Notes: The Jumbler music synthesiser module is a six by six channel analogue signal combiner and distributor for the New Universal Synthesizer System or any Eurorack modular synthesiser. Jumble is one of the N.U.S.S. concepts where the routings of a patch could be re-configured, or jumbled, instantly via voltage control to produce variations on a theme.

Jumbler gives you powerful two-parameter access to the rearrangement of both origins and destinations for up to six modular signals. One to six inputs are routed to one to six outputs, in an order determined by the Rotate control, and combination determined by the Radiate control. Unlike a simple switch module, Jumbler's analogue VCA-based design is specially geared for smooth transitions and hybrid signals.

Jumbler is a great module for hybrid control voltage mashing, complex waveform mixing, on-the-fly effects re-routing, gate and clock re-combinations and more. Some folks have said it is like patching a stack of 6 RxMx circuits.

Width: 10hp
Max Depth (incl. power cable): 43 mm

Power:
178mA@ +12V
92mA @ -12V

Notes: 'Pamela's PRO Workout' is a compact programmable clocked modulation source for your Eurorack modular system. It provides 8 highly editable outputs producing various control voltage signals correlated and synced to a BPM based master clock.

Each output can provide everything from simple clocked triggers, complex rhythmic waveforms, quantised melodic patterns to random chaos with direct and assignable CV control over numerous parameters. These features together with a quick and easy to use interface provide almost limitless synced modulation possibilities in a tiny space.

Building on the original 'Pamela's Workout' & 'Pamela's NEW Workout' the evolved 'PRO' Pam maintains the precursor's form factor and intuitive workflow but improves and adds many new features with upgraded hardware, more CV inputs, a new full colour hi res display and rewritten software adding many new enhancements like micro grid timings and cross output modulations.

Through optional expander modules more CV input and outputs can be added with support for external non euro equipment through Midi and Din Sync outputs. Please enjoy your next generation PRO workout!

Size: 8HP
Power: +12v 60ma / -12v 10ma
Depth: 32mm (approx with power header)
Outputs: 0-5v buffered low impedance. 12 bit res. 3.8khz max update freq.
Inputs: CV 0v-5v / Clock, Run - rising edge 700mV min.

Notes: The new Genelec 8010 allows professionals to work in compact studios and on the move with an accurate monitoring tool.

The Genelec 8000 Series is widely used in broadcast, music and post-production studios around the world.

The ease of installation and outstanding sound quality make Genelec 8010 monitors ideal for small studios, OB vans, and perfect companions for portable recording devices and other mobile work.

Notes: Full-featured triangle core VCO/LFO

The Dixie II+ is a larger variant of the classic Dixie II. Using the same great triangle core oscillator, it adds a number of features to make it even more versatile with only a modest increase in size. The Dixie II+ makes a great primary oscillator for a modular system, or a great companion the Rubicon.

Notes: The Polaris is a 4-stage cascaded OTA filter designed by David Dixon. It builds on the lineage of the Dr. Octature and Atlantis filters, but with a totally revised core and resonance control. Along with dedicated LP, HP and BP outputs it features a configurable MULTI output capable of an unprecedented 27 different filter modes.

With drive turned down the Polaris is capable of buttery smooth filtering, and the cutoff control range has been fine-tuned for playability. With the drive dialled up and the new asymmetric multi distortion circuit engaged it creates a more aggressive sound. Not content to be just a filter, the Polaris's AP phaser mode combined with frequency modulation can be used to achieve a phaser effect.

With so much versatility in a modest size, the Polaris is an ideal filter for a starter system and an excellent addition to the tonal palette of a larger modular.

Notes: The Ensemble Oscillator is a unified polyphonic voice of sixteen complex oscillators combining additive, FM, phase-distortion and wavefolding synthesis techniques in new unorthodox ways. By quantizing the oscillators to scales or series of harmonics, the Ensemble Oscillator allows you to explore the sonic boundary between musical chords and rich evolving textures. Easily create a wide variety of sounds ranging from aggregates of pure sine waves to pulsar synthesis or pristine harmonic tones and lush wide chords to rich dirty drones and rumbling glitches. Custom scales can quickly be "learned" and saved using a CV keyboard or by manually entering notes with the controls.

The Ensemble Oscillator is designed by Matthias Puech and 4ms Company.

Electrical and Mechanical Specifications:

16HP Eurorack format module
0.98" (25mm) maximum depth (including power cable)
10-pin to 16-pin Eurorack power header

Power consumption:
+12V: 114mA maximum
-12V: 45mA maximum
+5V: 0mA (not used)

Audio outputs
Frequency range: 0Hz (DC) - 20kHz
Typical amplitude: 10Vpp
Maximum amplitude: 18.5Vpp
1V/oct inputs (Root and Pitch)
Voltage range: -2V to +6V (8 octave range)
Factory calibrated to 1.00V/oct
Per-jack user-calibration allows from 0.7V/oct to 1.3V/oct
CV inputs (other than 1V/oct)
Voltage range: -5V to +5V

Gate inputs:
Trigger threshold: 2.5V
User memory (non-volatile)
Scale slots: 30
Shift feature settings
1V/oct calibration settings

Notes: Instant ambient bliss coupled with the powerful ambience processing is a brand-new Ensemble engine, capable of creating pads and soundscapes that follow your playing organically - so if you change pickups or play in a different place on the neck you get different results. It's unlike anything you've ever heard or played before, all wrapped in a smaller form factor that still manages to house full stereo I/O, TRS MIDI and USB-C connectors on the back panel. Prepare to be inspired!

Cloudburst's Ensemble switch reveals a whole new world of captivating sounds never previously heard from a reverb pedal. Use it subtly to add harmonically rich and otherworldly dimensions to your ambient reverb soundscapes, or use it liberally to hear a lush synthesized string section swell under your guitar playing. Ensemble reacts to your entire guitar signal in an organic and musical way, delivering a richly responsive and uniquely inspiring playing experience.

Cloudburst gives you multiple reverb experiences, with beautifully-tuned and natural small spaces at one end of the Decay knob and vast, expansive atmospheres at the other. As you turn the Decay control numerous internal parameters are automatically adjusted, allowing this ambient reverb pedal to produce outstanding studio-quality spaces of any size at the turn of a single knob.

All of the premium components, sound quality and road-worthiness you expect from a Strymon reverb pedal are here in Cloudburst's new compact format. Featuring unbeatable ease of use and some of the finest reverb sounds we've ever created, Cloudburst could easily be the only reverb pedal you need on your pedalboard.

Notes: RackBrute 3U is a comprehensive Eurorack housing, transport, and protection solution. Featuring configurable positions, dependable power supply, and maximum practicality, you can be assured your precious modules will be well guarded.

Don't worry; your beloved modules are under heavy guard.

