Notes: Really smart integration of macro controls for Eurorack, based on the original design by Emblematic Systems. Assign settings to eight CV outputs then morph with the crossfader or record movements to manage presets or set up complex real-time modulation. Can also operate as Catalyst Sequencer.

Supplier's Notes:
The Catalyst Controller is a macro controller with eight precision CV outputs and a responsive crossfader to morph between scenes. A scene is a snapshot of up to eight CV outputs, like a modular preset. Traverse a "pathway" composed of multiple scenes using the crossfader or an external CV signal, or immediately jump using the scene buttons. Record CV and slider movements, and play recordings back via a button or external trigger.

Each output has sub-millivolt precision and a maximum range of -5V to +10V. Channels have an adjustable morphing curve, can be quantized to common scales, restricted to a particular voltage range, or set to output gates.

Whether used as a CV preset manager, seamless transition generator, chord sequencer, CV recorder, or experimental CV playground, the Catalyst Controller puts control of your modular at your fingertips.

The Catalyst Controller can also turn into a Catalyst Sequencer! Hold down a special button combination to change between controller and sequencer modes. If you end up liking the Sequencer more, you can even remove the double-sided faceplate, flip it over, and re-install with the Sequencer artwork visible.

Based on the original Catalyst module from Emblematic Systems.

Specifications:

Smooth, responsive crossfade morphs between scenes
Eight output channels, each can be CV or Gate
Arrange scenes into pathways of up to 64 scenes
Smooth, responsive crossfader morphs from scene to scene along the pathway
Set slew/lag to limit how fast scenes can change
Adjustable Morph time per output
Control crossfading with an external CV
Record and playback up to 20 seconds of CV and crossfader motion
CV outputs can be set to -5V to +10V maximum, or limited to +/-5V, +5V, +3V, or +1V
CV outputs can be unquantized (sub-1mV resolution), or Quantized to common scales
Randomization of channel values/gates
Copy/paste
Based on the original Catalyst from Emblematic Systems

Pairs with: 4ms Catalyst Sequencer

Notes: The Catalyst Sequencer combines a traditional clocked step-sequencer with an unconventional phase-based sequencer to produce a new paradigm in sequencing. Eight precision CV sequencer channels can be simultaneously driven by a clock, a phase CV, or scrubbed manually with the crossfader.

Each of the eight channels has its own sequence length, quantizer, transposition, clock divider, randomization, voltage range (max -5V to +10V), and selectable CV (precise 16-bit resolution) or Gate mode.

Phase-based sequencing is an advanced form of sequencing where each step is selected by CV. The Catalyst Sequencer has a smooth, responsive crossfader that scrubs the sequence, playing it forward or backwards to track your motions. Patching in a CV signal will do the same: a ramp-up CV plays the sequence forwards, a ramp-down plays it backwards, a triangle plays it ping-pong, and complex waveforms generate new interesting rhythmic and melodic patterns.

The Catalyst Sequencer can also turn into a Catalyst Controller! Hold down a special button combination to change between sequencer and macro controller modes. If you end up liking the Controller more, you can even remove the double-sided faceplate, flip it over, and re-install with the Controller artwork visible.

Based on the original Catalyst module from Emblematic Systems.

Pairs with: 4ms Catalyst Controller

Notes: ***B-STOCK: Light marks on the screen***


A serious trigger sequencer for generating complex, multi-layered rhythms. Eight channels of Euclidean pattern generation meet probability, modulation and CV control for real depth and power.

Supplier's Notes:
Constellation is all about rhythm. It is an 8 channel pattern generator that works by combining multiple dense and sparse patterns to create long, complex and musically interesting trigger and gate rhythms. Constellation takes a "parametric" approach to rhythm - there is no explicit step sequencing on the module, rather the rhythms are defined by euclidean (and more) parameters that build the rhythm mathematically.

Constellation aims to evolve the concept of euclidean rhythms far beyond the useful but repetitive patterns we often think of when we hear the term "euclidean rhythm". This is accomplished by by combining up to 8 individual euclidean patterns of different lengths and density. Each pattern may provide only a small component of the final output, but together create immensely musical and varied rhythmic material over a very long time frame - up to 999 steps! If each of those steps are 1/16 note in length at 120 bpm, that's a full 2 minutes of explicitly defined, yet non repeating rhythmic material.

In addition, Constellation's parametric approach allows any of these parameters to be modulated with CV through one of 8 freely assignable CV inputs. CV modulation introduces further ability for Constellation's rhythmic output to vary over time. Paired with a Maestro or Navigators, hours of interesting morphing rhythms are possible without the need for tons of step programming or the uncontrollable chaos of a purely generative approach.

When writing music, rhythmic interest is often built through the combination of repeating and non repeating elements that work together to anchor the overall feel but also keep the ear free from boredom over the duration of the piece. Constellation provides a unique set of tools to accomplish this goal and achieve rhythms that are intentional, unexpected and exciting to use as the foundation of your compositions.

28hp, 25mm deep
75mA +12, 18mA -12

Notes: These are right angle patch cables for Eurorack. Colour is black, pack of 5 cables.

Notes: Two channel expander for Bartender

Mixer section

Each channel has the following:

Stereo or mono - Each channel can be treated as a stereo channel or a mono channel with two summed inputs.

CV inputs for both panning and level control

Two send buses - You can route each channel to one of two send buses. Each send bus is stereo. You can choose if you want the send to come before or after the level/panning controls.

Mute - The mute has both latching mute (up) and a momentary mute (down). The mute uses a capacitor to slow the turn off and on of the mute action. So it is mostly click-less, but you may find an occasional pop.

Cue bus - You can route each channel to the cue bus.

Expandable Mixer Series

Bartenders can be cascaded to create 8ch, 12ch, or 16ch mixer. The main level is what is sent the main level control can act as a group control.

Barbacks can be added to add 2ch to your mix. Barbacks can also be cascaded enabling up to a 16ch mixer configuration.

Send-VCA can be added for CV control of the level of the send.

DVCA, Cast Iron, Mingles, and USB-2CH can all be connected with Dupont cables (aka female to female breadboard cables) via pin headers on the back of the modules. Connecting the in and out pins will send/receive the audio into the next module.

Width: 10hp
12V: 125mA
-12V: 100mA

Notes: These rack screws for Eurorack can be screwed by hand for quick changes, or use a standard Phillips head screw driver.

Each Standard Size M3 X 8mm stainless steel screw comes with a black nylon washer in a black tin.

Notes: Unique custom design 3.5mm patch cables.

They feature strong, ergonomic barrels which are slim and stubby for max patchability.

Available in various lengths (15, 30, 60, 90 & 120cm) and colours.

Longer 60, 90 & 120 lengths also include ALM cable tie.

Notes: Unique custom design 3.5mm patch cables.

They feature strong, ergonomic barrels which are slim and stubby for max patchability.

Available in various lengths (15, 30, 60, 90 & 120cm) and colours.

Longer 60, 90 & 120 lengths also include ALM cable tie.

Notes: Unique custom design 3.5mm patch cables.

They feature strong, ergonomic barrels which are slim and stubby for max patchability.

Available in various lengths (15, 30, 60, 90 & 120cm) and colours.

Longer 60, 90 & 120 lengths also include ALM cable tie.

Notes: Unique custom design 3.5mm patch cables.

They feature strong, ergonomic barrels which are slim and stubby for max patchability.

Available in various lengths (15, 30, 60, 90 & 120cm) and colours.

Longer 60, 90 & 120 lengths also include ALM cable tie.

Notes: Unique custom design 3.5mm patch cables.

They feature strong, ergonomic barrels which are slim and stubby for max patchability.

Available in various lengths (15, 30, 60, 90 & 120cm) and colours.

Longer 60, 90 & 120 lengths also include ALM cable tie.

