

The mixer can control the levels and mix the two oscillators, the suboscillators and the white noise or the external input (when the external input is connected, the white noise is disabled).

Filter

The filter is a 4-pole ladder-type low-pass filter with resonance control. It can be modulated with EG1, this modulation an also be affected by velocity. It can also be modulated with any of the 3 LFOs. On the other hand, it features keyboard tracking and it can be controlled by the modulation wheel or aftertouch.

Chorus

There are two types of chorus available: basic and ensemble. The Basic algorithm is subtle and allows you to add some spatiality tothe resulting sound, while the Ensemble algorithm adds a different dimension to the sound, simulating a string or vocal ensemble. The Basic algorithm uses two delay lines, while the Ensemble uses 4 delay lines. Each delay line has its own internal LFO. There are controls for rate, depth and mix.

Delay

The delay can be a stereo delay or a ping pong delay, with its maximum delay time being as long as 1.35s. It is possible to sync the delay to the MIDI clock too. If the delay is synced, the delay time knob controls the time division instead of the delay time. There are controls for the feedback and mix too.

LFOs

There are three LFOs available. LFO 1 and 2 have 5 waveshapes: triangle, ramp up, ramp down, square and random with sample and hold. LFO 3 has the first 4 waveforms and is activated with the modulation wheel and/or aftertouch.
LFO frequencies go from 0.1Hz to 100Hz. Additionally, LFO 1 and 2 have different modes:

Monophonic: The LFO is in phase for all of the voices.

Polyphonic: The LFO is generated to a slightly different frequency for all of the keys pressed. This allows an interaction of the phases, generating more complex modulations.

Keyboard Tracking (KB Tracking): The LFO frequency varies according to the note played following the chromatic scale.

Keyboard Sync (KB Sync): The LFO is restarted when a key is pressed. Each voice has its independent LFO.

Clock Sync: The frequency of the LFO is synced to the MIDI clock signal. The e7 automatically detects the BPM of the clock signal. It can be configured to generate different rhythmic figures.

Keyboard + Clock Sync: The LFO frequency will be a sub-division of the MIDI clock signal. Also, the LFO will be restarted each time a key is pressed.

Envelope generators

There are two ADSR-type envelope generators. There are controls for attack, decay, sustain and release. Attack and release can be modified by velocity and the envelope times have keyboard tracking.

Stereo

By default, the voices have a stereo panning from left to right. By adjusting the stereo spread, it is possible to set all voices to the center or set them from right to left. There is also a stereo motion option that allows this stereo spread to be adjusted by an LFO.

Presets

The synth can store up to 640 presets, 128 of them being multitimbral presets.

Multitimbral

The synth can have up to 4 multitimbral parts. Each part has its complete sound configuration, assignable MIDI channel, keyboard zone, velocity zone, transpose setting and MIDI filter. Additionally, each part can have different voice assignments and/or share some voices.
MIDI Polyphonic expression

MIDI Polyphonic expression is supported by the GS-e7. It was tested using GeoShred, allowing independent pitch control and cutoff for each voice.


Specs

Polyphony: 7
Multitimbral: 4 parts
Oscillators: 2 voltage controlled analog oscillators (VCO) with sub-oscillators. Hard sync.
Oscillator Waveforms: Triangular, Saw-Tri, Sawtooth, Pulse with PWM. It is possible to mix the pulse with the other waveforms.
Filter (VCF): 24dB / Oct low pass filter (4 poles) with resonance control.
Envelopes: 2 (Attack, Decay, Sustain, Release), Velocity to Attack
LFO: 3
LFO waveforms: Triangular, Ascending ramp, Descending ramp, Square, Sample and Hold
Effects: Chorus, Delay
Presets: 512 programmes, 128 multi
Conennections: MIDI IN, MIDI OUT, MIDI Thru, USB, Pitch CV, Cutoff CV, Gain CV, Ext input, Audio Out (L/Mono, R, 1/4" TRS balanced), Headphones
Power supply: DC 12V 3A
Dimensions: 520mm x 190mm x 108mm
Dimensions (with packaging): 620mm x 290mm x 230mm
Weight: 4.6 kg (estimated)

Notes: Future Retro's unique modern take on vector synthesis takes full advantage of an impressive hybrid synth engine. Digital oscillators, ring modulation and complex envelopes meet a multi-mode analogue filter with paraphonic capabilities. Quirky and flexible.

Supplier's Notes:
The Vectra is a unique hybrid synthesizer with a flexible architecture that allows many different forms of synthesis to be realized. It's the best of both worlds... The Vectra utilizes digital oscillators, ring modulators, noise sources, vector mixer, LFO's, complex envelopes, and modulation routings providing many capabilities that would be very difficult to produce with analogue circuitry alone. This allows for accurate tuning, repeatability of complex patches, and patch storage. The Vectra also provides a multi-mode analogue filter, VCA, and final output, as these provide the best sonic qualities.

The Vectra includes a powerful and fun sequencer and arpeggiator, with many new capabilities. Although the Vectra is a self contained instrument, MIDI can be used to interface with other devices.

The Vectra provides four oscillators, white and pink noise sources, four ring modulators, a four-channel mixer, five LFO's, six morphing envelopes, six primary multimode analogue filter types, a main analogue VCA, and numerous internal modulation routings and VCA's controlling modulation amounts.

It really is like having a powerful self-contained semi-modular synthesizer with approximately 500 internal signal routings, and around 256 storable sound parameters.

The synthesizer architecture is designed to allow the greatest flexibility in recreating multiple synthesis techniques of the past while introducing several new innovations. The sound section has been inspired by features of the greatest synthesizers ever made, while not focusing specifically on recreating any instrument in particular. The Vectra is in fact it's own unique self-contained instrument.

The oscillators are digital as this provides the highest degree of tuning stability, while allowing both virtual analogue and digital waveform generations. With features like oscillator Sync, PWM, the new waveform Phase Slice, and Fade features, independent glide times per oscillator, constant beat detuning, and paraphonic voice modes, not to mention FM, AM, ring-modulation, and dedicated LFO's, envelopes, and VCA's per oscillator really make these oscillators a power house.

The four-channel mixer is unique in that it provides an even balance when mixing multiple sources, either manually with the joystick, or applying automated vector mixing, or mixer modulation.


OSCILLATORS (1-4)
Frequency Range: <0.01 Hz to 20.00 kHz
Analogue Modelled Waveforms: Sine, Triangle, Sawtooth, Square, Pulse Width Modulated
Pulse Width Range: 1% to 99%
Pulse Width Modulation Sources: Random1/2, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y,
LFO, Envelope
Digital Waveforms: 500
Number of Digital Waveforms per Oscillator: 2
Waveform Modulation Types: PWM, Slice, Fade
Waveform Start: 0 to 255 samples
Waveform Modulation Sources: Random1/2, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y,
LFO, Envelope
Waveform Modulation Amount: 0 to 100
Octave Range: -7 to +5
Pitch Tuning: Semitones
Fine Tuning: 128 steps per semitone
Constant Beat Detuning: -/+5.00Hz
Paraphonic Modes: 8 total
Sync: Off/On, 0-360 degrees
Glide Time per Oscillator: 0ms to 14.7 seconds
Key Tracking: On/Off

OSCILLATOR FREQUENCY MODULATION (1-4)
Modulation 1 Source: LFO
Modulation 1 Control: Off, Random1/2, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y, LFO,
Envelope
Modulation 2 Source: Envelope
Modulation 2 Control: Off, Randon1/2, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y, LFO,
Envelope

Modulation 3: Randon1/2, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y, Filter LFO, Filter Envelope, Amplifier Envelope

Total Modulation Range: 0.5 to 10 octaves
Individual Modulation Amounts: -99 to 100

LFO (1-4, Filter)
Analog Modelled Waveforms: Sine, Triangle, Ramp, Sawtooth, Square, Random
Digital Waveforms: 500
Waveform Start: 0 to 255 samples
Initial Frequency Range: 0.001 to 1001Hz (greater with key tracking and modulations)
Fine Tuning: 128 steps per semitone
Key Tracking: On/Off
Sync: Off/On, 0-360 degrees
Frequency Modulation Sources: Random1/2, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y,
LFO, Envelope, Filter LFO
Total Modulation Range: 1 to 10 octaves
Modulation Amount: -99 to 100

41

ENVELOPES (1-4, Filter, Amplifier)
Initial Envelope Stages: Delay, Attack, Hold, Decay, Sustain, Release, Repeat/Loop
Modulated Envelope Stages: Delay, Attack, Hold, Decay, Sustain, Release, Repeat/Loop
Normal Envelope Contours: 5
One-Shot Envelope Contours: 4
Looping: On/Off with repeat time
Envelope Times per Stage: 0ms to 14.7 seconds
Sustain Level: 0 to 100%
Key Sync: on/off (retriggering)
Attack Reset: Off/On
Time Modulation Sources: Off, Random1, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y

MIXER
Channels: 4
Audio Sources:
Oscillator (1-4)
Oscillator (1-4) controlled by Envelope (1-4)
Oscillator (1-4) controlled by LFO (1-4)
Ring-Modulation of Osc 1&2, Osc 2&3, Osc 3&4, Osc 4&1
White-Noise
White-Noise controlled by Envelope (1-4)
Pink-Noise
Pink-Noise controlled by Envelope (1-4)
Mixer Types: Manual, Envelope, One-Shot, Key-Synced, Free-Running, Modulated
Automix X:Y Location Stages: 4
Automix Stage Times: 0ms to 14.7 seconds
Mod Mix X:Y Location Stages: 2
Mod Mix Control Sources: Off, Random1/2, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y,
LFO, Envelope
Mod Mix Sources: Random1/2, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y, LFO, Envelope,
Filter Envelope
Mod Mix Amount: 0 to 100
Output Gain: 1.00x to 5.00x