Modular gear is a precious commodity, and you need a versatile housing and security system to accommodate them. A first glance, you'll see that this is a perfectly fitted 3U, 88 HP case made of a light but strong aluminium chassis, fitted with wood side panels.

Deceptively simple, RackBrute is far more than a simple box. It includes many smart additions, such as the included +12V / -12V / +5V power supply that ensures that keeps everything up and running, and the multi-position handle system that not only lets you carry your collection with ease, but also lets you deploy an optimal operating angle, whatever your preference.

Ready for anything

Secure an unobstructed viewpoint over the theatre of operation, and hold the position 'til further orders.

In addition to keeping your modules safe and secure, RackBrute 3U gives you total control of the situation, no matter the context. The first of its secret weapons is the Link fastening system. Paired with the included handle, it will let you choose one of several configurations and orientations for your modular arsenal. Whether you want your gear stealthy and prone, or standing to attention, RackBrute is at your command.

The second trick up its sleeve is the stalwart, ever-reliable, power supply module. Including two independent circuits to supply common modular voltages, it will more than cover your need for +12V, -12V and +5V, providing up to 1600mA in total.

Thirdly, its robust power rail includes a sophisticated noise-filtering technology, and provides 20 standard slots to leave plenty of space for your collection.

Once you're powered, in position, and locked down, you'll feel like your modular rig could withstand a siege.

Joining forces with allies

Always remember the Modular Republic's motto: Unity is strength.

The Link fastening system not only equips the RackBrute 3U, but also its large-calibre sibling, RackBrute 6U as well the MiniBrute 2 and MiniBrute 2S. No matter the combination you go for, you can make the most out of your extensive module collection, or create a powerful EcoSystem with the extensive CV/Gate connectivity of the MiniBrute 2 and 2S.

It's also worth noting that although this technology comes straight from the top secret Arturia research labs, they are working for the greater good. The Link system is patent-free, so you can expect more and more Link-enhanced equipment to become available in the near future.

Do not wait for reinforcements, bring them yourself.

Let's move out

Arturia have made sure that your gear would arrive without any scratches.

When carrying precious cargo, dozens of fragile modules, a unique and irreplaceable collection, you need to be certain of their safety. With RackBrute 3U, you have nothing to fear: from the handle, all the way to the threaded nut strips, you'll find strong aluminum and steel. Wherever you go, however long your journey, however heavy your setup, RackBrute was built to last. Even transporting two RackBrutes or a RackBrute and a MiniBrute 2 is totally risk-free thanks to the built-in Spacers, eliminating any chance of collision.

If you are planning an undercover mission, the dedicated, discrete RackBrute Travel Case will keep your precious equipment free from harm.

When you need to take your show on the road, rehearse, or even just rearrange your creative space, you can depend on RackBrute.

What's in the box

Box content:

RackBrute 3U unit
Power cord
Instrument dimensions
Size : 19 x 6.6 x 3.3 inches (484 x 167 x 83mm)
Weight : 4.7 lbs. (2.1 Kg)

Main Features:

Eurorack format, 88 HP
Aluminum Chassis
Provided with a 5 HP power module
Up to 1600mA on +12V and 1600mA on -12V (2 separate circuits of 800mA)
Up to 900mA on 5V (USB + 5V modules)
Power rail with noise filtering
20 standard power slots with up to 800mA on +12V and -12V
Link system and smart handle to fasten a MiniBrute 2/2S or another RackBrute unit in various configurations
Built-in Spacers for the highest protection in transport configuration

Notes: Low-cost, portable, compact enclosure that turns Eurorack modules into table-top instruments.

The Pod64X is 64HP with 2.16" (55mm) of available module depth. The built-in power supply has four power connectors and can be daisy-chained to other Pods. More power connectors can be added with the Multi Power Cable accessory.

Pods require a power brick, or a barrel cable to daisy-chain to a Pod or Row Power that's already powered.

Pods are a perfect way to get started in Eurorack, or add a couple more modules to your monster system!

Made from 100% anodized aluminum, Pods are light, tough and perfect for on-the-go set ups. The power supply can handle up to 1.4A of +12V, which is plenty of juice for even the most modern digital modules. (Or if you prefer to DIY your power supply, Pods are also available unpowered)

Each Pod64X typically will house up to six modules, but more can be accommodated using a multi-power cable accessory.

Mix and match your Pods with desktop synths, effect pedals, drum machines or any musical gear for a flexible modular system. Pods can even daisy- chain with the 4ms Row Power system making them a convenient outboard mini-skiff. Need to add another module? Just add a Pod! Need to pack light for a live set? Just grab the Pods you need and go!

Basic Features:

64 HP of Eurorack modular space
Extra room for deep modules
Standard M3 threaded holes
100% lightweight anodized aluminum
Built-in Power supply
Red, White, and Blue LED power indicators

Includes:

64HP Pod, black anodized aluminum
Built-in power supply with six Eurorack power headers
Extra deep (2.16"/55mm) fits virtually every Eurorack module
M3 x 8mm pan-head screws, stainless steel (20)
Adhesive rubber feet (4)
Does not include barrel cable or power brick
Power Supply:

Four 16-pin Eurorack power shrouded headers
+12V max 1.4A
-12V max 0.67A
+5V max 1.0A
Power input: Two barrel jacks for daisy-chaining
15V-20VDC, 2.1mm positive tip
Exterior dimensions:
Width: 329.7mm (12.98")
Height: 159.5mm (6.28")
Depth: 57mm (2.24")
Interior dimensions:
Max module depth: 55mm (2.16")
Module width: 64HP
Weight:
0.5 kg = 17 oz

Notes: The little brother to the original DrumBrute arguably packs a bigger punch. Gritty analogue sounds are on offer, but the sequencer is just as inspiring. A great alternative to the usual Roland suspects.

Supplier notes:
This is the drum machine you've been waiting for.

Combining bold, hard-hitting analogue sounds, a monstrous output distortion, performable controls, superb connectivity, and a powerful sequencer, DrumBrute Impact will fill your music with energy and muscle.

Putting the focus on "Brute", DrumBrute Impact features 10 high-energy, refined, punchy analogue sounds.

You can also use the exclusive "Colour" sound-shapers to introduce unique, per instrument effect for some variation. Boost the harmonic content, add some drive, snap, or crack at the touch of a button, you can even automate tonal changes by creating a "Colour" sequence. If you want your drums to push even harder, use the built-in distortion on the output for some drum-optimized crunch.

DrumBrute Impact is a drum machine for musicians and producers who crave raw power and monstrous tone.

Awesome drums made easy:

Sharing the same prize-fighting sequencing architecture found in the original DrumBrute, you'll love the simple, fun, and intuitive sequencer in DrumBrute Impact.