Notes: Unique custom design 3.5mm patch cables.

They feature strong, ergonomic barrels which are slim and stubby for max patchability.

Available in various lengths (15, 30, 60, 90 & 120cm) and colours.

Longer 60, 90 & 120 lengths also include ALM cable tie.

Notes: Unique custom design 3.5mm patch cables.

They feature strong, ergonomic barrels which are slim and stubby for max patchability.

Available in various lengths (15, 30, 60, 90 & 120cm) and colours.

Longer 60, 90 & 120 lengths also include ALM cable tie.

Notes: Unique custom design 3.5mm patch cables.

They feature strong, ergonomic barrels which are slim and stubby for max patchability.

Available in various lengths (15, 30, 60, 90 & 120cm) and colours.

Longer 60, 90 & 120 lengths also include ALM cable tie.

Notes: Next-generation rotary mixer from Pioneer's parent company, AlphaTheta. Cutting-edge digital tech meets analogue richness thanks to output transformers from the legendary Rupert Neve Designs. The best of both worlds.

Supplier's Notes:
Euphoric sound with digital clarity and analogue richness from Rupert Neve Designs transformer

The euphonia produces a euphoric sound with the clarity of digital and the richness of analogue that's never been heard from a DJ mixer before.

To deliver a clearer sound quality that accurately reproduces the expression of the music, the euphonia uses high-quality 32-bit A/D and D/A converters as well as 96kHz/64bit floating point mixing processing operations in the DSP, utilizing the digital signal processing technology AlphaTheta has developed over many years.

All sound coming out of the euphonia passes through a transformer circuit co-designed by AlphaTheta and Rupert Neve Designs, the legendary makers of outstanding analogue audio circuitry and mixing desks revered by artists and sound engineers around the world. This transformer circuit, tuned specifically for the euphonia, adds harmonics to the music and creates a glossy and energetic sound that's smoother for mixing. Low frequencies such as kicks and bass are more stable and punchy, mid frequencies like vocals and instruments have more presence and gloss, and high frequencies such as hi-hats sound silky and natural. The transformer breaks down the barrier between vintage live and modern electric sounds, making mixing easier and surprisingly natural, as if recordings in different styles were originally one piece of music.

Specially developed rotary fader makes you feel one with the music

When you touch the faders on the euphonia, you won't want to let go. To enhance its intuitive mixing experience, the unit is loaded with rotary faders that feature a brand-new carefully developed design to give you the feeling that you and the mixer are one. After extensive testing, the perfect knob sizes were chosen, with an elastomer applied to the outer circumference of each to ensure a comfortable and reliable grip as well as a high level of vibration absorption.

The uniquely developed mechanism for the faders also benefits from optimum weighting. You'll notice a difference in the feel of the knobs when you turn them at different speeds, as a smooth load is applied when you turn a knob slowly for delicate fine-tuning and a limited load level is applied when you turn a knob quickly to instantly reach your intended volume level. And the fader volume curves have been optimized through feedback from numerous DJs, enabling smooth and natural mixing without equalizing, so you can concentrate on volume control. This innovative fader allows for musical expression that will move your audience and enhance your performance.

Energy Visualizer for understanding overall sound at first glance

Get an instant visual grasp of the status of your mix and the balance of track volume levels by glancing at the euphonia's Energy Visualizer. Conventional VU meters only have 1 needle meter, making it difficult for DJs to grasp multiple channel levels at the same time. But the euphonia's uniquely developed Mix Level Meter features a needle meter for each channel so you can visually check the levels for all channels and mix smoothly while keeping the groove going. You can even keep an eye on the balance of the master output by looking at the Spectrum Analyzer, which helps you keep your mixes sounding consistent and smooth, even in a long set, as you "watch" the euphonia's output and adjust it to create your perfect sound.

Next-generation 3Band Master Isolator that transforms sensibility into sound at your will

Highest-quality isolator

The size of the isolator knobs is perfect for rapid turns from centre to maximum or minimum, and the torque load is perfectly balanced for both quick operation and fine sound quality adjustment, with a luxurious feel that's not too light. The cut-off frequency and slope are set to control and highlight the kick, melody, and rhythm bands in a natural yet sharp manner.

Brand-new Boost Send for one-handed effects application

Add one of the built-in Send Effects, or an effect from an external unit, to the sound of any of the master isolator frequency bands.

Specifications

Max. external dimensions (W × D × H): 429.2 × 331.0 × 119.9 mm / 16.90" × 13.03" x 4.72"
Main unit weight: 9.5 kg / 20.94 lbs.
Frequency response: 20 Hz - 40 kHz (LINE)
S/N Ratio: 107 dB (USB, DIGITAL IN)
88 dB (PHONO)
105 dB (LINE)
79 dB (MIC)
Power requirements: AC 110 V - 240 V, 50 Hz / 60 Hz
Power consumption: 43 W
Accessories: Power cord
Warranty (for some regions)
Quick start guide
Precautions for use

Compatible software:
rekordbox
Serato DJ Pro

Terminals

Inputs:
DIGITAL IN × 4 (coaxial)
LINE × 4 (RCA)
PHONO × 4 (RCA)
MIC x 1 (XLR & 1/4" TRS jack)

Outputs:
MASTER × 1 (XLR)
BOOTH × 1 (1/4" TRS jack)
REC × 1 (RCA)
PHONES × 2 (1/4" stereo phone jack, 3.5 mm stereo mini jack)
USB: USB Type-C × 1

Others:
SEND × 2 (1/4" TS jack)
RETURN × 2 (1/4" TS jack)

Notes: Incredible value as always from the latest version of Arturia's Essential 88-key MIDI controller. Pads, faders, rotaries and a large LCD screen. Excellent integration with DAWs and the included Analog Lab V plugin.

Supplier's Notes:
Control your DAW, play with MIDI hardware, and get hands-on with your own style of music-making with KeyLab Essential mk3 88. This full-range keyboard controller removes barriers and makes creativity simple, with expressive semi-weighted keys, idea-sparking creative functions, and the most inspiring music software included as standard.

The streamlined piano range keyboard

Expand your musical horizons with a semi-weighted 88-note keyboard that removes barriers and makes your creative life easier. From studio to stage, DAW to MIDI hardware, KeyLab Essential 88 mk3 keeps things simple so you can focus on your music with full piano-range expressivity.

Your essential ingredients for creativity

KeyLab Essential provides an array of useful & intuitive controls that'll get the job done. Enjoy a comfy keybed, tactile faders/encoders/pads, and thoughtful layout that'll make sense for your setup. Enjoy a hands-on instrument experience balanced with software flexibility.

The best DAW integration

Get creative right out the box with KeyLab Essential's custom DAW scripts, bringing pre-mapped controls into your workflow with any major DAW. Not only that, but the KeyLab Essential controls work seamlessly with Analog Lab V, the included sound anthology plugin - letting you freely explore thousands of sounds, old and new.

Your musical workhorse

For when you want to get experimental, find a new sound, or just need a bit of extra inspiration, KeyLab Essential has a few tricks up its sleeve. Create fun ever-changing melodies with the Arpeggiator, weave rich chord voicings with Chord play, and always stay in key thanks to Scale mode.

What's new compared to the previous version?

A bigger display with 4 contextual buttons
5 dedicated DAW scripts, plus MCU & HUI protocols, for controlling any DAW
Enhanced integration with Arturia Software
Creative features: Scale mode, Chord Play, Arpeggiator (with presets), Hold function
2 Pad Banks (for finger drumming, clip launching, or User configuration)
Bigger software bundle (Analog Lab V, Ableton Live Lite, NI The Gentleman, UVI
Model D, Loopcloud & Melodics)
Multi-purpose pedal input (Sustain, Footswitch or Expression)
USB-C
Eco-designed

Included Software

You'll also get 6 titles giving you everything you need to make music your own way - here's

What's included:
Analog Lab V software with 2000 synth & keyboard sounds
Ableton Live Lite
UVI Model D & Native Instruments The Gentleman pianos
Loopcloud subscription
Melodics subscription

Box content
Quick Start
Registration card
USB Cable (C/A)

Notes: Really clever stuff here. The Octaves VCO takes an additive approach, layering harmonics on top of a fundamental frequency to create complex tones. Control the six bands via CV to adjust the harmonic content.