ANALOG FILTER
Primary Filter Types: 4p low-pass, 2p low-pass, 1p low-pass, 2p band-pass, 2p high-pass, 2p notch
Filter Frequency Range: approximately 20 Hz to 20 kHz
Resonance: 0 to 100
Key Tracking: Off/On
Modulation 1 Source: LFO
Modulation 1 Control: Off, Random1/2, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y, LFO-4,
Filter Envelope
Modulation 2 Source: Envelope
Modulation 2 Control: Off, Randon1/2, Key1/2, Velocity, Aftertouch, Mod-Wheel, Stick X/Y, LFO-4,
Envelope-4
Modulation 3: Randon1/2, Key1, Velocity, Aftertouch, Mod-Wheel, Stick X/Y, DC+, Mix-1, Mix-2,
Mix-3, Mix-4, LFO-1, Env-1, Amplifier Envelope
Individual Modulation Amounts: -99 to 100
42

ANALOGUE AMPLIFIER (see also Envelope parameters)
Additional Envelope Type: Drone

Envelope Amplitude Modulation Control: Off, Random1/2, Key1/2, Velocity, Aftertouch, Mod-
Wheel, Stick X/Y, LFO-4, Envelope-4

KEYBOARD / SEQUENCER
Keys: 29
Scales: 29
Linear Transpose: -12 to +16
Scale Transpose: -12 to +16 notes
Octave Reiterations: -3 to +3
Tempo: 10 to 250 BPM
Swing: 50% to 75%
Sequencer Modes: Play, Arpeggiate, Fill, Edit, Real-time, Auto
Max Steps per Sequence: 16
Sequencer Parts: Pitch, Velocity, Rhythm (Note-On/Off, Glide, Sustain)
Time Signatures: 1-4, 2-4, 3-4, 4-4, 6-4, 8-4
Directions: Down, Up/Down, Up, Random, (plus 25 complex directions)
Loop Point: 1 to 16 steps

MEMORY
Max Number of Sounds and Sequences: 999
Global Parameters Saved: Output level, MIDI Channel, Fine Tuning, Screen Saver Time, Last File

MIDI
Channels: 1-16
MIDI Messages Supported: Note-Pitch, Note-On/Off, Velocity, Aftertouch, Pitch-Bend, Mod-Wheel,
MIDI Sync: Clock, Start, Stop

OTHER
Input/output: 15V DC input, MIDI (IN/THRU/OUT), 1/4" unbalanced Audio Out
Unit Dimensions: (width) 18.25" x (depth) 11.0" x (height) 3.5"
Unit Weight: 5.0 lbs
Power: 15V DC (centre-pin positive) rated at 1 Amp current.

Notes: The top dog of the Hydrasynth range, featuring a dual synth engine offering 16 voices (double the standard model) and a larger six-octave keyboard. Serious synth power with great wavetable sound.

*** New 2.0 Firmware update for all Hydrasynth models - March 2023 ***

This is a free of charge update for all current and new users of Hydrasynth. The biggest news in this update includes:
Expanded memory to 8 banks (Keyboard, Desktop, and Explorer only)
NEW modulation source: VOICE MODULATOR
OSC Bit reducer
LFO quantizer
ENV quantizer
LFO Step Advance
Global FX bypass
Increased Vibrato resolution
New Sustain pedal options including Sostenuto
More LED options
Glissando in glide options
Arp Range goes to 6 octaves
Arp Step Offset parameter
More Rand/Init shortcuts (all STEP LFO steps, Wavescan waves, Voice mod offsets)
Local On/Off saved
......And more!
This is the first major update to the Hydrasynth family in a little, which adds a tonne of new features.


Supplier's Notes:
The ASM Hydrasynth Deluxe is the new flagship Hydrasynth. Offering a dual-engine setup with a total of 16 voices plus an all new 73-note keybed featuring ASM's much sought after PolyTouchr polyphonic aftertouch functionality, clearly in a class of its own. With essentially two Hydrasynths in one instrument, KeySplit and Dual voice mode patches with 8 independent voices each are possible. You also have separate balanced stereo audio outputs for each of the two parts. The easily accessible 4 octave ribbon controller adds for truly expressive playing. The Hydrasynth Deluxe of course offers CV/GATE I/O for interfacing to modular and other voltage controlled synths. There's a ton of potential for sound creation, using ASM's WaveScan oscillators together with the Mutator waveshaping section and user configurable filters. A plethora of LFO's and Envelope's plus Insert and Master Effects makes this a dream sound creation tool and quite possibly the ultimate synthesizer and controller combo for your rig.

Tech Specs

Type: Polyphonic Wave Morphing Synthesizer
Sound Engine Type(s): Wavescan
Analog/Digital: Digital
Number of Keys: 73
Type of Keys: ASM POLYTOUCH Polyphonic Aftertouch Keyboard, On/Off Velocity-sensitive
Other Controllers: Ribbon Controller, Pitch Bend, Mod Wheel
Polyphony: 16 voices (Full/Layer/Split)
Number of Presets: 1024 Single Programs, 1280 Programs in Multi (Upper/Lower)
Number of Multis: 640 Programs
Oscillators: 3 x Wavescan oscillators (219 Waveforms), 4 x Mutator wave shapers (8 Types), Noise (7 Types)
Mutators: 8 Types (FM-Lin, WaveStack, PW-Orig, PW-Squeeze, PW-ASM, Harmonic Sweep, Hard Sync, PhazDiff)
Noise: 7 Types (White, Pink, Brown, Red, Blue, Violet, Grey)
LFO: 5 per Voice (Sine, Triangle, Saw Up, Saw Down, Square, Pulse27%, Pulse13%, S&H, Noise, Random, Step), Tempo syncable, Semitone Lock
Envelopes: 5 per voice, Tempo syncable, Variable trigger sources
Filter Types: 1 Multimode Filter (16 types) and 1 Variable LP-BP/Notch-HP filter, series or parallel routing
Filters: Filter 1 (LP Ldr12, LP Ldr24, LP Fat12, LP Fat24, LP Gate, LP MS20, HP MS20, LP 3-Ler, BP 3-Ler, HP 3-Ler, LP Stn12, BP Stn12, HP Stn12, LP 1 Pole, LP 8 Pole, Vowel), Filter 2 (LP-BP-HP, LP-Notch-HP)
Effects: 9 Insert Effects, 5 Delays, 4 Reverbs
Effects Types: Chorus, Flanger, Rotary, Phaser, Lo-Fi, Tremolo, EQ, Compressor, Distortion, Delay, Reverb
Arpeggiator: 8 types (Up, Down, Up&Down, Up/Down, Order, Random, Chord, Phrase)
Other: Mod Matrix (32 slots), Macro Controllers (8), Favorites (32), Randomizer (Patch and Module), MPE Compatibility, Warm Mode, Microtuning
Audio Outputs: 4 x 1/4" Balanced (L/Mono Upper, R Upper, L Lower, R Lower)
Headphones: 1 x 1/4", 1 x 1/8", Separate volume control
USB: 1 x Type B
MIDI I/O: In/Out/Thru
Pedal Inputs: 2 x 1/4" (expression, sustain)
Other I/O: 2 x 1/8" Inputs (Mod 1, Mod2), 5 x 1/8" Outputs (CV, Gate, Mod1, Mod2, Clock)
Power Supply: 12V DC switchable power supply
Additional: Utility shelf
Height: 3.62" / 9.2cm
Width: 44.45" / 112.9cm
Depth: 13.62" / 34.6cm
Weight: 29.33lbs / 13.3kg
MPN: HSLX

Notes: *** Osmose 2.0 Firmware Update- August 2024 ***

What's New in Osmose 2.0?

Here's a quick overview of the new features:

Press Glide in External MIDI Mode
MPE Arpeggiator in External MIDI Mode
Preset Favourites & Playlists
2048 Preset Slots
Preset & Playlist Changes via Program Changes
New Soundbank Management System
and more!


Next-gen standalone expressive synthesizer. Add emotion & movement to your music with a simple touch.

Osmose is the new standard for musical expressivity. Use intuitive gestures to control this standalone synthesizer and upgrade your playing & production skills. Press, bend, shake, strum & more to interact with keyboards & electronic sounds in a new organic way. Whether you're a veteran keyboardist, a workflow-oriented producer, a daring sound designer, or anything in between, Osmose will take your musical journey to uncharted places.

Explore new ways to play

Behind the expressivity of Osmose lies a few natural gestures you already know well. Discover how they interact with Osmose and enhance your musicianship from the very first touch.

Design & build quality

Designed in France to stand the test of time and touring with style, Osmose is made of quality components and boasts a high repairability index.

A sound engine by Haken Audio

Made for expressivity by Haken Audio, the EaganMatrix sound engine is at home with FM, virtual analogue, and physical modeling synthesis, as well as everything in-between.

Fun to play

Easy-to-tweak presets, a playful interface, and an innovative keybed make for a fun & refreshing playing experience, for players of all levels.

Osmose's browser has been tailored to make it a hassle-free experience. It offers various filters and sub-filters based on both sound types and colours so you can find the sounds in your head quickly.