Whether you want to create complex, phasing polyrhythms or straight, pounding rhythms; record a finger-drumming performance; punch in a step-sequenced masterpiece; DrumBrute Impact beats to your rhythm. Use the touch strip to create some real-time glitchy, beat-repeat breakdowns, spice up a single instrument or your whole pattern with a dedicated 'Random' knob, and add some syncopation and groove with the 'Swing' feature.

A true analogue experience:

Connect to your other gear, sync up, and make some music the old-school way.

Get away from computer screens, say goodbye to sub-menus, and jump into the world of tactile, instant, analogue satisfaction. Featuring a huge array of sync and connectivity options, you'll be able to hook up and jam with practically any other synth, sequencer, or MIDI-enabled instrument. Mix on the fly with dedicated controls for every function, multitrack, record, effect, and mix the sound your way with multiple bus outputs. Save patterns that you love, chain them together, and create full songs and live sets, all without looking at a single screen.

DrumBrute Impact is a massive sounding, creativity fuelling beast, with effortless workflow and amazing performance controls.

Notes: Equipped with the same ESS Sabre32 Ultra DAC Technology found in audio interfaces costing thousands, the M4 delivers an astonishing 120 dB Dynamic Range on its main outputs. ESS converters also drive the headphone output, which rivals dedicated headphone amplifiers costing hundreds. Ultra-clean preamp circuits produce a measured -129 dBu EIN on the mic inputs. Capture and monitor your audio with pristine clarity.

The M4 provides best-in-class speed for monitoring live inputs (mic, guitar or keyboard) through your computer, thanks to MOTU's expertly engineered USB drivers, which deliver class-leading, ultra-low 2.5 ms Round Trip Latency (at 96 kHz with a 32 sample buffer).

When recording and mixing, nothing is more critical than achieving optimum levels. The M4 is the only audio interface in its class with a full color LCD featuring clear, detailed level meters for all inputs and outputs. Enjoy professional-level volume control and feedback to get your sound just right.

The M4 driver provides convenient loopback channels to your host computer, so you can easily route computer output back to the computer, where you can mix it with live mics and/or guitar inputs from the M4 in your host software for live streaming or podcasting. Streaming and podcasting has never been easier and better-sounding!

Decades of award-winning product engineering for hit songs, mega tours, primetime shows and blockbuster movies goes into every MOTU audio interface.

Notes: Rings is a resonator, the essential ingredient at the heart of several physical modeling synthesis techniques. The resonator transforms an external, unpitched excitation audio signal into a full-bodied pitched sound. Rings is the bar, the tube or the bunch of strings you cause to vibrate with a bursty external signal.

Any signal can be fed into the resonator, including envelope clicks, trigger signals, noise bursts, even tonal sounds. It also contains a special "polyphonic mode", where four notes can ring together at the same time. Although it is not truly polyphonic, it adds density and chordal characters to the sounds output. For those wanting the functions of Elements without the losing HP real-estate, Rings is exactly the solution.

Three families of vibrating structures are simulated by the module, with CV control over their parameters:

Strings, membranes and tubes as modelled by Elements' resonator section (modal synthesis).

Strings coupled together and vibrating in sympathy, with controllable intervals between them.

Strings with a variable amount of inharmonicity.

Rings can be configured so that each new note is played on its own virtual string, while the previously played note(s) still decay. This unique take on polyphony allows the module to play strummed chords.

Controls

Number of strings/structures (1, 2 or 4).
Synthesis model (modal, sympathetic strings, string).
Main frequency (quantized in semitones).
Structure. With the modal and string models, controls the inharmonicity of the spectrum (which directly impacts the perceived "material"). With the sympathetic strings model, controls the intervals between strings.
Brightness. Specifies the brightness and richness of the spectrum.
Damping. Controls the damping rate of the sound, from 100ms to 10s.
Position. Specifies at which point the structure is excited.

Inputs and Outputs

Frequency, structure, brightness, damping and position modulation CV inputs with attenuverter (-8V to +8V).

"Strum" trigger input to indicate when a new polyphony voice needs to be allocated. Normalized to an edge detector detecting changes on the main V/Oct input, or sharp transients on the audio input. Detection threshold at 0.6V.

1 V/Oct frequency input (-1V to +5V).

Resonator audio input, normalized to a filtered pulse/noise burst triggered by the "Strum" input (for stand-alone use). Modular level, up to 16Vpp.

Two audio outputs, splitting the signal into even/odd partials in monophonic operation, or even/odd notes in polyphonic operation.

Specifications

Module width: 14HP
Module depth: 25mm
Current draw: 120mA @ +12V, 5mA @ -12V

Notes: The ultimate finger drum pad

With ultra-sensitive Pads in an ergonomic layout perfect for finger drumming, the FGDP features a Tone Generator, internal speaker, and rechargeable battery that make it a true all-in-one instrument that you can play anywhere. Let your fingers make the rhythm!

Made for finger drumming

Thoughtfully designed layout and Pads for the ultimate finger drumming performance. From sampled acoustic drums that sound like they're right in front of you to powerful electronic sounds, beloved and curated by top professional artists, covering a wide range of genres. Yamaha promises uncompromising performance.

Optimised layout

Introducing a distinctive Pad layout meticulously designed for optimal finger drumming by prioritizing ergonomic comfort.

With the FGDP, you have the freedom to assign Voices to Pads according to your creative vision, but at Yamaha, we recommend the 3-finger style. Harness the power of your thumb for the kick drum, rely on the enduring middle finger for precise hi-hat control, and let your dexterous index finger bring to life the delicate nuances and intricate phrases of the snare.

The home position enables you to effortlessly execute fundamental rhythms, like 8th notes using just one hand. You can use your other hand to play on the other symmetrically laid out pads to unleash captivating back beats in 16th note or double kick styles.

Equipped with an ample number of Pads perfectly suited for finger drumming, the FGDP empowers you to deliver your finest performances, setting itself apart from conventional Samplers and MIDI Pads.

Expressive precision

Featuring cutting-edge Pads designed to capture every subtle nuance, the FGDP ensures that no detail goes unnoticed. With the powerful combination of the internal Tone Generator, you can deliver delicate performances encompassing ghost notes, impactful accents, flams, and lightning-fast rolls. Moreover, the Pads support Aftertouch, allowing for enhanced expression and enabling unique drumming techniques such as cymbal choking by applying pressure to a Pad while holding it pressed. With the FGDP, your drumming possibilities are almost limitless.