Supplier's Notes:
A harsh and funky take of an additive Oscillator.

Pile up multiplications of your frequency to get a lo-fi-retro wall of squared sound!

You get six doubled frequency pulses, or octaves, with common PWM and volume control for each of them.

The output of each is cascaded to the next one, so you can either have one output with all frequencies or break the chain and get several sums and modulate each independently!

Features
Six bands, multiple of the base frequency.
Square wave oscillator with Octaves selector PWM control and sync.
Range control for Tune pot.
Volume CV control and individual output for each band
Cascaded summing outputs.

Specifications
Current needs: +12V: 110mA, -12V: 84mA
Width: 12 HP
Depth: 22mm (assembled and DIY), including power connector
Aluminium, heat-treated front panel
Designed, kits prepared and completed modules assembled in Barcelona

Notes: *** B-STOCK: Box opened, but product is in excellent condition and in perfect working order ***


Really clever stuff here. The Octaves VCO takes an additive approach, layering harmonics on top of a fundamental frequency to create complex tones. Control the six bands via CV to adjust the harmonic content.

Supplier's Notes:
A harsh and funky take of an additive Oscillator.

Pile up multiplications of your frequency to get a lo-fi-retro wall of squared sound!

You get six doubled frequency pulses, or octaves, with common PWM and volume control for each of them.

The output of each is cascaded to the next one, so you can either have one output with all frequencies or break the chain and get several sums and modulate each independently!

Features
Six bands, multiple of the base frequency.
Square wave oscillator with Octaves selector PWM control and sync.
Range control for Tune pot.
Volume CV control and individual output for each band
Cascaded summing outputs.

Specifications
Current needs: +12V: 110mA, -12V: 84mA
Width: 12 HP
Depth: 22mm (assembled and DIY), including power connector
Aluminium, heat-treated front panel
Designed, kits prepared and completed modules assembled in Barcelona

Notes: The DS01 is the second-generation clone of the most classic dub siren in the known universe, old school transistors sound FX machine with unique feel and sound.

Audio output: impedance balanced 1/4" TRS Jack

DC Input: 12VDC, 500mA, centre positive, 2.1mm x 5,5mm barrel type connector

Dimensions: 120mm x 90mm x 40mm

12VDC 1A power supply included.

Notes: The classic dub siren, updated and improved. Machine-gun/laser-gun and airhorn sounds with modulation controls and tough build quality for use in live settings.

Supplier's Notes:
Our take on one of the most iconic dub sirens

-Classic machine-gun/laser-gun sound FX

-Brand new airhorn-like sound FX

-Modulation speed and frequency pitch control

-3 Base frequencies for the audio oscillator

Classic laser-gun sound FX machine

SPECIFICATIONS
Audio output: impedance balanced 1/4" TRS Jack

DC Input: 12VDC, 500mA, centre positive, 2.1mm*5,5mm barrel type connector

Dimensions: 120mm*90mm*40mm

12VDC 1A power supply included.

Notes: Studio grade connectivity.

Your studio needs more than just accessible patching - exceptional audio quality through the entire signal path is crucial! Black Lion has been improving already-great gear through their modification service for years, and all that know-how has been channelled straight into the PBR TRS3.

The PBR TRS3 is a 48-point TRS patchbay, suitable for the most robust routing imaginable in a single rack space, loaded with 96 audiophile-grade gold-plated 1/4" TRS connectors for maximum conductivity and signal clarity. You'll easily interconnect your preamps and other outboard hardware via its audiophile-grade, secure connections.

Limitless flexibility and road-worthy construction

You'll reconfigure your entire studio's routing at a moment's notice (while cutting down on cable clutter! The rear-mounted 3-way mode switches allow for Normal, Half-normal, and Thru operation, delivering unlimited routing potential for mults, bypassing, monitoring, and parallel processing.

Black Lion's team of engineers have worked tirelessly to ensure that the PBR TRS3 delivers proper quality through-and-through. The PBR TRS3 is also built Black Lion-tough, with a reinforced steel chassis and black-anodized aluminium faceplates that make for a matched and sophisticated look.

Not your average patchbays.

Configure your studio with the best: Black Lion Audio PBR Series Patchbays. Your recordings deserve the best, and maintaining a great signal path is crucial!

Features

96 audiophile-grade gold-plated 1/4" TRS connectors
Rear-mounted 3-way mode switches for Normal, Half-normal, and Thru operation
Black-anodized aluminium faceplate and reinforced steel chassis
Includes front panel labels
Exceptional value for the price

Specifications

Number of Points: 96
Front Connectors: 48x XLR
Rear Connectors: 48x TRS
Dimensions: 534 x 102 x 51mm, 1.4kg (boxed)

Notes: Custom moulded to fit the contours of the Allen & Heath Xone K2, designed for the Digital DJ. Our super durable polycarbonate shell offers a high level of protection and slides straight into controller bags, ideal for the travelling DJ.

Finished with a high quality smoked/clear sheen, shields faders and controls from dust, liquid and accidental impact whilst accommodating cables. At home, on the road or in the club, Decksaver has your Xone K2 covered.

*Photographed Allen & Heath K2 is not included

Notes: ***B-STOCK: Box opened, product in perfect working order***


Module A-149-1 is the first module of the A-149-x range. In this group we present by popular request several functions of Don Buchla's "Source of Uncertainty 265/266" (SOU) modules that cannot be realized with existing A-100 modules. Many functions of Buchla's 265 and 266 SOU can be realized with existing A-100 modules. For details please refer to A-100 patch examples.

Module A-149-1 has available four different analogue random control voltages that are generated in different ways.

The "Quantized Random Voltages" section has available 2 CV outputs: "N+1 states" and "2N states". N is an integer number in the range 1...6 that can be adjusted with the manual control (Man N) and an external control voltage CVN with attenuator. Whenever the rising edge of the input clock signal (Clk In) appears a new random voltage is generated at the N+1 resp. 2N output. The N+1 output is capable to generate N+1 different voltage levels (or states), the 2N output up to 2N different states. If for example N is set to 4 the N+1 output generates up to 5, the 2N output 16 different states. The voltage steps of the 2N output are adjusted to 1/12 V in the factory. Consequently, exact semitones can be obtained in combination with a VCO. The voltage steps of the n+1 output are adjusted to 1.0 V in the factory corresponding to octave intervals in combination with a VCO. For each output a trimming potentiometer is available on the pc board that enables the user to select other voltage steps for the output in question.

Even the "Stored Random Voltages" section has 2 stepped CV outputs available: one with even voltage distribution of the max. 256 output states and second one with adjustable voltage distribution probability. The distribution probability is adjusted by a manual control (Man D) and an external control voltage CVD with attenuator. With the control set fully counter-clockwise most of the random voltages will be low magnitude but even medium and high magnitude voltages may appear but with smaller probability. As the control is turned to the right (or a positive control voltage appears at the CVD input) the distribution moves through medium to high magnitude voltage probability. The symbol at the lower jack socket shows this coherence graphically. The voltage range is 0...+5V for both outputs of the "Stored Random Voltages" section. For each output a trimming potentiometer is available on the pc board that enables the user to select another voltage range for the output in question.

The A-149-1 can be extended by 8 random digital voltages with the A-149-2 Digital Random Voltages module.