Main features:

49 Key MPE keyboard with polyphonic aftertouch
Full-size keys with 3-dimension MPE control
EaganMatrix sound engine by Haken Audio: a digital modular sandbox allowing subtractive, FM and different physical modeling synthesis
24 voices of polyphony
Assignable mod and pitch sliders
500 factory presets
128 user presets
Configuration modes: standalone synthesizer, MPE MIDI Controller, and classic MIDI Controller
Filters and sub-filters for browsing
Customisable sensitivity and velocity curves
Multi-mode MPE arpeggiator and innovative pressure glide feature
Digital stereo effects: select between reverb , mod delay, swept echo,analog echo or LPF and HPF delay
Large colour display
9 push encoders
2 Line outputs: Two 14" TS pseudo balanced line outputs
MIDI input, output, and MIDI-thru
USB MIDI
Separated 1/4" TRS headphone output on the front panel (with its dedicated volume knob)
2 continuous pedal inputs assignable to macro or sustain: 6.35 mm Jack
Power: External PSU with lockable connector, 12V, 1.5A, center positive
Dimensions (W x H x D): 894 x 316 x 87.5 mm / 35.2" x 12.4" x 3.4"
Weight: 8.3 kg / 18.4 lbs
Includes a software updater for new firmware and library versions
Includes a Mac/PC editor to create and edit sound

Notes: Updated version of the ground-breaking synth, sampler and sequencer. Better than ever, with legendary sound quality and portability.

Supplier's Notes:
The beauty of evolution.

Louder, thinner and 100 times better.

Introducing the all new OP-1 field. Injected with more than a decade of ideas, refinements and improvements. Just to mention a few: stereo throughout the whole signal chain, Bluetooth MIDI, USB type-C, a new speaker system with a passive driver for detailed, fat and loud sound, a massive 24 hour battery life, multiple tapes and recording formats, new great sounding reverb and the 'dimension' synth engine, an all glass, flush, high resolution display. The graphics have also been meticulously reworked, screen by screen.

Reworked, refined, reborn.

Think of OP-1 field as the natural continuation of its predecessor. Updated with the latest technology, improved design and finely tuned with professional musicians, recording artists and sound designers in mind. Higher quality in all aspects, from its circuitry to connectivity and flexibility, it's tailor made for professionals in the field.

The new stereo sample engine is just one of the features that takes the OP-1 field to a higher level. With increased sampling time up to 20 seconds and dual layer mode for instant mixing of the a and b channels or via an assigned LFO.

Four new recording formats: Studio 4-track, vintage 4-track, porta and disc mini.
All with their own unique characteristics and graphics. Now with multiple tapes or discs, up to 8 in total.

If it feels thinner, it is.

By lowering the aluminium body around the keyboard, the new OP-1 field feels lighter, thinner and more precise. with 2k moulding Teenage Engineering have also managed to fit a dual 2.4 GHz antenna system inside the aluminium body.

The back is warm, velcro and bass.

Two soft velcro rings have been added on the back for fastening covers and accessories. Perhaps you want to stick your op-1 field on top of your full size keyboard, or slap it on a guitar? Use the included adhesive looped back and start experimenting. On the right you'll find an additional passive loudspeaker for hugely improved bass. And for a 'no-more-cold-metal-on-your-lap' experience, the aluminium body has been folded in a warm, soft touch, hard cover.

The first accessory out using the velcro rings is the Bill Amberg leather wrap that attaches to the back and wraps around the op-1 field and locks around the encoders.

Dimensions: 28.8 cm x 10.2 cm x 2.9 cm

Notes: The premium version of Korg's excellent Wavestate gets the Platinum look in this limited-edition model. 61-note keyboard, metal chassis and limited-edition Platinum finish.

Supplier's Notes:
Wavestate SE Platinum

The ultimate Wavestate, the limited edition Wavestate SE Platinum features a stunning premium silver aluminium panel and stainless steel side panels.

Wavestate SE is the powerful evolution of Korg's legendary Wavestation, taking Wave Sequencing to a new level. Designed in California and built in Japan, Wavestate SE includes a premium 61-note keyboard with aftertouch, in an all-metal chassis.

Built for a new era of musicians, composers, and producers, Wavestate SE features hundreds of dynamic sounds, extensive hands-on control and 120 notes of stereo polyphony to inspire new levels of creativity.

A sonic evolution

Wavestate SE is the powerful evolution of Korg's legendary Wavestation, taking Wave Sequencing to a new level. Designed in California and built in Japan, Wavestate SE includes a premium 61-note keyboard with aftertouch, in an all-metal chassis. Built for a new era of musicians, composers, and producers, Wavestate SE features hundreds of dynamic sounds, extensive hands-on control and 120 notes (stereo) of polyphony to inspire new levels of creativity.

Premium, expressive touch

Featuring a 61-key natural-touch keyboard, Wavestate SE feels incredible to play. The inclusion of aftertouch gives fingertip control of the unique constantly changing sound. All factory presets have been meticulously programmed to take full advantage of this expressive control.

Beauty meets brawn

Wavestate SE's all-metal design is as hard-wearing as it is beautiful - with a matte-black aluminium panel complimented perfectly by glossblack stainless-steel sides. The premium finish continues to the controls themselves, where metal-plated knobs are perfectly weighted and add a luxurious touch.

Easily expressive. Exceptionally deep.

The Wavestate SE puts filters, envelopes, LFOs, effects and more at your fingertips with dedicated front-panel controls. Eight programmable Mod knobs are customised to bring out the most in every sound, for real-time performance and also when saving results as new patches. Pitch bend and modulation wheels, and the unique Vector Joystick, give you instant access to multiple dimensions of real-time expression. Digging deeper, almost all front-panel knobs, and most on-screen parameters, can be modulated. You can even modulate settings for individual Wave Sequence steps! Mod Processors let you transform modulation signals using quantization, smoothing, curvature, and more.

Gigabytes of samples

Totalling in the gigabytes, Wavestate SE's sample library is vast. At a thousand times larger than that of the original Wavestation, the amount of great-sounding raw material for Wave Sequences is astounding.

Three of the key sound designers from the original Wavestation, John Bowen, John "Skippy" Lehmkuhl (Plugin Guru), and Peter "Ski" Schwartz, joined Belgian artist Airwave and the renowned Korg voicing team to create the incredible Wavestate SE sound library.

Powerful effects

An arsenal of superb effects ensures Wavestate SE delivers production-ready sounds. Each performance has a master reverb and parametric EQ while each layer has three dedicated effects. Alongside compressors, EQs, choruses, flangers, phasers, and stereo delays, you'll find distinctive processors such as the Wave Shaper, Talking Modulator, Reverse Delay, Multiband Mod Delay, and Overb, plus modelled effects including Vox guitar amps and wah pedal, multi-head tape echo, and a collection of other classic guitar pedals.

Multiply by four

Take all that power, and quadruple it! You can layer up to four Programs together in a Performance-each with their own effects and arpeggiator. The Vector Envelope and Joystick mix the individual voices of the four layers, and can also modulate any other parameters. This sheer sonic power is further enhanced with 120 notes (stereo) of polyphony. Set Lists offer effortless organisation of your Performances, and deliver instant access at the gig or in rehearsal. And thanks to Smooth Sound Transitions, previously-played voices and effects continue to ring out naturally, even when a new sound has been selected.

Deep connectivity

Connect to recording or monitoring systems with balanced stereo outputs, and a stereo headphone output is provided for private playing or onstage cueing. Din-style MIDI jacks ensure connection to other MIDI-equipped instruments and audio gear. The Wavestate SE supports class-compliant USB MIDI connections to Windows and Mac computers, and the Wavestate SE Editor/Librarian and Sample Builder programs are available as free downloads from Korg.

Wave Sequencing 2.0

The original Wavestation gave each step of a wave sequence a duration, a sample and a pitch. This created ear-catching repetitive patterns, giving rise to entirely new approaches to sound design. But what if the sounds could evolve in organic and unexpected ways, instead of just repeating? Wave Sequencing 2.0 separates the timing, the sequence of samples, and the melody, so that each can be manipulated independently. It also adds new characteristics, including shapes, gate times, and step sequencer values. Each of these is a "Lane", and each Lane can have a different number of steps, start, end and loop points. Every time the sequence moves forward, the individual Lanes combine to create the output. For instance, a sample may be matched with a different duration, pitch, shape, gate length, and step sequence value every time that it plays. You can modulate each Lane's start, end, and loop points separately for every note, using velocity, LFOs, envelopes, Mod Knobs, or other controllers. Each note in a chord can be playing something different! Lanes can also randomise the step order every time they play, with real-time control over the range of included steps, and individual steps can be randomly skipped (with a modulatable probability from 0 to 100%). The result is organic, ever-changing sounds that respond to your control. The four onboard arpeggiators can interact with Wave Sequences for even more possibilities.

Specifications

Keyboard: 61 keys (Natural touch keyboard with velocity and release-velocity
sensitive, aftertouch)
Sound generation: Wave Sequencing 2.0
Polyphony: 120 stereo voices
Sounds: 261 Performances, 799 Programs, and 1,042 Wave Sequences. Storage for tens of thousands of user Performances
Performance: 4 Layers, Reverb, EQ; all edits are stored in the Performance, DAW-style (saving as separate Programs, Wave Sequences etc. is supported but not required)
Layer: Program, Arpeggiator, Key and Velocity Zones
Program: Wave Sequence, Filter, Amp, Pre FX, Mod FX, Delay
Filters: 2-pole LPF, 2-pole HPF, 2-pole BPF, 2-pole Band Reject, 4-pole LPF, 4-pole HPF, 4-pole BPF, 4-pole Band Reject, Multi Filter, MS-20 LPF, MS-20 HPF, Polysix
Controllers: Mod Wheel, Pitch Wheel, Vector Joystick X/Y, 8x
Program/Performance Mod Knobs

Inputs/outputs: Headphone (6.3 mm stereo phone jack) OUTPUT L/MONO and R (impedance balanced 6.3 mm TRS phone jacks)
DAMPER (6.3 mm phone jack)
MIDI IN and OUT connectors
USB B port

Power supply: AC adapter (DC12V, 2500mA)
Consumption: 5W
Dimensions: 1,014 x 344 x 108 mm
Weight: 8.6 kg

Included items

AC adapter, hard case, t-shirt, stickers

Notes: An excellent combination of West Coast and East Coast synth philosophies, the Implexus features a complex wave generator and wave folder, analogue low-pass filter and sinkable LFOs and stereo delay.