Specifications

Size/Weight

Dimensions

Width: 223 mm (8-3/4 in)
Height: 51 mm (2 in)
Depth: 223 mm (8-3/4 in)
Weight: 1.1 kg (2 lbs. 7oz)

Packing Box

Width: 282 mm (11-1/16 in)
Height: 110 mm (4-11/32 in)
Depth: 272 mm (10-3/4 in)

Pad section

Drum Pads: 18 pads
RGB square pads: 8 pads

Number of Trigger Settings:
Preset: 12
User: 50
After Touch: Polyphonic, Channel
Assignable Functions: Yes

Control Interface
Display: LCD with backlight

Tone generator
Tone Generator AWM2

Maximum Polyphony: 64 notes
Drum kits: Preset: 48 Kits, User: 50 Kits
Voices: 1,500
Kit Edit: Yes
Effects: Reverb: 11, Chorus: 10, Variation: 23, Speaker EQ: 5

Audio Files
Import limit: 100 files
sample format: WAV, AIFF (44.1 kHz, 16-bit, mono/stereo)
Maximum loadable sample time approx. 600 seconds (44.1 kHz, 16-bit, mono), approx. 300 seconds (44.1 kHz, 16-bit, stereo), approx. 20 seconds per file

Click
Tempo: 30 to 300 BPM, Tap Tempo supported.
Beat: 1 - 16
Others: Patterns (1/4, 1/4T, 1/8, 1/8T, 1/16, 1/16T, Clave)

Session Creator

Number of Session Creators: 23
Sections: Intro, Main × 4, Ending
Parts: Drum, Bass, Other × 4

Recorder
Recording time: USB flash drive approx. 80 minutes per file
Format: WAV (44.1 kHz, 16 bit, stereo)

Functions

Voices
Note Repeat: Each Pad
Humanize: Each Pad

Registration Memory
Number of Buttons: 4
Preset: 5 Banks, User: 50 Banks

Amplifiers and Speakers

Amplifiers: 2.5 W
Speakers: 4 cm × 1

Other

Connectors

Headphones: Headphones/Output (Stereo mini jack x 1)
AUX IN: AUX IN (stereo mini jack × 1)
USB: USB TO DEVICE (Type A), USB TO HOST (Micro B)

Power Supply
Power Supply: USB power adaptor 5 V/1.5 A or greater USB BC specification compatible products (Sold separately)
Internal Battery: 1,400 mAh, 4.5 Wh 3 hours
Power Consumption: 7 W

Accessories
Included Accessories: Owner's Manual, USB cable

Notes: Goldring D42 stylus is designed to fit the current Goldring 1042 phono cartridge or old model 1040, a direct replacement when your stylus is worn - saving the cost of buying a whole new cartridge. Goldring cartridges generally last many hours until the stylus needs replacing. An indication of wear is a "duller" sound.

Simply remove your current stylus by carefully pulling it away from the cartridge and replace it with the replacement.

The 1042 is a record cartridge for the audiophile who demands the ultimate sonic performance from their system, together with the convenience of a user replaceable stylus. The extended groove contact of its Gyger-S diamond gives the 1042 unsurpassed resolution of the fine groove modulations, producing an exceptionally detailed, smooth and musical sound.

Replacement stylus: 1042 - D42

Notes: A 22hp version of Mutable Instruments Elements. It is functionally equivalent and therefore runs all firmware options and having identical sound characteristics. This version is great compromise between the tight spacing of Atom and full size original, which is a bit large.

Width: 22hp
12V: 130mA
-12V: 10mA

Module power connector can be connected either way on the module side.

Notes: Cutting-edge tech meets ancient sounds in this truly original 'instrumentalis electronicum'. Create beats using genuinely old-school drum sounds, lutes, lyres and more, then load or record your own samples to expand your sonic options.

Supplier's Notes:
EP-1320 Medieval

The world's first medieval electronic instrument

Hurdy gurdys, lutes, Gregorian chants, thundering drums and punishing percussive foley FX. The EP-1320 is the first of its kind: featuring a large library of phrases, play ready instruments and one-shot samples from an age where darkness reigned supreme, the instrumentali electronicum is the ultimate, and only, medieval beat machine.

Unlock the magic of medieval sounds

The EP-1320 comes with hundreds of medieval sounds and samples, a redesigned set of send effects and punch-in FX, a brand new arpeggiator and a collection of craftily captured multi-sampled instruments. The line input and the internal microphone allow you to sample your own sounds in just seconds. Whether you're into making sultry serenades or bubonic beats, the EP-1320 has you covered.

Become your own bard

Alongside a bucketful of one-shot samples the instrumentalis electronicum features a number of readily playable medieval instruments - play them on the pads or on an external MIDI keyboard.

Summon your inner troubadour

In Demus mode, choose any of the 9 medieval songs and jam along using the sounds and instruments on the four banks. Add some punch-in FX and you're ready to send any tavern floor into a frenzy! (Also perfect for banquets and fetes).

An unrivalled medieval experience; EP-1320 features a hundreds of built-in medieval sounds for your nostalgic pleasure. Go back in time and play along with the built-in magical melodies, sultry serenades and bubonic beats. Included in the box are 4 knobs, a sticker pack and a quick start guide for you to hit the ground running.

Packaging: 262x262x28mm
Product weight: 0.625 kg
Total weight: 0.750 kg
Power: USB-C (cable not included)
Battery: 4 x AAA (not included)
Start up guide included
Exclusive medieval sticker pack included
Knobs to be affixed by customer (supplied separately, in same box)

Specifications

Sampling frequency: 46 kHz / 16-bit
Internal signal chain: 32-bit
128 MB total memory
96MB ROM SOUNDS
32MB user sample memory
9 built-in demo songs
High resolution sequencer
Built-in pocus
Fader
Pressure sensitive pads
Six stereo voices, or twelve mono
Runs on 4x AAA batteries with the option to be powered via USB-C

inputs and outputs

Stereo output
SYNC IN/OUT
TRS-A MIDI IN/OUT
USB-C

Dimensions and weight
240 mm x 176 mm x 16 mm
9.45 in x 6.93 in x 0.63 in
620 g / 22 oz

Electronic specifications

3.5 mm TRRS jacks
Stereo input: 24 bit
SNR: 96 dBA
Impedance: 6.5 kOhm
Analogue gain: 0 - 12 dBmax level: 8 dBu, 2.0 Vrms
Stereo Headphone/Line Output: 24 bit
SNR: 98 dBA
Max level: 5 dBu, 1.4 Vrms

MIDI input
MMA compliant pinout (type A)
opto-coupled

MIDI output:
MMA compliant pinout (type A)
Voltage: 3.3 V

Sync output
TIP: Sync 8th, 16th, 24 PPQN
RING: Start/Stop
Voltage: 3.3 V

Sync input
TIP: Sync 8th, 16th, 24 PPQN
Ring: Start/Stop
Voltage: 3.3 V
Max level: 10 V

Notes: Part of TipTop's exceptional series of Eurorack-format Buchla modules, the 264t provides four sample-and-hold circuits, plus a logic circuit designed to control polyphonic patches. Deceptively simple but surprisingly creative, like most Buchla modules.

Supplier's Notes:
Four independent sample-and-hold circuits, plus a specialized logic circuit for expediently implementing polyphonic patches.