Dimensions
12 HP
60 mm deep

Current draw
40 mA +12V
10 mA -12V

Notes: Buzz. Beep and bloop. Get high on the lo-fi sounds of "old-school" games, toys and terminals!

The Mainframe provides sample rate reduction ranging from 48kHz to 110Hz. A little background... the sample rate is the number of times per second that a sample or snapshot of an analogue signal is taken. For example, CDs (remember them?) had a sample rate of 44.1kHz which means that the original analogue signal is sampled 44,100 times per second.

The sample rate defines the frequency range that can be reproduced while maintaining good fidelity. When the sample rate is reduced the quality of the audio is degraded and aliasing occurs. Aliasing means audible artifacts created when higher frequencies are sampled at an inadequate rate and the result is distortion. The Mainframe's sample rate range is wide enough to take you from sounds that are quite pristine to sounds that are unrecognizable when compared to the input signal.

It also provides bit crushing ranging from 24-bit to 1-bit. What does that mean? Bit crushing is bit depth reduction. Back to the CD example... CDs used a 16-bit bit depth meaning that each of its samples was represented by 16-bits of information. Higher bit depths can accurately represent a greater dynamic range while bit crushing increases the number of sampling errors and creatively degrades the sound to bring us back to those nasty "old school" sounds we love.

The Mainframe's selectable High/Low/Band-Pass filter lets the user shape the artifacts of the bit crushing and sample rate. Another very cool feature is its Sample Rate Tuning Mode where the pedal analyses your input signal in real-time and sets the sample rate to match the pitch of your signal, or a set interval above your signal. This allows you to set the sample rate to match the key of a song, or it will continually adjust the sample rate based on what you play!"

Specifications

Circuit: Digital
Bypass: Buffered Bypass
Audio: Mono
Power Supply: 9.6VDC-200mA power adapter included
Dimensions (in): 4.5 x 2.75 x 2.1
Current Draw: 90mA
Year Released: 2020

Notes: Amazing analogue delay plus chorus and vibrato!

The EHX Memory Boy straps on the cape and flies with heritage into the search for amazing sound at a price that mere mortals can afford.

The Memory Boy uses the Deluxe Memory Man as a base, expanding upon it with additional modulation features and an optional Expression Pedal input allowing external control over Delay Time or Modulation Rate.

The Memory Boy carries the performance heritage for warm analogue delays and modulations that made its ancestors the go to legends that remain today. With two years in design, the focus was making the legend affordable to every musician while maintaining the character and artistic sounds that let you stand apart.

All analogue delay with Feedback
Up to 550 ms delay time
Selectable Chorus or Vibrato modulations rates
Choose between triangle or square modulation waveforms
Expression pedal control of delay time or modulation rate (expression pedal extends the range of modulation rate)
True Bypass
Power adapter included

Specifications

Circuit: Analogue
Bypass: True Bypass
Audio: Mono
Power Supply: 9.6VDC-200mA power adapter included (optional 9V battery not included)
Dimensions (in): 4.75 x 4 x 2.25 121 x 102 x 57
Current Draw: 60mA
Year Released: 2009

Notes: We took the Big Muff Pi circuit and simply shrunk it without changing its rich, creamy, violin-like sustain and sound!

The EHX Nano Big Muff Pi works and sounds identical in every way to our classic NYC Big Muff Pi. Get a piece of the pi for yourself!

Crushing distortion
Singing sustain with attitude
Compact, rugged nano enclosure
True bypass
Adjustable tone
9V battery included

Specifications:
Circuit
Analog
Bypass
True Bypass
Audio
Mono
Power Supply
9V battery included (optional 9.6VDC-200mA power adapter not included)
Dimensions (in)
4.5 x 2.75 x 2.1
Current Draw
3mA
Year Released
2013

Notes: Delivers overdrive and distortion with impact, and the modern player in mind!

The EHX OD Glove provides a rich, overtone laden sound that doesn't get muddy. Responsive controls that take you from sparkling, clean boost through brown crunch and all the way to thick, saturated hi-gain. Advanced features like Tone Shift and selectable 9 or 18V internal voltage for surgical sound sculpting.

Versatile MOSFET overdrive/distortion
Tone Shift switch
Selectable 9V or 18V internal voltage
True bypass
Tough, compact die-cast chassis
9V battery included

SPECIFICATIONS
Circuit
Analog
Bypass
True Bypass
Audio
Mono
Power Supply
9V battery included (optional 9.6VDC-200mA power adapter not included)
Dimensions (in)
4.5 x 2.75 x 2.1
Current Draw
12mA
Year Released
2013

Notes: Vintage tremolo and panning with Wave Form and Shape control!

The EHX Stereo Pulsar Stereo Tap Tremolo generates vintage tremolo and panning that will fill any venue with rhythmic stereo energy. Its Wave Form switch allows you to change the modulation from triangle to square form. The Wave Shape control allows you to control transitions from negative to positive saw tooth or adjust pulse width. This all means you can create any type of stereo tremolo from pure vintage to ones never heard before.

Stereo outputs
Tough and compact die-cast chassis
9V battery included

Specifications

Circuit: Analogue
Bypass: Buffered Bypass
Audio: Stereo
Power Supply: 9V battery included (optional 9.6VDC-200mA power adapter not included)
Dimensions (in): 4.75 x 4 x 2.25
Current Draw: 17mA
Year Released: 2007

Notes: Erica Synths Black Spring Reverb is a different take on spring reverberation units. Firstly, it has built in vactrol based audio compressor, secondly, it can operate an external tank and combination of both internal and external ones for effects unheard before, thirdly, in order to animate reverb effect, the module has built-in feedback effects - pitch shifters, delay, ring-modulator, etc; feedback amount and effect parameters can be controlled manually and via CV, making the module an experimental instrument on its own. Module comes with compact spring reverberation tank which can be easily installed in most eurorack cases.

Features
Compact spring reverberation tank to install in a skiff case
Manually and CV controlled feedback amount
Vactrol-based compressor
7 distinct feedback effects
Selection between internal, external reverberation tanks or combination of both
Feedback Send and Return jack sockets
The module is designed to be used with wide variety of spring tanks, but the best results will be using tanks with low input impendance - 8-200ohm

Technical specifications:
Audio input level -5V - +5V
CV level (full span) -5V - +5V
Power consumption 43mA, -71mA
Module width 12HP
Module depth 30mm
Internal reverb tank dimensions 190mmx67mmx24mm (30mm with spacers)

Notes: Blank panel for Intellijel 1U spaces. Made from high quality brushed aluminium that matches the 1U modules.

These can also be used for DIY purposes if you drill/mill them to fit your own custom circuits.

Comes with 2 screws.

Notes: The new, 2nd generation Audio Jacks Board comes pre-installed in every Intellijel 7U case manufactured since early 2019. Because this board is more fully featured than the previous generation, it's available as a stand-alone component for anyone who wishes to update an older 7U case.

You can tell which board you have by looking at the connectors. The new Audio Jacks Board has a large shrouded header flanked by two smaller shrouded headers, flanked by two link connectors at either end. Older boards have only one connector along the bottom edge.

The board holds four Neutrik TRS jacks, each of which can be configured as either an input or an output depending on the modules you connect. This allows you maximum flexibility when configuring your case - whether you wish to use the audio jacks as outputs, inputs, sends & returns; or some combination of these.

The jacks carry different audio signals depending on what you connect to the Audio Jacks Board. Please refer to the manual for more details on the many options available.

Notes: The Voltage Controlled Amplifier or "VCA" is one of the most essential and useful building blocks in a synthesis patch. The DUAL VCA 1U packs two high quality, DC coupled, linear VCAs into a very compact 1U package.

The two VCAs can be used completely independently or in tandem via the handy signal normalling. The DC coupling means that the VCA can be used for the amplitude control of both control voltages (CV) and audio signals.