Supplier's Notes:
The IMPLEXUS is a hardware desktop synthesizer combining west - and east-coast synthesis techniques into a single formfactor. The IMPLEXUS uses analogue waveshaping, folding and audio rate modulation to create a immense range of sounds and textures!

The IMPLEXUS is a performance-oriented musical instrument which will inspire you to compose music and explore its unique soundscape. The IMPLEXUS has a carefully designed analogue signal path with many unique ways to create intriguing sounds. The many sound shaping methods and modulation possibilities help you to create west-coast style harmonically rich sounds as well as thick east-coast analogue sounds.

The IMPLEXUS has a powerful "one-knob-per-function" interface with graphical feedback, utilizing LED rings to indicate modulators. The drone mode, tap tempo and looping envelopes let you explore the IMPLEXUS as a standalone sound generator. The MIDI and Eurorack compatibility and clock synchronisation options make sure it can be played in every setting. The IMPLEXUS is built to last. It has metal shaft potentiometers, an aluminium casing with scratch and solvent resistant graphics and an internal power supply (no adapter!). The IMPLEXUS is a characteristic, unique and complete musical instrument.

"West-Coast"

The characteristic sound of the IMPLEXUS comes from shaping and folding a sinewave, resulting in a complex waveform. The shaping and folding can be modulated at audio-rate in a single knob turn utilizing the second generator. Instead of subtracting you will be adding harmonics. After tweaking for a while you will be surprised to find out you didn't touch the filter... yet.

Unique filter design

The IMPLEXUS offers a 12dB/oct VCF with a unique analogue topology. This filter offers a lowpass and highpass mode. For cutoff modulation there is an envelope amount control with polarizer and a CV input on the back of the IMPLEXUS. There is an input mixer that has amplitude control over three inputs: complex generator, basic generator and the sub-oscillator.

Syncable delay

The IMPLEXUS has a stereo digital delay with dry/wet, delay-time and feedback control. There is a subtle modulation difference between the left and right channels to create a wide stereo image.
The delay can be synchronized to MIDI and external (modular) clock sources. Also the delay can be synchronized to Tap Tempo. For clock synchronization there are five divisions: 1/1 3/4 1/2 1/3 1/4.

Global pitch controls

The IMPLEXUS has a global pitch control section offering control over glide rate and pitch envelope amount. There is a dedicated vibrato LFO with manual control over amount and frequency.

Syncable LFO's

The IMPLEXUS has two LFO's with a variety of waveforms and multiple modulation destinations. The LFO's offer a wide range of 0.01 - 100Hz and can be BPM synced to MIDI and external clock. The LFO's can also be synchronized to Tap Tempo and can even be set in five different divisions.

Connections

The IMPLEXUS offers a 1/4" stereo balanced output. In addition to that there is a stereo headphone output with dedicated volume control.
There is standard MIDI input and thru over DIN and USB. Also there is a eurorack compatible patchbay on the back. This extends the sound and modulation possibilities of the IMPLEXUS even more!

Built in VCO tuner

There is a strobe tuner with 3 LED's on board, which lets you tune both the Complex and the Basic generator to a perfect "A" within just a couple of seconds.

A unique project by a small company

Majella Audio is a small company, and because of that, Majella Audio do most of the design and development themselves. The amount of hard work and effort that went into this project is what makes the IMPLEXUS a unique piece of gear with outstanding build quality. Majella Audio have created a few "How its made" videos to give you an insight into the design and development of the IMPLEXUS, which are viewable on their web page.

Features/specifications

Generators
Analog Complex Generator consisting of a waveshaper cascaded by a wavefolder to create Complex Waveforms
Analog Basic Generator
Sub-Ocscillator one octave below Complex Generator
Dedicated octave switches with 6 octave settings
Pitch modulation sources: Envelope, Vibrato, Glide, Pitchbend, External 1V/oct (CV)
Cross modulation: Linear FM, Folding, Folder DC Bias

Filter:
Analog VCF
12dB/oct Slope
Switchable Low-pass/High-pass
Mod Envelope to Cutoff with attenuverter
External CV for Cutoff
3x audio input from the Generators

2x LFO section:
Accurate digital waveform generation
5 waveform shapes: Random, Square, Sine, Ramp, Saw
Syncable from all clocking sources or "Free" running
Frequency range: 0.01 Hz-100 Hz
Clock divider options: 1/4 | 3/16 | 1/8 | 1/3 | 1/16
Destinations options LFO 1: Bias, Folder, Harmonics,
Destinations options LFO 2: Bias, Folder

2x Analog Envelope Generators:
1x Modulation EG and 1x Amplitude EG
Attack, Decay, Sustain, Release controls
Velocity amount per Envelope
MOD EG is Loopable as AD-LFO triggered by gate
MOD EG Destinations: Filter Cutoff, Harmonics, Folding, Global pitch
AMP EG has 'DRONE" mode for instant sound generation

Delay FX:
Digital Audio Delay with Analog Dry/Wet mixing
Maximum delay time: 1 second
Syncable delay time from all clocking sources
Clock divider options: 1/4 | 3/16 | 1/8 | 1/3 | 1/16

Performance Features:
"One Knob Per Function" philosophy
LED ring indicators for visual feedback and easy understanding of CV signal routing
Guitar Style Tuner for Basic and Complex Generator making it easy to tune the IMPLEXUS
Drone mode for instant sound without any external gear necessary

Physical:
2mm thick solid aluminium casing
Graphics are underneath the anodisation layer and thus scratch and solvent resistant
Handcrafted wooden side panels made from regional oak
All metal shaft potentiometers
High quality switches and connectors (Neutrik)
Internal power supply (AC Input 100-240 VAC)
No adapters needed
Dimensions: W 345 mm x D 206 mm x H 75 mm
Weight: ca. 3kg
Serial number plate

Connectivity:
External CV inputs: Pitch (1V/oct), Gate, Velocity, Folding, Harmonics, Bias, VCF cutoff
External CV outputs: Complex generator, Basic Generator, Clock output
MIDI IN over USB
MIDI IN over DIN
MIDI thru over DIN
1/4" TRS Balanced line outputs
1/4" Dedicated stereo heaphone amp

Clocking options:
External Modular/Eurorack Clock (automatic detection)
MIDI clock via DIN or USB (automatic detection)
Tap Tempo

Global Controls:
Master Volume
Headphone Volume
MIDI Channel selection

Notes: The kind of instrument Soma Labs do so well: weird but wonderful. Based around 32 complex digital synth algorithms and 12 note velocity- and pressure-sensitive sensors, transposition techniques allow you to play the full range of a grand piano.

Supplier's Notes:
TERRA is a new SOMA Labs synth.

TERRA is a highly conceptual device. The core idea is unity of nature and technology, and a perfect balance between simplicity and versatility. Behind the extremely simple interface hides a complex polyphonic, microtonal synthesizer with a broad and flexible sound palette that ranges from classical beautiful tones to complex atonal noise, and offers smooth and fast transitions between these extremes.

The innovative keyboard design invites new playing techniques and covers the full range of a grand piano with the possibility to tune each note with an accuracy of 125 steps per semitone. To achieve this range with such a simple keyboard we designed a unique system of pitch shifting using four additional sensors. Pressing different combinations of them will result in 16 variations of keyboard transposing, including up to 3 octaves up and down, fifth, fourth, third, tone etc.

Not only do you get the full range of a grand piano in a very compact design, TERRA also offers an entirely new and different approach to playing melodies and chords.

The keyboard consists of 12-note sensors with velocity and pressure sensitivity allowing for the manual creation of slow attack and vibrato, 4 dynamic sensors for timbre modification and control, 4 pitch-shifting sensors and 2 hold sensors for holding the state of the timbre and note sensors.

Inside TERRA there is a three-axis motion sensor for creating a variety of different modulations by simple intuitive movements of your hands and body.

TERRA is digital and contains 32 complex synthesis algorithms. Each algorithm has been carefully designed to be a complete and flexible musical instrument on its own, ready for learning and playing in its own unique way. The goal is to free the musician from long exhausting programming, setting hundreds of parameters for creating one timbre, and instead putting the focus directly on music and performance and following your imagination and inspiration.

TERRA offers the best of both worlds: the direct intuitive tactile connection from acoustic instruments and the flexibility and versatility of synthesizers. TERRA inherits design principles from LYRA-8 and also contains application of the new principles that were announced for ReFLEX, exploring the future of synthesis.

TERRA has an extremely simple interface that gives you instant access to all its functions in several touches, including saving and loading the 96 presets that are stored directly on the playing sensors. TERRA has no display. Instead it shows and lets you dial all necessary data on the 6 LED-sensor triangle in the centre.

TERRA has a built-in FX processor so the stereo output is ready to use, making it a perfect stand-alone performance instrument. While the sound generation is digital, TERRA has a unique custom-built and top quality analogue part that makes it sound rich, natural, clear and powerful at the same time.

The housing of TERRA comes from a solid piece of wood, making each instrument unique and slightly different. In the photo above and in the announcement demo video you can see the prototype of the synth. The final design is in development and we intend to make several different versions.

TERRA is a sanctuary for a natural soul right in the middle of the rumbling plastic world, a ground where you can breathe in and out slowly, and hold on to your roots.

TERRA is our dream about a bright future where we will be both technologically advanced and more connected to nature, where machines and technology are not a prison for our feelings and spirit but their extension.