Sample-and-hold's are essentially one-cell analog memories. They are useful for "remembering" the instantaneous value of a control voltage (a detected envelope, for example), for generating equally spaced steps from a constant slope input (as from a 281t envelope generator), and for converting any continuously changing voltage (a random voltage, for instance) into a series of discrete values.

The 264's sample-and-hold circuits have two operating modes: sample and track. In the sample mode, the value of the input is sampled and applied to the output whenever a pulse is received. The output remains at this value until the next pulse arrives. The track mode diers in that an input is applied to the output for the duration of the pulse. The output tracks the input until the end of the pulse and remains at a constant value until the next pulse.

To use the 264t as four independent channels set the separate/common switch to separate. A single CV can be set to all four channels by setting the operate/common to common and plug CV in the the back jack on the with right side.

The Model 264t includes a polyphonic adaptor, which performs the logic necessary to implement four-voice polyphony. Facilities are incorporated for fine tuning and f.m. modulating the oscillators; light emitters display the adaptor's operation.

Specifications:

Size: 18 HP - Depth: 45mm
Power: +12V 60mA / -12V 30mA

Notes: Part of Sonicware's Liven groovebox series, the 8bit Warps draws on retro 80s chiptune vibes to create a mini instrument with huge character and surprising range.

*** Update: New features of the version 3.0 firmware September 2023 ***

Added 6 effect types:
- Distortion
- Phaser
- Tremolo
- Ring Modulator
- Auto Wah
- Reverse Delay

Added the Sound Locking features

A sequence can be duplicated to double the length

Looping of chain playback is now possible

New preset 29 drum sounds that can be easily made drum patterns with the sound locking feature

And several bug fixes and improvements

Supplier's Notes:
The LIVEN 8bit warps combines an 8-bit waveform memory synthesizer with a step sequencer.

Carefully selected preset waveforms and editable user waveforms along with high-quality filters and effects can be used freely to create a wide spectrum of sounds. The LIVEN 8bit warps can generate classic retro game sounds of course, but its unique 8-bit sound can also be used in a range of music genres, including EDM, hip-hop, techno and rock.

Powerful functions for live electronic music performance include 16 physical control knobs, parameter locking for each sequencer step, a looper, and SYNC IN/OUT and MIDI IN/OUT connectors to make synchronized performance with other equipment easy.

All these powerful functions are in a device that weighs only 790 g. Play it anywhere at any time.

Size : 11.7 inch (W) x 6.92 inch (D) x 1.89 inch (H), 297mm (W) x 176mm (D) x 48mm (H)

Weight : 1.74lb., 790g

Accessories: Warranty

Power supply: AA batteries x 6, or 9V DC output AC adapter (1A or higher, EIAJ3 standard inner diameter 1.7mm outer diameter 4.75mm, center +)

Notes: Muxlicer is a sequential signal processor designed for add a huge range of special functions to your modular setup in the minimum space.

Muxlicer is divided in three main blocks: Digital Step Controller, Gate Generator and Analog Switch (a.k.a. Mux/DeMux).

The module is designed with high "function to HP ratio" philosophy, to have maximum flexibility in minimum space.

Notes: Protect and display:

The Glorious Vinyl Vault for vinyl collections

The Glorious Vinyl Vault not only protects records, but also displays them perfectly. It is the ideal combination of functionality, aesthetics and quality for vinyl collections. With practical drawers, the vinyl record cabinet offers a convenient way to browse through your records collection and display and organise them in an eye-catching way.

Sophisticated design for effortless browsing

The record storage cabinet is equipped with soft-closing drawers. Each drawer offers space for up to 80 valuable 12" records. The LPs are easily accessible at the back of the drawer thanks to the telescopic full-extension runner, making it easy to reach the desired albums. The back of the drawer is also steplessly adjustable for flexible record loading.

Modular solution for growing collections

With a total capacity of up to 160 12'' records (capacity may vary depending on the type of cover), the modular storage solution is ideal for vinyl lovers with a growing collection. The modular design allows a perfect combination with other Vinyl Vault modules or the Glorious Record Rack 330 series.

Secure and stylish

Pre-drilled mounting holes ensure secure wall mounting and stability (mandatory). Thanks to Glorious's high design and quality standards, installation is simple and can be completed in just a few steps. The Glorious vinyl LP storage system is supplied flat-packed including mounting materials.

Specifications

Features

Modular record storage cabinet with convenient drawers for flipping through records
Perfect for displaying and sorting your record collection
Capacity for up to 160 pcs. 12'' vinyl records (capacity may vary on type of cover)
Soft-closing drawers that each holds up to 80 pcs. 12" vinyl records
Vinyl drawers are on telescoping, full-extension hardware, so finding a record tucked in the back of the drawer is easy
Stepless adjustable drawer back panel for variable record capacity
Pre-drilled fixture holes for secure wall mounting (mandatory for safe installation)
Modular vinyl storage system matches further Vinyl Vault modules or also the Glorious Record Rack 330 series
Includes 4 felt glides for floor protection
Easy assembly in just a few steps with Glorious design & quality standards
Ships flat-packed, including assembly materials
Delivery without decoration

Technical Data

Material: Particle Board, MDF
External dimensions: 406(W) x 342(D) x 856(H) mm
Vinyl drawer dimensions: 368(W) x 260(D) x 240(H) mm
Weight: 17.90 kg
Recommended maximum load desk top: 34.5 kg
Recommended maximum load pull-out drawers: 24.5 kg each
Delivery without decoration

Notes: The AudioFuse X8 IN is an essential tool for recording producers and sound engineers who are looking for additional high-quality analogue inputs. By extending digital connectivity, AudioFuse X8 IN provides more channels for instruments and outboard gear. It enhances studio flexibility and scalability while preserving audio quality, accommodating the demands of modern music production and sound design. More specifically, an 8 Analog-to-ADAT input expander enables you to extend your synth and instrument array and have all your gear connected at once and ready to record in your DAW.

Efficient expansion

AudioFuse X8 IN provides 8 additional analogue line inputs, enhancing the connectivity of your existing audio setup without the unnecessary cost and clutter of a fully-featured audio interface.

Professional audio quality

AudioFuse X8 IN supports 8 channels of premium analogue-to-ADAT conversion up to 96 kHz and utilizes the best components available, ensuring your recordings maintain the highest fidelity.

Versatile installation

Designed as half-sized rack units, X8 IN comes with removable rack ears for flexible installation. This allows them to be used as desktop units or mounted in a standard rack setup, accommodating up to two units side by side for expanded setups.

Ease of use

Front-panel controls offer direct access to channel management, making setup and adjustments straightforward. Colourful VU meters provide clear visual feedback for monitoring levels.