Some application/use examples:

- Dual, independent VCA for dynamic level control of two different audio or cv sources
- Stereo VCA (use the CV normalling where CV A normals to CV B) for processing stereo sources or CV pairs.
- CV/Audio summing (when Out A is not patched, it normals to sum with OUT B, CV A and B control the independent levels)
- Voltage/signal doubling (use input A only and the doubled voltage will appear at OUT B when a CV of +5V applied to CV A)

Notes: Mixup is a versatile, expandable audio mixer for Eurorack format. It has eight inputs (6 on the front panel) and two outputs. Inputs 1 and 2 are single-channel mono inputs, each with its own mute switch and level control; Input 3 is a dual-channel stereo input with a shared mute and level control; and input 4 is an auxiliary unity-gain, non-mutable stereo input.

Using bus connectors on the back panel, you can chain multiple Mixups together in series, giving you the ability to mix together even more inputs, or to create sub-mixes for routing around larger systems.

Because Mixup is designed specifically for audio (and not for CV mixing), it uses AC-coupled circuitry (which reduces the potential for 'pops' when muting and unmuting audio), and it uses audio-grade, logarithmic attenuators for a smooth, even response across the entire volume range.

Notes: Noise Random Tools comprises a collection of useful utility blocks that you could use in many of your patches - Clock, Random Pulse, Analog Noise, Sample and Hold, and Slew.

Features:

- Clock and Random pulse source with adjustable rate
- Analog pink and white noise source with very accurate spectrum
- Analog sample / track and hold with very low droop
- Analog slew with adjustable slew rate

Notes: Outs enables your modular system to output both professional and prosumer compliant audio, and send it to external amplifiers, mixers, recording devices, or DAW interfaces. Using the L+R Level knob, it scales modular-level voltages down to the level required to drive external gear at either the +4dBu balanced professional line-level standard or the -10 dbV unbalanced standard.

Headphone monitoring is also provided via a low noise built-in headphone amp (with its own independent level control), capable of driving a wide range of impedances - from studio grade headphones to portable style earbuds.

To use Outs, simply connect the final output of your patch to the 1/8" inputs (where the built-in activity LEDs light up to indicate the presence and intensity of the input signal). The left input is normalled to the right, so you can create a stereo signal from a mono source. Or if you have an Intellijel Mixup, you can remove a jumper from its rear panel, and connect it to the Outs module using the 3-pin link cable included with the Mixup.

Notes: This module has 1/8" jacks to accept either mono or stereo audio signals from your modular gear.

It features input level indicator LEDs, and contains all the gain control circuitry necessary to drive external audio gear at the proper levels.

A ribbon cable is included for connecting it to either the Stereo Out Jacks 1U module, or a compatible Intellijel case with 1/4" jacks (e.g. 7U x 104HP, 7U x 84HP, or Palette 62).

Notes: Tangrams

Push (or Pulse) the Envelope

Snappy, classically analogue envelopes with visually intuitive controls. Add a powerful, cv controllable cyclical gate generator, integrated VCA, and trigger buttons -then double it-now you've got Tangrams.

Tangrams, like the Dual ADSR before it, is a dual analogue core-envelope inspired by the Roland SH-101 / System 100m design with several enhancements. Taking further inspiration from trapezoidal function generators like the one on the EMS Synthi, Intellijel have added a voltage-controlled pulser circuit to link the triggering of two envelopes - allowing for delayed one-shots, cycling organic envelopes, and more. In addition, Intellijel added two VCAs for level control of each envelope, or alternatively, direct injection of the signal you'd like to envelope - freeing up your other VCAs.

The Pulser

The Pulser can be thought of as a way to set both a gate ON time (T1) and an OFF time (T2). In this way, you could configure a cycling ADSR that has a gate time that is different from the interval between gates. Alternatively, you can create a sequence where ADSR2 is triggered by a delayed amount of time after ADSR1 is triggered (either cyclically or in a single shot sequence). The panel switches for routing or disabling the pulse sources allow for even more complex combinations of control beyond these examples. This special combination of functions can yield a plethora of interesting and organic envelope and gate patterns to be created; cyclical and single shot.

ADSR + VCA Features

Dual Analogue ADSR envelopes with digital gate Pulser for trapezoid shapes
Pulser stages P1 and P2 can be selectively routed to trigger each ADSR via panel switches
Three timing ranges: (FAST: ~5 seconds, MED: ~35sec, SLOW: ~1min A/D times)
Retrig input (allows re-triggering of the envelope if source gate held high)
VCA input can be used to dynamically control the respective ADSR output level (bipolar) or to process signals to be modulated in amplitude by the ADSR.
Manual GATE buttons for each envelope

Pulser Features

A pulse is made of individually controllable T1 and T2 stage lengths
CV control over T1 and T2 time
Pulser can be one-shot (SINGLE) or repeating (CYCLE)
PULSE output has a switch to select P1 or P2 as the source.
Pulser stages P1 and P2 can be selectively routed to trigger each ADSR via panel switches
START trigger input for starting/restarting the Pulser sequence
Manual GATE button to trigger the Pulser sequence

Size: 14HP
Depth: 35mm
Power: 66mA @ +12V 49mA @ -12V

Notes: Triplatt is a three-channel active/buffered attenuverter and summing mixer. Each channel has a knob, which can function as a unipolar attenuator or a bipolar attenuverter, depending on the setting of its corresponding two-position polarity switch.

Each input is normalled to a built-in precision +5V DC voltage source. With nothing plugged into the jacks, each knob controls a voltage range of 0 to +5 V or -5 to +5 V depending on the position of the channel polarity switch. Outputs A and B are also capable of a range of 0-10 / -10 to +10 when using the special function switches.

Each output is normalled to mix into the output of the channel below, making it possible to do sub mixes in groups of two or three.

In addition, each channel has a "special function" switch to alter its input voltage in a specific way. Channel A has a 2x voltage multiplier switch, allowing you to double the voltage sent into Channel A. Channel B has a +5V switch, allowing you to add 5V to whatever voltage is sent into Channel B. Channel C has a mute switch, allowing you to completely turn off the signal being sent into Channel C.

Notes: Mighty oscillations, mini size.

An analog oscillator and LFO with pure waveforms and precise tracking in a compact package. Perfect as a utility modulation source but equally capable to be used as a primary sound source. Patch it up and let it rip!

Features
Four simultaneous pure waveforms: Sine, Triangle, Square and Sawtooth
Pitch input for 1V/Oct tracking and FM
SYNC input for Hard Sync. This input has a comparator so that you can use a variety of waveforms as triggers.
Switch to select VCO (audio) or LFO range of operation
Three position Octave switch to jump pitch up or down by two octaves
PITCH knob has three octave range in VCO mode (extended to seven with the octave switch) and seven octave range in LFO mode (extended to 11 with the octave switch).
Bicolor led indicates the state of the triangle core rate

Specs
Width 14HP
Depth 37.5mm
Power 19mA @ +12V
16mA @ -12V

Notes: Convenient Connections

Use this module to tap into the 3-pin LINK connector used in several Intellijel products, including Mixup, Pedal I/O and the Palette and 2nd Generation Audio Jacks Board in a 7U case.

The XY I/O uses two 3.5mm TRS jacks, which accept insert cables to provide send/return capability to a pair of Pedal I/O's, or additional stereo inputs (or outputs) to a pair of Mixups, or one of each.

A third 3-pin Link connector on the back panel allows the X and Y jacks to access the L/R (or Send/Return) jacks on a single connected module or case without needing a stereo cable.