Synthesis algorithms: 32
Polyphony: 1-12 voices (depending on the algorithm)
Presets: 96
Pitch Shifter presets: 24
Line out: L, R TS/TRS 1/4-inch jacks / 6.35 mm jacks
Maximum line output signal: 13 V peak-to-peak
Nominal line output signal: ~1.5 V (volume 100%)
Headphone output: TRS 1/4 inch jack / 6.35 mm jacks
Headphones impedance: 6-64 ohm
CV-clock input voltage: 3-15 V
Power supply voltage: DC 12 V *
Consumption current: 0.2 A
DC jack: 5.5 x 2.1 mm, "+" in center
Dimensions: 405 x 365 x 57 mm
Weight: 2.2 kg
* TERRA comes with a high quality power supply . If it gets lost, use a high-quality modern switched-mode power supply with 12 V output voltage, at least 0.4 A maximum current, 5.5 x 2.1 mm DC jack, center "+".

What's included:

TERRA - 1 pc.
Power supply - 1 pc.
CV clock adapter (DIN5 - 3.5 mm mini-jack) - 1pc.
Short interface reference manual - 1 pc.
On-table mounting pads - 4 pcs.

Notes: It starts with a dream

We are all fans of synthesizers, their vintage sound, classic and modern at the same time, their ability to mix several timbres. We love the musical journey that transports us while listening to each new presets.

We also like guitar and bass. Standing or sitting, in your studio or on stage, playing on guitar or bass is this tremendous energy, this way in which the intensity of the playing is in total connection with the music you want to create. A sweet ballad, a melodious arpeggio, a hell of a bass line, a stratospheric lead, an awesome riff.

What if we could express all that but with a great synth sound?

The dream came true, and even more!

A modern synth played like a guitar or a bass

Elyra is played with the typical gestures of playing guitar and bass and all the energy that comes from it. You play with your whole body.

There are two strumming aera for strings, one dedicated to back and forth and another dedicated to bass and arpeggios.

Elyra is designed to be played by both right-handed and left-handed people.

You can also play it placed on a table or on your knees like a groove box.

A powerful and unique composition tool

With up to 16 voices polyphony, spread across 16 instruments/layers and with is powerful sequencer, Elyra is more than a groovebox, it is a composition tool.
You can have one instrument with 16 voices or 16 instruments with one voice and everything in between.

Because Elyra is battery powered, you can carry it anywhere with you and play for several hours.

You can play and sequence all your other instruments via MIDI port.

A sound engine is made for this instrument by Kodamo.

At the core of Elyra there is a powerful and beautiful sound engine created for by Kodamo.

It is a virtual analogue engine based on subtractive synthesis with just enough FM synthesis to offer a vast sound territory.

It has many parameters to sculpt and create a unique sound.

Electronics and wood

Elyra is made of electronics and wood.

The electronic parts are designed in France and comply with environmental standards and in particular RoHS.

The body of the instrument is made of wood. It is cut and assembled in France. The wood is only chosen from sustainable or recycled sources.

Elyra is built to last.

Raised touch buttons

All Elyra buttons are touch sensitive pads made up of a slightly raised area allowing the user to feel physical feedback.

This is capacitive sensor technology which offers an extremely fast response time of 2 ms.

There are 5 distinct areas on the main panel:

the fretboard composed of 4 * 12 pads
the strumming area separated into two types, A and B
two assignable sliders
an OLED screen with its wheel and its 8 contextual buttons

Guitar/bass mode

At first you need a double trig to play a note in Guitar or Bass mode: the hand on the fretboard selects the note to be played, and the other hand uses one of the two strumming areas.

Each one of the four strings has its own two strumming areas.

The strumming area A, is made of a long and very thin relief pad. It is ideal for playing back and forth on one or more strings.

The strumming area B, is a double pad surrounded by holes in the main layer, it allows both bass type playing and is ideal for playing arpeggios.

Elyra retains the essential subtleties of guitar playing, when a note has just been played you can also, like in guitar, slide to another note, or do a Pull-off or a Hammer-on without using the strumming area again.

You can use the slider with your thumb to bend the notes.

Elyra can be tuned according to your needs. there are basic tunings, like the first 4 strings of a guitar E, A, D, G, or any open tuning, or like a Ukulele.

You choose the root notes of each string, and the choice is specific to each track in one project.

Specifications

Fretboard: 12*4 capacitive pads (2ms latency)
Sound Engine: Virtual analogue + FM
Polyphony: 16 voices shared by all tracks
Multitimbrality: up to 16 instruments/layers
Presets: 256 factory presets
1024 user presets
16 presets per project
Oscillators: 15 waveforms including sine, triangle, saw, pulse and noise
Pitch envelope
Amp envelope ADSR + delay
FM: envelope modulator (osc 2) + feedback level
Filter: filter type : HPF, LPF
Filter slope: 2 poles -12dB/oct, 4 poles -24d B/Oct
Envelope ADSR
LFO: 2 LFOs, 5 waveform, speed depth, delay, retrig position, sync to BPM
Effects: 3 master effects with individual send by tracks
Effect 1: distortion/overdrive
Effect 2: bitcruch or chorus
Effect 3: stereo delay or reverb
Sequencer: a pattern = up to 256 steps per track, 128 patterns per project
max 999 project by SD card
Power Supply: 5v USB bus power supply
Memory: SD card

Size and Weight

Width: 435 mm - 17 - 1/8 inches
Depth: 170 mm - 6 - 11/16 inches
Height: 40 mm - 1 - 37/64 inches
Weight: 1.2 kg / 2 lbs 12,3 oz

Notes: Premium version of the excellent Opsix, Korg's contemporary take on FM synthesis. Full 61-note natural-touch keybed with aftertouch, 80-voice stereo polyphony and full metal construction.

Supplier's Notes:
The Ultimate Union of Power and Performance

opsix SE is a digital synth like no other. With a premium all-metal design, 61-keys, and aftertouch, it unlocks a new world of sonic capabilities. Building on the expansive sound engine in the original opsix, opsix SE enhances it with increased polyphony and voicing, resulting in a synthesizer created for superior performance and precise control.

The opsix Operator Mixer simplified FM synthesis for the first time, making it not just comprehensible but also controllable. With the addition of extra synthesis capabilities and programming, it offered a more efficient workflow and an even richer sound.

The opsix SE takes this even further. It is equipped with Korg's premium 61-key natural-touch keyboard, complete with aftertouch, delivering the exceptional tactile experience expected from Korg's flagship workstations. With a sleek, robust metal body, it's built for both the intensity of live gigs and the precision of studio sessions. The metallic knobs are optimally weighted for effortless adjustments. Underneath its exterior, the opsix SE boasts an incredible capacity of 80 stereo voices of polyphony.

The opsix SE arrives preloaded with hundreds of sounds enhanced for aftertouch control. Moreover, it is fully compatible with the sounds and samples from both the original opsix and the opsix Native software, including numerous high-quality libraries.

Build to play

opsix SE was born out of the desire to play this incredible synth with both hands. Equipped with KORG's premium 61-note natural-touch keyboard, the opsix SE offers the same outstanding tactile response as KORG's top-tier workstations. Aftertouch puts unparalleled control of all the exceptional opsix sounds at your fingertips. Of course, we've modernized the factory Performances for aftertouch and introduced some fresh ones to the mix as well. In fact, most of the opsix SE programs have been revised to make full use of aftertouch, extended keyboard, and polyphony.

Premium metal design

The opsix SE showcases a notable upgrade in aesthetics. A slim body, specifically designed for this instrument, features a striking brown painted aluminium control panel, paying homage to vintage machines. Together with the vivid, illuminating LEDs, it brings a vibrant energy to any stage performance. The side panels, painted in a sleek black metal, amplify the overall aesthetics for a luxurious finish.

Exclusive hard case included

The opsix SE ships in a dedicated hard case, including space for cables and a sustain pedal. Your instrument can travel protected, whether you're carrying it to a rehearsal downtown or packing it up for a tour.

Get Illuminated with the Operator Mixer

At the heart of every sound is opsix SE's Operator Mixer - a simple set of six faders and knobs that invite exploration. Each part lights up red to indicate carriers or blue for modulators. Manipulating them opens up new sound-shaping possibilities to breathe fresh life into your musical ideas. This straightforward, hands-on workflow is part of what makes opsix SE so unique, just like the sounds it offers.

Direct Hands-On Control

Whether you're tweaking a preset or building a patch from the ground up, the six data entry knobs on the right give you quick access to the parameters you need and seamlessly sync with the large OLED display, giving you a clear, focused direction to your workflow. Coupled with the mixer, it makes creating fresh sounds super easy and, most importantly, fun!

Select from a full range of analogue-style filters, from the radical Korg MS-20 low-pass/high-pass filter to the powerful yet smooth KORG Polysix low-pass filter that gives your sound a vintage feel. There are also two or four-pole low-pass, high-pass, band-pass, and band-reject filters with resonance.

There's even a built-in spectrum analyser and oscilloscope that gives you visual feedback via the screen on the music you're making.

Six in One Synthesis

The core of opsix is nothing short of exponential. Since waveforms can be arranged and modulated in nearly infinite ways, opsix can easily do the sonic work that is similar to numerous types of synthesis:

Subtractive

Removing parts of the sound to get the sound you want; the most widely-used synthesis. opsix uses up to six envelopes and multi-modeled filters to achieve many cutting-edge and classical analog synthesis tones.


Semi-Modular
Rerouting signal paths to change the sound. A spin through the Alogorithm section will dramatically reshape the sound by changing how the signal routing between the operators work together, and no patch cables are needed.


Analog (Modelling)
Analog-style controls and plenty of stackable waveforms take you from digital to analogue-sounding in no time. Enjoy deep basses, crisp leads, thick pad sounds, fuzzy brass tones, and so much more.