Notes: Empowering music creators with the freedom to create wirelessly, TMA-2 Studio Wireless+ features W+ Link with ultra-low latency wireless and lossless audio, Bluetooth 5.0 with +80h playback, and a coiled hi-fi cable.

Free yourself from cables and unleash your creative flow with ultra-low latency wireless headphones.

Create wirelessly with no compromise:

Cable-like performance with ultra-low latency and uncompressed audio via W+ Link technology.

Hear all the details: Clear and natural sound representation tuned for music creation.

Stay in the zone for hours: Enhanced comfort via lightweight build, memory-foam cushions and ergonomic headband.

Go beyond the studio: Switch to Bluetooth mode for everyday listening with +80h playback, or plug directly into a headphone jack with the detachable cable.

Customise, replace and upgrade: The modular nature of TMA-2 Wireless+ allows for endless customisation and easy upgrades or replacements of individual parts.

Ultra-low latency, uncompressed wireless audio TMA-2 Studio Wireless+ delivers uncompressed 44.1kHz, 16-bit wireless audio with only 16ms of latency through the robust W+ Link connection.

Tuned for clarity and detail

Signature AIAIAI bio-diaphragm speaker designed for music creation with a critically acclaimed sound stage and clear, highly detailed sound representation.

Enhanced comfort Soft over-ear memory foam cushions covered with resilient, CO2 neutral, and highly comfortable Alcantarar, ideal for longer sessions in the studio.

Modular product design

These TMA-2 modular headphone system offers a customisable solution that adapts to your creative process. With interchangeable components such as ear pads, cables, and drivers, you can upgrade or change parts of your headphones to improve sound quality, comfort, or style.

Three audio connection modes

Use W+ Link for wireless music creation and studio work with 16 hours of playback Seamlessly switch to Bluetooth 5.0 with +80 hours of playback for everyday listening and inspiration, or plug in to a headphone jack with the included coiled hi-fi cable.

The TMA-2 Studio Wireless+ is a versatile professional headphone, featuring ultra-low latency and uncompressed audio, giving you the freedom to create wirelessly without compromising sound. Designed for today's dynamic creative workflow, it features enhanced comfort for long sessions and a clear and detailed sound representation. Featuring new W+ Link technology, added Bluetooth 5.0 with +80 playback, and a coiled hi-fi cable.

Packaging

Items per master: 10
Packaging weight (g): 664
Packaging width (mm): 235
Packaging height (mm): 210
Packaging depth (mm): 85
Product weight (g): 270

Specifications

Driver diameter (mm): 40
Resonance frequency (Hz): 80
Frequency range: 10Hz - 40kHz
Sensitivity (db @ 1mW): 97
Impedance (Ohm): 32
Rated power (mW): 40
Max power (mW): 100
Diaphragm material: Bio-cellulose
Magnet type: High-grade N45 Neodymium
W+ Link audio quality
Uncompressed 44.1kHz 16-bit
W+ Link operating range (m): 12
W+ Link latency (ms): 16
W+ Link headband playback time (hours): 16
W+ Link transmitter playback time (hours): 30
W+ Link transmitter charging time (hours): 3
W+ Link transmitter input: 3.5mm/6.3mm TRS jack
Bluetooth codec: AAC, SBC
Bluetooth version: 5
Bluetooth profiles: A2DP
Bluetooth operating range (m): 10
Charging time (hours): 3
Number of talk mics: 1
Talk mic frequency range: 100Hz - 10kHz
Responsible design: Main material
Speaker Units: Recycled ABS. Headband: Silicone + Recycled ABS. Earpads: Alcantara + PU foam.

Packaging material

Sleeves: Recycled paper, outer sleeve cradle-to-cradle certified. Bags: Recycled plastic.
Design for disassembly: Yes
Right to repair compliant: Yes
Repair parts available: Yes
Repair guides available: Yes

Notes: The full power of Mutable Instruments Elements packed into 18hp. It features jack lights that can be turned on/off via a jumper on the back. This module comes loaded with the most recent firmware, with the new Chords mode that unlocks a whole new world of potential.

Based on open source designs by emilie gillet under Creative Commons (CC-BY-SA) license.

Width: 18hp
12V: 130mA
-12V: 10mA

Notes: Rhythmi is a Eurorack drum sequencer that allows you to dial in your groove, and explore it by evolving the pattern and modulating the energy. It allows for rhythmic inspiration and creativity without the burden of step programming. The evolve parameter enables smooth transitions between related rhythms through the use of branches. New branches can be generated at the push of a button, loading up a whole new branch of related rhythms to explore. The Evolve parameter is the heart of Rhythmi, its inspiration, and defining feature. Allowing rhythms to shift, transform, and melt into one another.

The Clock Section provides internal or external clocking with division or multiplication. The Customize Section shapes individual drum elements through density and syncopation. The Global Section introduces macro-level control over the rhythm via the Energy, Evolve, Length and Swing parameters, dynamically shaping fills and variations. Rhythmi has a jumper cable connector on the back to pair up seamlessly with Beatsi, the drum voice it was designed alongside with.

Technical specs:

- Module Size: 3U X 14HP X 25 mm Deep.
- Current Draw: 120mA (170mA peak)@ 12V, 10mA@ -12V.

What's in the box:

1x Rhythmi module
1x User Manual
1x Power cable
4x Mounting screws

Notes: Beatsi is Omni-Tone's love letter to modular drums! Inspired by classic modular drum synthesis which uses the fundamental building blocks, Beatsi's timbres were created using the same methods, only digitally. Beatsi is not a sample player or a physical modeller, and it's meant to be that way.

Beatsi's interface allows for control over individual piece Timbre, Pitch, Decay, and Level. The timbres are organized into 3 kits: an orange (acoustic) kit, a blue (low-fi) kit, and a green (alien) kit. Within these kits the timbres blend smoothly into one another allowing for seamless modulation. Beatsi has two CV modulation inputs which are assignable to any and all parameters with individual attenuversion. Beatsi may be small, but it packs a serious punch.

Technical specs:

- Module Size: 3U X 8HP X 25 mm Deep.
- Current Draw: 160mA (180mA peak)@ 12V, 10mA@ -12V.

What's in the box:

1x Beatsi module
1x User Manual
1x Power cable
1x Jumper cable
4x Mounting screws

Notes: The Dual Stereo Gate (DXG) music synthesizer module is a Dual Stereo Low Pass Gate and Mixer. It follows in the footsteps of the QMMG, Optomix, RxMx, DynaMix, and LxD. Unlike its predecessors, the DXG is specifically oriented around mixing stereo signals, making it an important addition to any system containing modules like XPO, QPAS, Morphagene, Mimeophon, and other stereo modules by Make Noise or others.

Unique to the DXG is a new low pass gate circuit that does not use vactrols. This circuit is 100% analogue and its response was arrived at after many months tailoring it to meet or exceed the expectations that have been set by all the vactrol low pass gates that Make Noise has created over the years.