Width: 4HP
Depth: 24mm

Notes: Two oscillators independently set as VCO, LFO, or random generator

This new version replaces the original Twin Waves. All features of the former are retained. You can check all videos, reviews and comments of V1, being sure to benefit of all in the MKII version :-)

Features in VCO mode:

V/Oct tracking over 10 octaves
Tuning lock with octave selection
Through zero and linear FM
Sub-octave output
Hard & soft synchronization
VCA control and CV algorithms selection
Quantizer with various scales
20 algorithm-based synthesis types among:
Wave shaping
Phase modulation
Phase positioning of multiple waves
Up to 5 stacked oscillators in tunable unison
Self-sync with phantom oscillator
Additive synthesis (7 waves)
Variable bit reduction (bit-crushing)
Ring modulator with its own 2nd oscillator
Noise with LPF, BPF, or resonant filter

Features in LFO mode:

Simultaneous signal and trigger outputs
External wave synchronization
Clock controlled rate with voltage controlled multiplier and divider
CV and knob control of output level
Algorithm based wave engine with a selection of:
Wave shaping
Phase modulation
Random levels and vectors (also Brownian)
Randomly spaced triggers and waves
Display with contextual icons and instant reminder help text
LEDs indicating potentiometer vs. value matching, switch settings and output signals
Automatically saved settings for instant recall at power on
Firmware update by playing an audio file via the front panel
Compact and skiff-friendly module

Dimensions
8 HP
21 mm deep

Current Draw
52 mA +12V
17 mA -12V
0 mA 5V

Notes: ***B-STOCK: Box damaged, product in perfect working order***


Second-gen version of the excellent Opsix features major updates including 64-voice polyphony and an improved interface. Same powerful six-operator FM synth engine.

Supplier's Notes:
A Full-Spectrum Sound Experience

Opsix mk II is a digital synth like no other. Based on the sound engine of the original Opsix, the number of simultaneous voices and voicings has been expanded to an astounding 64 voices. The result is superior performance and precise control.

The Opsix Operator Mixer simplified FM synthesis for the first time, making it not just comprehensible but also controllable. With the addition of extra synthesis capabilities and programming, it offered a more efficient workflow and an even richer sound.

And, it is fully compatible with the sounds and samples from both the original opsix and the opsix Native software, including numerous high-quality libraries.

Evolved to an astounding 64 voices

The Opsix mk II has 64 voices, twice as many as the original 32 voices, allowing users to enjoy tone editing without having to worry about the number of simultaneous voices. In addition, the operator-mixer section, the most distinctive feature of this product, has been accented with a new image colour, green.

Get Illuminated with the Operator Mixer

At the heart of every sound is Opsix mk II's Operator Mixer - a simple set of six faders and knobs that invite exploration. Each part lights up red to indicate carriers or blue for modulators. Manipulating them opens up new sound-shaping possibilities to breathe fresh life into your musical ideas. This straightforward, hands-on workflow is part of what makes Opsix mk II so unique, just like the sounds it offers.

Direct Hands-On Control

Whether you're tweaking a preset or building a patch from the ground up, the six data entry knobs on the right give you quick access to the parameters you need and seamlessly sync with the large OLED display, giving you a clear, focused direction to your workflow. Coupled with the mixer, it makes creating fresh sounds super easy and, most importantly, fun!

Select from a full range of analogue-style filters, from the radical Korg MS-20 low-pass/high-pass filter to the powerful yet smooth KORG Polysix low-pass filter that gives your sound a vintage feel. There are also two or four-pole low-pass, high-pass, band-pass, and band-reject filters with resonance.

There's even a built-in spectrum analyser and oscilloscope that gives you visual feedback via the screen on the music you're making.

Six in One Synthesis

The core of Opsix mk II is nothing short of exponential. Since waveforms can be arranged and modulated in nearly infinite ways, Opsix mk II can easily do the sonic work that is similar to numerous types of synthesis:

Subtractive

Removing parts of the sound to get the sound you want; the most widely-used synthesis. Opsix mk II uses up to six envelopes and multi-modelled filters to achieve many cutting-edge and classical analogue synthesis tones.

Semi-Modular

Rerouting signal paths to change the sound. A spin through the Algorithm section will dramatically reshape the sound by changing how the signal routing between the operators work together, and no patch cables are needed. Analog-style controls and plenty of stackable waveforms take you from digital to analogue-sounding in no time. Enjoy deep basses, crisp leads, thick pad sounds, fuzzy brass tones, and so much more.

Analogue (Modeling)

Analogue-style controls and plenty of stackable waveforms take you from digital to analogue-sounding in no time. Enjoy deep basses, crisp leads, thick pad sounds, fuzzy brass tones, and so much more.

Waveshaping

Adding intentional distortion to the waveforms to achieve aggressive overtones that are either harmonic or inharmonic. This will help you achieve gritty, bitey tones dripping with character.

Additive

Stacking waveforms and blending their harmonics is key to an expansive range of harmonious, dissonant, and tension-driven sounds. With six operators available, the complete FM experience is possible, including the ability to go back in time for classic sounds you have heard throughout recording history.

Classic FM

Last but certainly not least, Opsix's highly flexible and powerful architecture starts with true six-Operator FM. As a result, it easily delivers signature sounds you have surely heard on thousands of hits from the '80s on through today, and with far more polyphony than other standalone FM synths available today.

With all of these ways to realize and explore sounds, Opsix mk II is uniquely suited as a "future-modern-classic" synth!

Altered Reality

What started as a legacy synthesis has evolved into something completely different. Opsix mk II is FM-based, but the similarities to the classic synthesis end there. The Altered FM architecture delivers sounds across a vast spectrum, far wider than any single synthesis has been able to cover before, thanks to new sound components; new waveforms, filters, shaping, effects, LFOs, envelopes, modulations, and more, all translating to its broad assortment of sounds.

Powerful Effects Processing

Opsix mk II provides three blocks of 30 types of high-definition effects that you can use together to enhance your sounds even further. There's everything from a great mix of usable standard effects like chorus, phaser, delay, and compressor to some world-class shimmering reverbs that will elevate your sound to the next level.

Specifications

Keyboard: 37 keys (velocity and release-velocity sensitive)
Sound generating system: Altered FM sound generator
Maximum Polyphony: 64 voices (varies depending on the setting)
Structure: 6 operators, 1 filter, 3 EGs, 3 LFOs, 3 effects, step sequencer, arpeggiator
Algorithm: 40 presets + user algorithm (unique to each program)
Operator: 6 modes (FM, Ring Mod., Filter, Filter FM, Wave Folder, Effect)
Oscillator waveform: 23 waveforms (Sine, Sine 12bit, Sine 8bit, Triangle, Saw, Saw HD, Square, Square HD, Additive Saw3, Additive Sqr3, Additive Tri3, Additive 12345, Additive 1+2, Additive 1+3, Additive 1+4, Additive 1+5, Additive 1+6, Additive 1+7, Additive 1+8, Noise S/H, Noise White, Noise Pink, Noise Blue)
Filter: 11 types (LPF 12, LPF 24, LPF MS-20, LPF POLY6, HPF 12, HPF 24, HPF MS-20, BPF 6, BPF 12, BRF 6, BRF 12)
EG: ADSR
LFO: 23 waveforms (Triangle, Saw Down, Saw Up, Square, Sine, Sample&Hold, Guitar, Exp. Triangle, Exp. Saw Down, Exp. Saw Up, Step4 Triangle, Step6 Triangle, Step4 Saw Down, Step6 Saw Down, StepRnd:Time, StepRnd:Lvl&Time, StepRnd:Level, Random:Time, Random:Lvl&Time, Triangle + , Saw Down + , Saw Up + , Square +)
V.Patch: 12 routings
Effect: 30 types (Chorus, Unison Ensemble, Phaser, Phaser (BPM) , Auto Pan, Auto Pan (BPM), Flanger, Flanger (BPM) , Rotary Speaker, Auto Wah, Exciter, Enhancer, LFO Filter, 3-Band EQ, Distortion, Guitar Amp, Decimator, Grain Shifter, Master Limiter, Compressor, Delay, Delay (BPM) , Autopan Dly, Autopan Dly (BPM), Tape Echo, Tape Echo (BPM) , Early Reflection, Reverb, Shimmer Reverb, Spring Reverb)
Sequencer: Step Sequencer (up to 16 steps, up to 6 notes per step), Motion Sequencer (up to 6 lanes)
Arpeggiator: 7 patterns (MANUAL, UP, DOWN, ALT1, ALT2, RANDOM, TRIGGER)
Number of programs: 500 (350 preset programs and 150 user programs as the factory-set default)
Favourite: 64 (16 Slots × 4 Banks)
Controllers: MODULATION wheel, PITCH wheel, RATIO OP 1-6 knobs, LEVEL OP 1-6 sliders, DATA ENTRY A-F knobs
Inputs/outputs: Headphone (6.3 mm stereo phone jack), OUTPUT L/MONO and R (impedance-balanced 6.3 mm TRS phone jacks), DAMPER (6.3 mm phone jack, half-damper not supported), MIDI IN and OUT connectors, USB B port
Power supply: AC adapter (DC12V)
Power consumption: 5 W
Dimensions (W × D × H): 565 × 338 × 90 mm / 22.24" × 13.31" × 3.54"
Weight: 2.9 kg / 6.93 lbs.
Included items: AC adapter
Accessories (sold separately): DS-1H damper pedal, PS-1 pedal switch, PS-3 pedal switch