Waveshaping

Adding intentional distortion to the waveforms to achieve aggressive overtones that are either harmonic or inharmonic. This will help you achieve gritty, bitey tones dripping with character.


Additive

Stacking waveforms and blending their harmonics is key to an expansive range of harmonious, dissonant, and tension-driven sounds. With six operators available, the complete FM experience is possible, including the ability to go back in time for classic sounds you have heard throughout recording history.


Classic FM

Last but certainly not least, opsix's highly flexible and powerful architecture starts with true six-Operator FM. As a result, it easily delivers signature sounds you have surely heard on thousands of hits from the '80s on through today, and with far more polyphony than other standalone FM synths available today.

With all of these ways to realize and explore sounds, opsix SE is uniquely suited as a "future-modern-classic" synth!

Altered Reality

opsix SE is FM-based, but the similarities to the classic synthesis end there. The Altered FM architecture delivers sounds across a vast spectrum, far wider than any single synthesis has been able to cover before, thanks to new sound components; new waveforms, filters, shaping, effects, LFOs, envelopes, modulations, and more, all translating to its broad assortment of sounds.

Powerful Effects Processing

opsix SE provides three blocks of 30 types of high-definition effects that you can use together to enhance your sounds even further. There's everything from a great mix of usable standard effects like chorus, phaser, delay, and compressor to some world-class shimmering reverbs that will elevate your sound to the next level.

Automatable 16-step sequencer

opsix SE features an incredible step sequencer that rivals groove boxes for flexibility and power. Press the PLAY button on any sound and experience the complexity of the sequences! Every Program has its unique sequence stored with it, or create your very own.

You can record up to six notes per step and edit each note's velocity, gate time, and playback timing. Create long phrases or make subtle shifts in timing to emulate strums or drum rolls, something that's not possible on a typical 16-step sequencer. The motion sequencer of the opsix SE also lets you record changes of up to six parameters, creating smooth motion changes in sound within a phrase or building rhythms that change dramatically with each step.

Notes: Top-of-the-range take on the powerful Wavestate synth concept, based on wave sequencing with 120-note stereo polyphony, natural-touch 61-note keybed and aftertouch.

Supplier's Notes:
Wavestate SE is the powerful evolution of Korg's legendary Wavestation, taking Wave Sequencing to a new level. Designed in California and built in Japan, Wavestate SE includes a premium 61-note keyboard with aftertouch, in an all-metal chassis.

Built for a new era of musicians, composers, and producers, Wavestate SE features hundreds of dynamic sounds, extensive hands-on control and 120 notes of stereo polyphony to inspire new levels of creativity.

A sonic evolution

Wavestate SE is the powerful evolution of Korg's legendary Wavestation, taking Wave Sequencing to a new level. Designed in California and built in Japan, Wavestate SE includes a premium 61-note keyboard with aftertouch, in an all-metal chassis. Built for a new era of musicians, composers, and producers, Wavestate SE features hundreds of dynamic sounds, extensive hands-on control and 120 notes (stereo) of polyphony to inspire new levels of creativity.

Premium, expressive touch

Featuring a 61-key natural-touch keyboard, Wavestate SE feels incredible to play. The inclusion of aftertouch gives fingertip control of the unique constantly changing sound. All factory presets have been meticulously programmed to take full advantage of this expressive control.

Beauty meets brawn

Wavestate SE's all-metal design is as hard-wearing as it is beautiful - with a matte-black aluminium panel complimented perfectly by glossblack stainless-steel sides. The premium finish continues to the controls themselves, where metal-plated knobs are perfectly weighted and add a luxurious touch.

Easily expressive. Exceptionally deep.

The Wavestate SE puts filters, envelopes, LFOs, effects and more at your fingertips with dedicated front-panel controls. Eight programmable Mod knobs are customised to bring out the most in every sound, for real-time performance and also when saving results as new patches. Pitch bend and modulation wheels, and the unique Vector Joystick, give you instant access to multiple dimensions of real-time expression. Digging deeper, almost all front-panel knobs, and most on-screen parameters, can be modulated. You can even modulate settings for individual Wave Sequence steps! Mod Processors let you transform modulation signals using quantization, smoothing, curvature, and more.

Gigabytes of samples

Totalling in the gigabytes, Wavestate SE's sample library is vast. At a thousand times larger than that of the original Wavestation, the amount of great-sounding raw material for Wave Sequences is astounding.

Three of the key sound designers from the original Wavestation, John Bowen, John "Skippy" Lehmkuhl (Plugin Guru), and Peter "Ski" Schwartz, joined Belgian artist Airwave and the renowned Korg voicing team to create the incredible Wavestate SE sound library.

Powerful effects

An arsenal of superb effects ensures Wavestate SE delivers production-ready sounds. Each performance has a master reverb and parametric EQ while each layer has three dedicated effects. Alongside compressors, EQs, choruses, flangers, phasers, and stereo delays, you'll find distinctive processors such as the Wave Shaper, Talking Modulator, Reverse Delay, Multiband Mod Delay, and Overb, plus modelled effects including Vox guitar amps and wah pedal, multi-head tape echo, and a collection of other classic guitar pedals.

Multiply by four

Take all that power, and quadruple it! You can layer up to four Programs together in a Performance-each with their own effects and arpeggiator. The Vector Envelope and Joystick mix the individual voices of the four layers, and can also modulate any other parameters. This sheer sonic power is further enhanced with 120 notes (stereo) of polyphony. Set Lists offer effortless organisation of your Performances, and deliver instant access at the gig or in rehearsal. And thanks to Smooth Sound Transitions, previously-played voices and effects continue to ring out naturally, even when a new sound has been selected.

Deep connectivity

Connect to recording or monitoring systems with balanced stereo outputs, and a stereo headphone output is provided for private playing or onstage cueing. Din-style MIDI jacks ensure connection to other MIDI-equipped instruments and audio gear. The Wavestate SE supports class-compliant USB MIDI connections to Windows and Mac computers, and the Wavestate SE Editor/Librarian and Sample Builder programs are available as free downloads from Korg.

Wave Sequencing 2.0

The original Wavestation gave each step of a wave sequence a duration, a sample and a pitch. This created ear-catching repetitive patterns, giving rise to entirely new approaches to sound design. But what if the sounds could evolve in organic and unexpected ways, instead of just repeating? Wave Sequencing 2.0 separates the timing, the sequence of samples, and the melody, so that each can be manipulated independently. It also adds new characteristics, including shapes, gate times, and step sequencer values. Each of these is a "Lane", and each Lane can have a different number of steps, start, end and loop points. Every time the sequence moves forward, the individual Lanes combine to create the output. For instance, a sample may be matched with a different duration, pitch, shape, gate length, and step sequence value every time that it plays. You can modulate each Lane's start, end, and loop points separately for every note, using velocity, LFOs, envelopes, Mod Knobs, or other controllers. Each note in a chord can be playing something different! Lanes can also randomise the step order every time they play, with real-time control over the range of included steps, and individual steps can be randomly skipped (with a modulatable probability from 0 to 100%). The result is organic, ever-changing sounds that respond to your control. The four onboard arpeggiators can interact with Wave Sequences for even more possibilities.

Ultimate protection

Whether travelling to a studio or setting out on a world tour, ensure your Wavestate SE arrives safely with the included hard case. The custom design even provides space for cables and pedals.

Specifications

Keyboard: 61 keys (Natural touch keyboard with velocity and release-velocity
sensitive, aftertouch)
Sound generation: Wave Sequencing 2.0
Polyphony: 120 stereo voices
Sounds: 261 Performances, 799 Programs, and 1,042 Wave Sequences. Storage for tens of thousands of user Performances
Performance: 4 Layers, Reverb, EQ; all edits are stored in the Performance, DAW-style (saving as separate Programs, Wave Sequences etc. is supported but not required)
Layer: Program, Arpeggiator, Key and Velocity Zones
Program: Wave Sequence, Filter, Amp, Pre FX, Mod FX, Delay
Filters: 2-pole LPF, 2-pole HPF, 2-pole BPF, 2-pole Band Reject, 4-pole LPF, 4-pole HPF, 4-pole BPF, 4-pole Band Reject, Multi Filter, MS-20 LPF, MS-20 HPF, Polysix
Controllers: Mod Wheel, Pitch Wheel, Vector Joystick X/Y, 8x
Program/Performance Mod Knobs

Inputs/outputs: Headphone (6.3 mm stereo phone jack) OUTPUT L/MONO and R (impedance balanced 6.3 mm TRS phone jacks)
DAMPER (6.3 mm phone jack)
MIDI IN and OUT connectors
USB B port

Power supply: AC adapter (DC12V, 2500mA)
Consumption: 5W
Dimensions: 1,014 x 344 x 108 mm
Weight: 8.6 kg

Included items

AC adapter, hard case

Notes: 12-voice version of Waldorf's Iridium Core, a compact synth from the same range as the Quantum. Running on the Waldorf OS, the Iridium features a versatile selection of Wavetable, Multi- & Granular-Sampling, Waveform, Kernel FM and Resonator synth engines.

Supplier's Notes:
The Core

Iridium Core provides the core synthesis engine of the Quantum / Iridium platform. It is the heart of Waldorf's most advanced hardware-based synthesis. The essence of forward-looking sound. The Core.

Sonic Explorer

Iridium Core contains 5 synthesis engines: Wavetable, Multi- & Granular-Sampling, Waveform, Kernel FM and Resonator. Combined with a broad selection of digital filter and processing options Iridium Core lets you explore a huge sonic universe of electronic sound. Iridium Core's intuitive and easy graphical interface helps you to keep your flow of creativity.

Wave Traveller

The compact form factor makes Iridium Core an ideal companion to travel with you to all your sonic explorations and performances. It fits well into laptop size bags and in carry on-baggage it leaves enough space to all your other devices you need for your performances.