In the past, Make Noise produced the Dynamix module and Dynamics circuit in the 0-COAST, both of which are vactrolless LPGs; however, the DXG is a completely new approach which better implements the gentle single pole filtering of a low pass gate, while also emulating the slow decay and memory of the vactrol based low pass gate. This new circuit makes possible the consistency of response necessary for versatile stereo use, while also keeping the module small and affordable so that it can be a key part of just about any modular system.

As on all of Make Noise's low pass gates, the DXG's Control parameter is used to set both the amplitude and the frequency content of the sound that passes through it. The control parameter tends to open faster than it closes, imparting a subtle decay phase onto any envelope shape that is used to modulate it.

Unlike previous low pass gates made by Make Noise, all the DXG's inputs and outputs are stereo. Each set of inputs is normalled so that the left input can be used for a mono signal, sending a copy to both left and right outputs. The Auxiliary inputs are also a stereo pair with mono normalization. These normalizations allow for the DXG to be used as a simple three channel stereo mixer, with one or two of the channels additionally being used for dynamics control and note event generation. The Aux inputs can be used to chain together larger decentralized mixes using additional DXG modules, or X-PAN, Optomix, modDemix etc.

Features

- Make Noise's first Stereo Low Pass Gate

- Vactrol-free design for classic Low Pass Gate sounds, but with the balance and consistency needed for true Stereo

- Fully Stereo i/o for easy integration into a Stereo-equipped modular synthesizer

- All Left inputs normalled for easy use with Mono signals

- STRIKE Input allows use of Gate signal to trigger Low Pass Gate circuit, creating "plucking" or "pinging" sound from any Gate

- Summing stage with Stereo AUXiliary IN allows for chaining of multiple units, creating larger mixes

- Part of a decentralized mix console integrated throughout the system along with X-PAN, Optomix, XOH, etc.

- Pairs well with XPO, QPAS, Morphagene, Mimeophon, Spectraphon etc.

Width: 8hp
Power:
74mA @ +12V
86mA @ -12V
Module Depth (incl power cable): 43mm

Notes: The latest and greatest version of one of the most popular microphones around. XLR and USB connections both offer warm sound suitable for vocals, instruments and podcasting.

Supplier's Notes:
The NT1 5th Generation is a revolutionary studio condenser microphone that fuses the classic sound signature of the iconic NT1 with cutting-edge, next-generation technology. It features RODE's groundbreaking (patent-pending) Dual Connect output, offering both XLR and USB connectivity for incredible versatility, a world-first "unclippable" 32-bit float digital output, advanced digital signal processing, and more, all while delivering the same warm, silky character, extremely low noise, and high SPL handling that the NT1 is renowned for. The NT1 5th Generation is a true studio workhorse that excels on everything from vocals and speech, to guitar, piano, drums and percussion - the ultimate studio microphone.

The Iconic Original Studio Microphone, Reborn

The NT1 5th Generation is the latest evolution of the iconic NT1. First introduced in 1991, the NT1 is the world's most popular studio microphone, renowned for its warm, classic sound and incredible versatility. The NT1 5th Generation takes the much-loved and respected core of the NT1 and introduces state-of-the-art features while preserving the legendary sound quality that made the original the go-to microphone for countless creators. A perfect marriage of tradition and innovation.

Game-changing Connectivity

Featuring RODE's groundbreaking, patent-pending Dual Connect output, the NT1 5th Generation can either be connected to an audio interface or mixer via XLR or directly to a computer via USB for studio-grade, plug-and-play recording. Unprecedented flexibility for any studio setup.

Classic Sound on the Cutting-edge

The NT1 5th Generation delivers the same warm, silky character, extremely low noise, and high SPL handling capability that the original is revered for, with improved circuitry for even lower self-noise - an astonishingly low 4dBA, making it the world's quietest studio condenser microphone. When using the XLR output, it delivers the rich, classic studio condenser sound you know and love from the NT1. When using the digital output, you get this same sound plus a slew of cutting-edge features to further enhance your audio for recording pro studio sound directly into your computer.

The Digital Studio of the Future

The NT1 5th Generation features a professional-grade audio interface built into the microphone, which is perfectly optimised to preserve its pristine audio fidelity and also offers a range of highly innovative features for enhanced sound, including the ultra-low-noise, high-gain Revolution Preamp™, high-resolution (192kHz) A/D conversion and advanced digital signal processing. This is so much more than just a studio condenser microphone, it's an all-in-one digital recording solution.

The "Unclippable" Microphone

The NT1 5th Generation features a world-first 32-bit float digital output - a revolutionary recording format that allows you to record everything from a whisper to a scream, the softest guitar to the loudest drummer without having to worry about setting your gain - simply adjust your audio after recording and all the dynamics of your performance will be maintained, with zero risk of clipping or distortion. Gamechanger.

Versatility Like No Other

With its smooth frequency response, extremely low noise, high SPL handling, flexible connectivity options and powerful digital capabilities, the NT1 5th Generation offers versatility like no other studio mic. It excels in any recording application, from vocals and speech to guitars, drums to piano, and can fit into any workflow, from a solo bedroom recording setup to a professional studio.

Craft Your Sound

Craft your sound with advanced APHEXr audio processing, driven by the NT1 5th Generation's powerful on-board DSP. Add compression, a high-pass filter, noise gate, and the legendary APHEXr Aural Exciter™ and Big Bottom™ to your audio with ease using the free RODE Connect and RODE Central companion apps. Dial in the perfect sound with the touch of a button using the intuitive VoxLab™ editor or fine-tune each processor using the advanced editor.

Premium Components, Built to Last

Made from premium components, the NT1 5th Generation is built to the highest standard in RODE's state-of-the-art manufacturing facilities in Sydney, Australia. The HF6 capsule is precision manufactured to sub-micron tolerances to ensure the utmost consistency in tonality and frequency response and is internally shock-mounted for minimising external vibrations. The body is machined from rugged aluminium and is available in black or silver, with high-grade finishes that are extremely resistant to scuffs and scratches, ensuring the NT1 5th Generation is ready to take on the rigours of recording day in, day out.

Everything You Need to Start Recording

The NT1 5th Generation comes with everything you need to start recording in the box, including XLR and USB cables, and a studio-grade shock mount and pop filter for minimising unwanted artifacts in your recording caused by plosives, knocks and bumps.

Unlock More Creative Potential with the RODE App Suite

The NT1 5th Generation is compatible with a range of free RODE apps, including the RODE Central companion app, RODE Connect podcasting app and UNIFY streaming app, all of which allow you to configure settings, access the advanced DSP, update firmware and more.