Review: Linkin Park were many people's favourite rock act at least for a short time during their rebellious teenage years. Well, it is now two decades since the American outlaws were at their peak and specifically 20 years since they released their second and globally acclaimed album Meterora. As such it gets a special anniversary reissue here that features all of the original material as well as four previously unreleased concerts on DVD, plus rare and unreleased material that will be all nee to even the most hardcore of fan. A real must for collectors.

Notes: Honey is a palm-sized, touch-based noise instrument based on the bytebeat principle. It runs on a single AAA battery and emits sound through a speaker. It doesn't have an audio jack. It creates dynamic sounds by manipulating variables and mathematical operations through touch.

The internal dynamic equations consist of five variables and four operations, with six possible operators for each operation. They are constantly changing and forming new equations, creating chaotic randomness.

If the unit does not respond correctly, the battery needs to be replaced.

Powered by one AAA battery

Notes: The Cab X2 is the latest digital cabinet simulation and impulse response pedal from MOOER Audio, featuring stereo input and output, build-in factory simulation models, and support for third-party impulse response files.

The Cab X2 provides robust stereo support for users that need to take their favorite digital cab sims and IR files from their laptop to the stage. The Cab X2 supports flexible stereo setups, allowing the option to bypass the cab sim pedal itself and connect to an external amplifier, sound board, PC, or pedal board. Two footswitch modes are also included and can be configured as a traditional on/off switch or to cycle through presets.

Designed to make management of all your presets and IR files simple, the Cab X2 editor software is free to download for MacOS/Windows and makes setting up your X2 fast and easy. Simply download the software, connect your X2 with the included USB cable, and tweak your cab simulation files to perfection.

While away from your PC, the Cab X2 includes a headphone jack to keep everything nice and quiet while you manage presets on-the-go or for practice.

Features:
High-quality, IR-loading stereo cabinet simulation pedal
Includes 14 user preset slots that can store two different cabinet simulation settings each
11 factory cabinet simulation files with support for loading third-party impulse response files
Choose between mono or stereo setups with the ability to bypass the cab sim for each channel
Footswitch can be assigned as a traditional on/off switch or to switch between presets
Comes with specialized editor software for preset management and IR loading

Specifications:
Input: 2*1/4" monoaural jack (Impedance value: 1M ohms)
Output: 2*1/4" monoaural jack (Impedance value: 510 ohms), 1*1/8'' stereo audio output jack (Impedance<1 Ohms)
Power supply: 9V DV center negative (Please ensure the voltage value of power supply is not more than 9V, ensure the polarity is correct.)
Current Draw: 300mA
Dimension: 0.334kg
Weight: 75mm(D)*115mm(W)*33mm(H)
Accessories: Owner's manual, USB TYPE-C to TYPE-A cable; DC 9V power supply, sticker

Notes: The first pedal to get the X2 treatment is the D7 X2 Delay Pedal. With the 14 high-quality delay effects, this pedal features more than double the effects of its skinnier brother, the D7 Delay, while also adding stereo inputs and outputs. The array of delay effects in the D7 X2 have a wide range from classic analog and tape delays to more modern and experimental delays such as "Low-Bit", "Galaxy", and "PingPong". Adjustable parameters are different based on each effect and can be customized with the Tweak 1 and Tweak 2 knobs. Additional parameters can be adjusted by using the MIX, TIME, and FEEDBACK knobs. Timing of each delay can be adjusted with the TIME knob or by using the TAP TEMPO footswitch for quick adjustments on the fly.

Notes: The R7 X2 Reverb combines MOOER's best digital effects algorithms from the A7 Ambiance and R7 Reverb pedals and combines 14 different types of high-quality stereo reverb in to one ultimate pedal. Parameter knobs include High Cut, Low Cut, and Mix for adjusting the EQ and Decay and Pre-Delay knobs for adjusting the intensity of each effect. Unique features of the R7 X2 include the Infinite and Trail-on functions to customize how each effect fades out.

Each pedal features a single designated save slot for each effect where users can save their settings after being tweaked to perfection. A BYPASS footswitch is included for easy toggling. Simultaneously pressing the TAP and BYPASS switches turns on Preset Rolling Mode to switch between saved presets easily

14 different reverbs

Classic: Room, Hall, Church, Cave, Plate, Spring, Studio

Modern Ambient: Mod, Reverse, Wrap, Shake, Crush, Shimmer, Dream

Notes: The Impact GX49 and GX61 are dynamic and expressive instruments, tailored to composition & performance with your computer music system. The no-fuss interface is a great entry into the world of Nektar controllers.

Featuring a 49-note (4 octave) or 61-note (5 octave) keyboard, pitch-bend wheel, modulation wheel and foot switch socket. Two multi-colored octave buttons enable shifting the keyboard range up or down -3/+4 octaves with the LED colors changing to show the exact status, Impact GX are well equipped to deliver a great workflow.

Dedicated transpose buttons allow you to shift the keyboard range up to +/- 12 semi tones. The buttons can quickly be re-purposed to change the Global MIDI Channel or send Program messages. Additionally an assignable potentiometer provides control over any MIDI parameter, by default controls mixer volume.

Nektar DAW Integration for many of the most commonly used DAWs makes it easy to get going, and a pleasure to use. With Impact GX49 your controller keyboard is part of your system, giving you the creative freedom to compose, perform and play, without having to reach for your mouse constantly.

Transport - Extended!

Eight buttons intended for DAW control, are at the center of the Impact GX. Essential tasks like transport activation or navigating tracks are highly repetitive and reaching for the mouse every time, can kill any seed of inspiration. Used with Nektar DAW integration, the 8 buttons extend functionality to include control over transport and a host of other important DAW functions, right from Impact GX.

The buttons can also be assigned to MIDI messages for use with any MIDI software that's not supported by Nektar DAW Integration. A primary and a secondary message can be programmed for each of 7 buttons, delivering 14 programmable options total.

Nektar DAW integration - ticking all the right boxes:

Nektar DAW integration is carefully crafted to give the best experience with your Nektar hardware. It delivers the freedom to create, instead of having to reach for the mouse constantly when you are in the middle of capturing an idea.

With Nektar DAW integration, the hard work is done, so you don't have to. Once installation is complete, Impact GX offers an extended feature set, normally unavailable on a compact controller.