Driven by Inspiration

Iridium Core comes with a huge collection of more than 1700 factory presets and samples to drive your sonic Wanderlust. Get inspired what the broad and diverse array of sound designers have created to fuel your musical endeavours.

Team Player

Iridium Core integrates into various live performance and studio setups. Its connects with your modular synths, drum machines, sequencers and computers. The compact form factor fits well into your tabletop or space limited setups.

Family Member

Iridium Core shares the same software platform like Quantum, Iridium Desktop & Iridium Keyboard. All instruments are powered by the Waldorf synthesiser OS and will receive joint updates. Thus, the whole family participates from future enhancements and developments.

Specifications

Compatible with the Waldorf Quantum synth engine
Software: Waldorf Synthesis Platform OS

Oscillators
3 Oscillators each capable of 5 synthesis modes:
Wavetable
Waveform (VA)
Particle (Sampling and Granular Sampling)
Resonator
Kernels (up to 6 sub-oscillators which can be interlinked through FM, AM or Wavetable-position at audio rate)

Dual Stereo Filters per voice
True stereo path Dual Digital Filter with independent modes:
12/24dB LP/HP/BP in all combinations
Nave, Largo, PPG, Quantum and StateVariable models
Analyzer displayed in Filter view
Filter curve animation when modulated (optional)
Sophisticated filter routing options with modulatable panning and levels

Digital Former
Filter models like State Variable, Waldorf Nave, Largo and PPG in HP/LP/BP/Notch
Comb filters, Bit-Crusher, various Drives, Ring-Modulation

Modulators
6 Envelopes
6 LFO
Komplex Modulator (LFO/Envelope combination with user-definable shape and morphing)

Mod Matrix
40 slots
Fast assign mode
One additional control amount per slot
Identical Sources and Destinations can be used multiple times until the matrix is full

Effects
5 slots per layer
Various parallel and sequential routing options
Reverb, Delay, Chorus, Phaser, Flanger, Drive, EQ, Compressor, Tremolo

Performance features
Advanced Arpeggiator
Step-sequencer with up to 64 steps for notes and parameters
2x4 button pads assignable to notes or chords
4 user-assignable potentiometers
6 user-configurable macro buttons
Favourites screen for quick patch recall
XY control on touchscreen
Wheels touchscreen for MIDI controls like mod wheel, pitch bend, aftertouch and velocity
MPE capable

Screen
Industrial-grade highly responsive touch screen with Brightness control
1024x600 pixels

Voices
12 voice polyphony
Duo-timbral
Mono, Legato and Unisono modes

Patches
Over 1700 factory patches
Capacity of 7000 patch memory slots (numbers 0000-9999 can be used)
Patches from Quantum and other Iridium variants can be loaded and vice-versa
Category filter for patch list
2.6 GB sample flash memory preloaded with 2 GB factory samples

Connections
Stereo Audio Out: 2x TS jacks
Stereo Audio In: 2x TS jacks
Headphones TRS output with level control
DIN MIDI IN & Out, mini-TRS Type A (two adapters to DIN MIDI sockets included)
USB Type B (device) for MIDI connection to computer
USB Type A (host) for storage media and MIDI devices
MicroSD slot
2 high-resolution CV Inputs which can be used as modulation sources in the Mod-Matrix
Analogue clock In & Out with clock divider settings

Overall
Sturdy metal case
Dimensions: 346 mm wide by 200 mm depth by 64 mm height (including controls)
Weight: 2.2 kg
External Power Supply: Input 100-240 V / AC 50-60 Hz, Output 12 V DC / 3 A

What's In the Box?
Iridium Core Synthesizer
Two MIDI adapters: mini TRS to DIN sockets
Power Supply
Printed Quick Start Guide

Notes: The premium version of Korg's excellent Wavestate gets the Platinum look in this limited-edition model. 61-note keyboard, metal chassis and limited-edition Platinum finish.

Supplier's Notes:
Wavestate SE Platinum

The ultimate Wavestate, the limited edition Wavestate SE Platinum features a stunning premium silver aluminium panel and stainless steel side panels.

Wavestate SE is the powerful evolution of Korg's legendary Wavestation, taking Wave Sequencing to a new level. Designed in California and built in Japan, Wavestate SE includes a premium 61-note keyboard with aftertouch, in an all-metal chassis.

Built for a new era of musicians, composers, and producers, Wavestate SE features hundreds of dynamic sounds, extensive hands-on control and 120 notes of stereo polyphony to inspire new levels of creativity.

A sonic evolution

Wavestate SE is the powerful evolution of Korg's legendary Wavestation, taking Wave Sequencing to a new level. Designed in California and built in Japan, Wavestate SE includes a premium 61-note keyboard with aftertouch, in an all-metal chassis. Built for a new era of musicians, composers, and producers, Wavestate SE features hundreds of dynamic sounds, extensive hands-on control and 120 notes (stereo) of polyphony to inspire new levels of creativity.

Premium, expressive touch

Featuring a 61-key natural-touch keyboard, Wavestate SE feels incredible to play. The inclusion of aftertouch gives fingertip control of the unique constantly changing sound. All factory presets have been meticulously programmed to take full advantage of this expressive control.

Beauty meets brawn

Wavestate SE's all-metal design is as hard-wearing as it is beautiful - with a matte-black aluminium panel complimented perfectly by glossblack stainless-steel sides. The premium finish continues to the controls themselves, where metal-plated knobs are perfectly weighted and add a luxurious touch.

Easily expressive. Exceptionally deep.

The Wavestate SE puts filters, envelopes, LFOs, effects and more at your fingertips with dedicated front-panel controls. Eight programmable Mod knobs are customised to bring out the most in every sound, for real-time performance and also when saving results as new patches. Pitch bend and modulation wheels, and the unique Vector Joystick, give you instant access to multiple dimensions of real-time expression. Digging deeper, almost all front-panel knobs, and most on-screen parameters, can be modulated. You can even modulate settings for individual Wave Sequence steps! Mod Processors let you transform modulation signals using quantization, smoothing, curvature, and more.

Gigabytes of samples

Totalling in the gigabytes, Wavestate SE's sample library is vast. At a thousand times larger than that of the original Wavestation, the amount of great-sounding raw material for Wave Sequences is astounding.

Three of the key sound designers from the original Wavestation, John Bowen, John "Skippy" Lehmkuhl (Plugin Guru), and Peter "Ski" Schwartz, joined Belgian artist Airwave and the renowned Korg voicing team to create the incredible Wavestate SE sound library.

Powerful effects

An arsenal of superb effects ensures Wavestate SE delivers production-ready sounds. Each performance has a master reverb and parametric EQ while each layer has three dedicated effects. Alongside compressors, EQs, choruses, flangers, phasers, and stereo delays, you'll find distinctive processors such as the Wave Shaper, Talking Modulator, Reverse Delay, Multiband Mod Delay, and Overb, plus modelled effects including Vox guitar amps and wah pedal, multi-head tape echo, and a collection of other classic guitar pedals.

Multiply by four

Take all that power, and quadruple it! You can layer up to four Programs together in a Performance-each with their own effects and arpeggiator. The Vector Envelope and Joystick mix the individual voices of the four layers, and can also modulate any other parameters. This sheer sonic power is further enhanced with 120 notes (stereo) of polyphony. Set Lists offer effortless organisation of your Performances, and deliver instant access at the gig or in rehearsal. And thanks to Smooth Sound Transitions, previously-played voices and effects continue to ring out naturally, even when a new sound has been selected.

Deep connectivity

Connect to recording or monitoring systems with balanced stereo outputs, and a stereo headphone output is provided for private playing or onstage cueing. Din-style MIDI jacks ensure connection to other MIDI-equipped instruments and audio gear. The Wavestate SE supports class-compliant USB MIDI connections to Windows and Mac computers, and the Wavestate SE Editor/Librarian and Sample Builder programs are available as free downloads from Korg.

Wave Sequencing 2.0

The original Wavestation gave each step of a wave sequence a duration, a sample and a pitch. This created ear-catching repetitive patterns, giving rise to entirely new approaches to sound design. But what if the sounds could evolve in organic and unexpected ways, instead of just repeating? Wave Sequencing 2.0 separates the timing, the sequence of samples, and the melody, so that each can be manipulated independently. It also adds new characteristics, including shapes, gate times, and step sequencer values. Each of these is a "Lane", and each Lane can have a different number of steps, start, end and loop points. Every time the sequence moves forward, the individual Lanes combine to create the output. For instance, a sample may be matched with a different duration, pitch, shape, gate length, and step sequence value every time that it plays. You can modulate each Lane's start, end, and loop points separately for every note, using velocity, LFOs, envelopes, Mod Knobs, or other controllers. Each note in a chord can be playing something different! Lanes can also randomise the step order every time they play, with real-time control over the range of included steps, and individual steps can be randomly skipped (with a modulatable probability from 0 to 100%). The result is organic, ever-changing sounds that respond to your control. The four onboard arpeggiators can interact with Wave Sequences for even more possibilities.