MIDI control & setup functions:

Impact GX is a MIDI controller as well as a DAW controller. If you use MIDI software that's not supported by Nektar DAW Integration, a host of options are available for you to set up MIDI control yourself.

Each of the 14 assignable MIDI buttons, the modulation wheel, foot switch and of course the big control knob, can be assigned to send out MIDI cc messages. The assignable buttons (14) can in addition be configured to send out Program message or MMC transport control. MMC (MIDI Machine Control) is often supported by DAWs that don't allow for advanced integration, so with this option Impact GX covers all the bases.

Connectivity & Apple iOS:

As a low powered USB device, Impact GX works with all USB devices that feature a Class compliant MIDI driver. That includes all version of Windows from XP and higher, Apple OS X 10.5 and higher plus Linux (as long as a USB MIDI driver package is installed).

And if you are often on the move you can easily hook your Impact GX keyboard to an Apple iPad using the iPad's optional USB camera connection kit (optional). Of course the Impact GX is powered by the iPad so you can work away for as long as your iPad remains charged.

Bitwig 8-track included:

Bitwig 8-Track in included with every Impact GX so you can start producing, performing, and designing sounds like a pro from day one. Bitwig 8-Track gives you access to over 50 software instruments and effects for use on up to 8 audio or MIDI project tracks, and you can use any 3rd party VST plug-ins you might own too if you like. The 'Bitwig Essentials Package', a highly versatile handpicked selection of loops, clips, and samples, is also included to help you get started. So put all that together and you have a powerful sketchpad for your musical ideas featuring the acclaimed workflow of Bitwig Studio.

Notes: The Nektar Impact GXP49 USB MIDI controller keyboard is designed for players: Experience 49 semi-weighted keys and instant access to performance controls including a real-time repeat engine, powerful Nektarine plugin patch management and Nektar DAW Integration. GXP gives you the keys to a great performance!

GXP Keys
PLAY - Treat your fingers to a dynamic semi-weighted keyboard with velocity and aftertouch that captures all aspects of your performances.

GXP Repeat Section
REPEAT - The Repeat Engine lets you create inspiring rhythmic elements with direct and intuitive realtime access from dedicated Repeat controls.

Impact GXP Transport
DAW CONTROL - Control essential DAW functions directly from Impact GXP using the dedicated transport controls. Supports 12 DAWs.

GXP Software Bundle
PRODUCE - All you need to create is included: Licenses for Steinberg's acclaimed Cubase LE Music Production Software and Retrologue virtual synthesizer.

KEYS: JUST THE RIGHT TOUCH
At the core of GXP49 is a newly designed and carefully balanced keyboard action. Its 49 semi-weighted full-size keys with velocity and aftertouch deliver a nice, firm touch and great playability.

Impact GXP 49 Front left view
Choose from 5 different velocity curves to tailor Impact GXP's keyboard sensitivity to your personal needs. The curves cover a wide dynamic range from soft to hard touch. The default curve "normal" is optimized to deliver good control across the whole velocity range right out of the box. In addition, 3 fixed levels let you send fixed velocity values across the whole keyboard if needed.

Nektar Impact GXP49 Control

DIRECT ACCESS: THE CONTROLS YOU NEED
The streamlined no-fuss control panel is based on the successful Nektar Impact GX-series, enabling advanced DAW integration with extended transport control, track selection and volume control as well as options to open/close DAW windows and navigate songs. In addition, GXP88's user interface also has 14 assignable illuminated RGB buttons for direct MIDI program- and bank-selection.

Impact GXP is a MIDI controller as well as a DAW controller:
If you use MIDI software that's not supported by Nektar DAW Integration, you can also set up MIDI control yourself. The assignable buttons in the transport section can be configured to send out Program message or MMC (MIDI Machine Control) transport control. In addition, any of the 28 assignable MIDI buttons, the modulation wheel, keyboard aftertouch, foot switches and of course the big control knob, can be assigned to send out MIDI cc messages. The settings are stored over power cycling.

GREAT CONNECTIVITY:
MIDI, PEDALS, POWER
The GXP49 gives keyboard players all the right expression options needed for live and studio work. It offers large pitch bend & modulation wheels and connections for up to 3 optional external pedals: Connect any standard expression pedal to the first, and any standard footswitch to the second socket. And if you use an optional Y-cable adapter, the footswitch socket even supports two independent switches.

Impact GXP Pedal Connections
Impact GXP Back Panel
Impact GXP can also be used stand-alone with external MIDI gear: The rear panel includes a 5-pin MIDI out jack and an external power supply socket for powering the unit when not connected via USB.

GXP Repeat Section 2

REPEAT: GET INSPIRED
The Repeat Engine is great for creating inspiring rhythmic elements: Simply press the dedicated Repeat button, play and get inspired.

The RGB buttons now give you direct one-button access to Repeat Rates, Accent, Interval, Swing and routing aftertouch or modulation to velocity. The large Data/Tempo Encoder turns into a dedicated tempo control, unless synchronization is set to external MIDI clock.

Choose from 5 different key trigger modes to change the repeat behaviour from interesting arpeggio-style effects with human feel to hard-quantized repetitive rhythms. Repeat is a fun way to experiment and create those famous "happy accidents", that make you come up with unexpected new ideas.

GXP Repeat Engine

NEKTAR DAW INTEGRATION: GIVE YOUR MOUSE A BREAK!
Install Nektar DAW Integration and the 8 buttons right above the wheels let you take control of essential tasks in your DAW right from Impact GXP. Features cover extended transport control including goto and set locators, track navigation, volume control, launching windows and patch navigation - without ever reaching for the mouse.

Notes: Control the expression inputs of your effects with Old Blood Noise's clever Ramper. Glide or step between two adjustable expression settings. A cheap and effective way to expand creative options.

Supplier's Notes:
Expression Ramper - Parameter Mover

Simplicity is the heart of innovation. This is exactly what the Expression Ramper from Old Blood Noise Endeavors offers - a super simple, yet highly innovative way to automate expression control, letting you conjure sounds you never thought possible from any pedal with an expression input. It's time to release your Inner-Ramper!

The Expression Ramper allows you to pick two expression settings and move between them, either in one motion or as a continuous LFO activated by a single footswitch. Just hook up the Expression Ramper to your expression-enabled effects pedal, simply pick your first expression setting in the A position, then your second in the B position and you're good to go.

From here, you can set Expression Ramper to move between A and B in three different ways. In TRI mode, it glides in a linear Triangle wave sweep from A to B, while in SQR mode it will make instant Square Wave jumps. Both TRI and SQR are LFO modes - you start the LFO when you hit the footswitch once, then stop it as you press the switch again. Alternatively, A<>B mode triggers a cool one-shot sweep, where every press of the footswitch jumps from one position to the other. The speed of the LFO and One-Shot movement is set via the Rate knob.

These simple and intuitive features can unlock worlds of sound. For instance, if you have Expression Ramper hooked up to a pitchshifter, you can create classic Whammy-like octave glides in one-shot mode, stretchy modulation in Triangle wave mode or hypnotic pitch sequences in Square wave mode. Got an expression-enabled phaser? Turn it into a step-filter with Expression Ramper's square wave. Or maybe an expression-enabled delay pedal? Use Expression Ramper to create swelling Feedback waves in Triangle mode or jump between two preset delay times in one-shot mode. The list goes on and on and the possibilities are basically endless.

While it should suit most effects pedals right out the box, Expression Ramper can easily be configured for different polarity or types of expression pedal simulation by using the internal jumpers. Plus, you can even change the supplied internal 50K digital socketed potentiometer and replace it with one of 10K or 100K values if needed. This enables the pedal to be specifically tailored for whatever expression-enabled devices you might have like keyboards, synths, vintage gear or more esoteric sound devices. All of this goodness is packed into a highly compact enclosure, ensuring that you can fit the Expression Ramper (or several Expression Rampers) into any setup.