Specifications

Keyboard: 61 keys (Natural touch keyboard with velocity and release-velocity
sensitive, aftertouch)
Sound generation: Wave Sequencing 2.0
Polyphony: 120 stereo voices
Sounds: 261 Performances, 799 Programs, and 1,042 Wave Sequences. Storage for tens of thousands of user Performances
Performance: 4 Layers, Reverb, EQ; all edits are stored in the Performance, DAW-style (saving as separate Programs, Wave Sequences etc. is supported but not required)
Layer: Program, Arpeggiator, Key and Velocity Zones
Program: Wave Sequence, Filter, Amp, Pre FX, Mod FX, Delay
Filters: 2-pole LPF, 2-pole HPF, 2-pole BPF, 2-pole Band Reject, 4-pole LPF, 4-pole HPF, 4-pole BPF, 4-pole Band Reject, Multi Filter, MS-20 LPF, MS-20 HPF, Polysix
Controllers: Mod Wheel, Pitch Wheel, Vector Joystick X/Y, 8x
Program/Performance Mod Knobs

Inputs/outputs: Headphone (6.3 mm stereo phone jack) OUTPUT L/MONO and R (impedance balanced 6.3 mm TRS phone jacks)
DAMPER (6.3 mm phone jack)
MIDI IN and OUT connectors
USB B port

Power supply: AC adapter (DC12V, 2500mA)
Consumption: 5W
Dimensions: 1,014 x 344 x 108 mm
Weight: 8.6 kg

Included items

AC adapter, hard case, t-shirt, stickers

Notes: A unique approach to FM synthesis in this updated version of Kodamo's ludicrously powerful EssenceFM. Up to 300 voice polyphony, hugely powerful touchscreen editing and stereo effects.

Supplier notes:
The EssenceFM is a powerful and easy to use FM synthesiser, allowing you to explore the endless soundscapes offered by FM synthesis. With a super-responsive touchscreen, assignable knobs and workflow optimized for sound design, creating rich and unique sounds is easier than on any other FM synthesiser.

The EssenceFM engine allows to create ridiculously powerful sounds made of more than 6 operators. That's why it's been given 300 voices of polyphony, you get the easy-to-program 6 op FM synthesis and the ability to layer many voices to create huge, rich-souding instruments.

There are 1800 operators and 4200 envelopes running at the same time, more than you will ever need.

This synth is the result of Kodamo's efforts to create the best user interface to interact with FM synthesis. No endless menus, no weird key combinations, no complex structure to remember. Everything is displayed on screen, every element is editable by pressing on it.It requires some trial and error to find the perfect sound, and that exploration process is fun only when the interface doesn't work against you. The EssenceFM is full of small details that makes workflow better: 1024 undo/redo steps while editing, copy/paste on every element, clear navigation using 4 modes and a breadcrumb, real-time envelope level display on the operators and much more. All that makes for a powerful and enjoyable synthesiser.

What you can do with it:
Create your own FM algorithms by drag and dropping operators on the touch screen. An almost infinite number of configurations is possible
Layer up to 128 voices per patch, each consisting of 6 operators, for incredibly rich sounds
Draw your custom waveforms on the touch screen to use them as oscillators or LFOs
Thicken the sound with the built-in effects
Take advantage of its 16 part/300 voice multi-timbrality to create full songs with it
Use it to make analog-like sounds with the built-in resonant filter
Connect it to your audio recording gear and effect modules in many different ways with the four balanced stereo outputs
Explore FM synthesis in the most convenient way possible with the Undo-Redo buttons, allowing for any action to be undone
Try microtunings, layer splits, round robin, MPE, and many other advanced features.

Package Contents:

EssenceFM synthesizer (MKII version)
Printed user manual
2x 3U 19" rack mount brackets
4x screws
Universal (100-240V) AC adapter
IEC power cable
2x rubber strip

Notes: Arturia's 25 years of experience shine through in this beautifully crafted studio and stage instrument, packing 10 of the brand's famously precise sound engines into a user-friendly, ultra-playable package.

Supplier's Notes:
AstroLab is the culmination of 25 years of passion, innovation, and commitment to the pursuit of unhindered musical exploration. From must-have performance instruments that respond to every keystroke just like the originals do, to iconic keyboards and futuristic synth textures - instantly find that perfect sound, stay in the zone and set your creative flow on a flight path beyond space and time.

For many musicians and producers who utilize a plethora of tools, instruments and custom sounds in their home or studio setup, recreating this for a live performance is not always straightforward. This is where AstroLab comes in, offering both a robust, minimalist design and workflow-focused technology that lets you integrate all your sounds effortlessly.

A universe of iconic sounds?

AstroLab comes with over 1300 onboard presets brought to life with 10 in-built sound engines, from Virtual Analog to Wavetable and Granular. Instantly access an unparalleled library of sounds as well as the ability to integrate your own - expandable through the Sound Store and companion software.

A performance keyboard you can trust

AstroLab lets you travel from the stage, to the studio, and back, without ever needing to compromise on sound quality and playability. Every aspect of AstroLab has been designed with the live musician in mind.

Produce, rehearse, perform

Focus on performance with AstroLab's simple yet powerful controls. Featuring quick sound selection, 4 multi-purpose macros, customisable FX knobs and innovative play modes to help you stay in key and inspire new ideas.

On-the-go control

Customize and organize sounds on-the-go via AstroLab's mobile app which brings the convenience of mobile technology to your performance workflow. Edit your playlists and explore new sounds with the sound store, all completely independent from your DAW or computer.

Professional software included

Fine-tune, record and curate custom sounds for AstroLab using its counterpart software, Analog Lab Pro, extending the sonic range and power of AstroLab to suit your every need.

Features

61-note semi-weighted keyboard
10 sound engines
Virtual Analog
Samples
Wavetable
FM
Granular
Physical modelling
Vector Synthesis
Harmonic
Phase distortion
Vocoder
Piano-size keys
Over 1300 in-built sounds from Arturia instruments
Up to 10.000 sounds via Arturia software
Navigation wheel & screen for easy browsing
10 Preset Buttons for quick sound access
4 macro controls for quick editing
17 insert FX & dedicated Delay/Reverb
4 dedicated knobs to control FX
Multis/Keyboard Split
MIDI i/o, audio input, and control pedal I/o
USB-C connection and USB-A host
Bluetooth audio and WiFi for wireless control
Arpeggiator, Looper, Chord & Scale modes

I/O on offer:

Stereo Audio input
Four control inputs
Stereo audio outputs
Dedicated headphone out
USB MIDI Host
USB C Connection to host computer
Locking DC power input

Included software

Make use of AstroLab's software ecosystem which enhances ease-of-use when on the road and offers greater control, customisation and an even greater range sounds:

AstroLab Connect (iOS + Android)
Analog Lab Pro
Compatible with V Collection and Pigments (not included)

Box Content

Quickstart
Registration card
USB Cable (C/A)
User Manual
Power Supply

Notes: The ARP 2600 is arguably the most iconic and recognizable synthesizer of all time. Having been used in countless records, film scores, TV shows and game soundtracks since its appearance from the 70's through to today, the ARP 2600's sound remains an essential part of the music world.

The new ARP 2600 M delivers the sound admired around the world, in a more compact and portable format and including added features that make it the ideal incarnation of this historic synth.

When the ARP 2600 FS was announced in January 2020, it quickly became a phenomenal success with musicians all over the world recognizing the faithfulness to the original ARP 2600.

The ARP 2600 M is around 60% the original size, making it lighter, more portable and easier to place and use in a studio. It integrates the same analogue circuitry and components as the ARP 2600 FS, thus faithfully reproducing the characteristic ARP sound.

The ARP 2600 M is built in Japan with the same care and extraordinary quality standard as the ARP 2600 FS, and uses the same analogue components to accurately reproduce the sound and feel of the original.

The Spring Reverb has been re-engineered and adapted to the new size body to the same lush effect.

The ARP 2600 M comes with a dedicated Carry Case that not only protects your instrument, but also makes it easier to transport, thanks to its custom casters with special anti-shock damping technology.

There is also enough space to carry other gear together, like your favourite volca, SQ-64 or MIDI controller!

It is not by chance that the ARP 2600 has been so extremely popular to this day.

More than a synthesizer, the ARP 2600 M is a complete sound design studio. Even today, the ARP 2600 stands as a bridge between the individual elements of modular synthesis and the immediacy of a production / performance instrument. Included are an ample supply of oscillators, envelopes, a filter and amplifier - all of the building blocks of analogue synthesis. But the ARP 2600 M goes even further, with a spring reverb tank and even a pair of built-in monitor speakers. Also present is much of the versatility of a vintage modular system, including a ring modulation, lag and voltage processors, an envelope follower, audio preamp, a clock-able switch, noise source, a sample-and-hold module, signal inverters, an auxiliary mixer, and even a set of parallel-wired/multi jacks.

The new ARP 2600 M is not only faithful to the original, it also includes an array of added features that will make it even easier to use:

Plug and play: Connect any class compliant MIDI controller such as a KORG microKeys, nanokeys or SQ-64 to one of the ARP 2600 M's USB ports (USB-A and USB-B) and automatically get full control of your instrument!

Resized: The new size makes it easier to visualize your patch and also allows you to use shorter patch cables

Filter Choice: Two types of filters from two versions of the original ARP 2600(4012 type, 4072 type)

More MIDI: 5-Pin DIN plug MIDI IN added

Modern Control: Pitch-bend, Modulation, Portamento ON/OFF and Portamento ON/OFF can be controlled through MIDI CC messages (USB/DIN MIDI)

Normalized voltage: The threshold of the trigger signal required to activate the ADSR through the S/H GATE JACK has been reduced from 10V to 5V, making it much easier to use in combination with other gear such as volcas or Eurorack modules

Tweaked Parameters: Improved Attack and Release time ratios

Easy Connections: L/R Stereo Output Jack (instead of XLR)

Speakers turn automatically off when using headphones- improved, smoother sliders

Celebrating the rebirth of this iconic synth, the first 1000 units will come with a special colour road case, as well as a KORG microKEY2-37 so you can start playing right away!

The ARP 2600 FS comes with a diverse variety of music software from Izotope including "Ozone Elements" which lets you not only create songs but also master them using AI, "Skoove" which will help you improve your keyboard playing skills, "Reason Lite" DAW software, as well as software synths from KORG and other brands.

In other words, the moment you get your hands on this synthesizer you'll have a variety of tools to help you take your music to the next level.