Specifications

Acoustic & Electrical Specifications

Acoustic Principle: Pressure gradient
Active Electronics: JFET impedance converter with bipolar output buffer
Capsule: 1.00"
Polar Pattern: Cardioid
Address Type: Side
Frequency Range: 20Hz - 20kHz
Output Impedance: 100O
Maximum SPL: 142 dB SPL
Equivalent Noise (A-weighted): 4dBA
Sensitivity: -32 dB re 1 Volt/Pascal (25 mV @ 94 dB SPL) +/- 2 dB @ 1 kHz
Analogue Power Requirements: Via XLR: P48
Analogue Output Connection: 3-pin XLR

Digital Specifications

Digital Power Requirements: Via USB: 5V
Digital Output Connection: USB-C
Bit Depth: 24-bit / 32-bit floating point
Sampling Rate (kHz): 48 / 96 / 192
Processing: APHEX digital signal processing (only available at 48kHz / 24-bit)
Minimum OS Requirements: Windows 10 Mac OS 10.15

Mechanical Specifications

Weight (grams): 308

Dimensions (millimetres):
Length: 52
Width: 52
Height: 189

Box Contains

1 x NT1 5th Generation
1 x SC29
1 x XLR-6
1 x SM6

Notes: Feel the bass

With the Mackie CR8SBT subwoofer, you won't just hear the bass-you'll feel it, too. The CR8SBT houses an 8" polypropylene-coated woofer within an all-wood sealed enclosure. The result? You get powerful bass reinforcement that delivers the bottom end you've been dreaming of.

Add Bluetooth to any speakers

Effortlessly pair your CR8SBT subwoofer with any Bluetooth device for easy streaming. And get this: You can connect any powered speakers to the CR8SBT and play through the entire system from your Bluetooth device, effectively adding Bluetooth connectivity to any non-Bluetooth speakers you may already own.

Studio-Quality Sound

How else are you going to hear those deep 808s when you're mixing or listening to music? Adding the CR8SBT to your setup brings powerful low-end to your studio or home audio system. You'll know it when you feel it.

Sleek Cosmetics

Sounding great is only half the battle-your subwoofer and speakers should reflect your style, too. The sharp aesthetic of CR8SBT looks great in the studio, the bedroom or any home listening setup, and goes perfectly with CR Series monitors. Be bold and make it loud without sacrificing style.

Control It

All the control you need is always within reach. Mackie CR8ST includes a CRDV desktop remote that allows for separate control of the overall system output level and subwoofer output level. You'll never have to get up from your chair to adjust volume ever again.

Product features

Powerful CR Series sound for home studios, gaming and listening
Adds Bluetooth connectivity to any non-Bluetooth stereo speakers
8" polypropylene woofer and custom-tuned ports for deep bass extension
Flexible inputs and outputs: 1/4" TRS and RCA, plus Bluetooth connectivity
Adjustable crossover frequency that ranges from 40-180Hz
Polarity control
Included CRDV desktop volume remote to control your whole system

Notes: mBrane is a 4 channel midi to CV interface based on opensource Yarns. The device includes a 1.5m 3.5mm TRS to Midi male cable (Type B). This is the brand new Rev1.1 of the device which now features PSImidi which allows ANY type of TRS midi cable to be used on the input. Type A or B, male or female, all will work.

Running firmware 1.5
Multichannel MIDI to CV/Gate conversion

Yarns is a MIDI interface providing up to 4 channels of very accurate CV/Gate conversion, which can be assigned to up to 4 voices.

In single voice mode, note, velocity, modulation and aftertouch (or other CC) CV are produced, along with a gate, a trigger, and a clock/reset output.

In two voices mode, two channels of note, modulation or aftertouch CV are produced, along with two gates, and clock/reset outputs.

Finally, in four voices mode, four pairs of CV/Gate outputs are provided.

Each voice has a built-in digital LFO to interpret modulation wheel messages as a vibrato; can respond to pitch-bend messages; or can be smoothed with a glide/portamento control - no need for a dedicated module and patches to get the right response from a MIDI keyboard!

Monophonic and polyphonic

The 2 and 4-voice modes are available both in a "polyphonic" and "multitimbral" flavour. The former receives chords from one single MIDI channel and dispatches them to the voices; while the later provides independent monophonic parts - which can be addressed to different MIDI channels, keyboard ranges, or even velocity levels.

Various note priority modes (low, high, last) and polyphonic allocation schemes (voice-stealing, random, cyclic) allows you to fine-tune the CV/Gate conversion to your playing style.

With sequencing and note transformation...

Each part can generate sequences either through an arpeggiator/euclidean sequencer combo; or with a SH-101 style sequencer with step-by-step recording, storing up to 64 notes. The module can sync to an external MIDI clock, and generate a clock/reset output at any subdivisions of the MIDI clock.

...and even more advanced features.

Other unique features include support for microtunings (either through standard MIDI messages or from a selection of historical tunings or indian ragas), just intonation, and an audio output mode which can transform one, two, or four of the CV outputs into simple digital oscillators.

Notes: Delta-V is a fully analogue dual-channel function generator, featuring a dedicated VCA and LFO cycle switch for each channel. It packs a great deal of functionality in only 10HP, and will surely find use in almost every patch.

Generate envelopes, slew gates and signals, or run LFOs with precise control over attack and decay times. Using the SHAPE knob, Delta-v can create a wide range of envelopes, from very snappy exponential curves for percussion to logarithmic thumps for bass lines.

If VCA's input is unpatched, the module outputs a regular voltage envelope. When an audio signal is patched into the VCA input, the output signal becomes the audio signal amplified by the envelope.

Sending other envelopes or an LFO to VCA input lets you modulate those modulators, quickly creating complex control voltages that go beyond the usual attack-decay envelope.

Combine this with the SUM output, which sums the two channels, and the attenuverters, which can quickly attenuate or invert the signal, and you have a whole array of signal processing capabilities.

The TRIGGER input fires a Attack-Decay envelope, while the SLEW input will affect the rate of change of the signal.

The trigger for channel 1 and 2 can be linked together, so you can fire two envelopes with one patch cable.

Each channel has an End of Cycle output, (EOC) this outputs a short trigger at the end of each envelope cycle.

The output voltage ranges from -10 to +10 volts, set with handy output attenuverters.

The CYCLE switch starts looping the envelope, creating LFO's that go up to audio rate, and that can also be used as an interesting sound source.

There are many ways to utilise Delta-V.

Challenge yourself to explore new, unconventional territories!


Width: 10HP
Depth: 27MM
Power: +12V 70 MA
Power: -12V 70 MA
Power 5V: 0 MA

Notes: This is a new build of a micro sized Mutable Instruments Plaits called Knit.

These modules use tall bushing potentiometers to offer a more stable feel.

The module is fully assembled, tested, and calibrated. Eurorack power cable is included.

Width: 6HP
Depth: 25mm
Height: 3U
Power Consumption: 12V: 50mA -12V: 5mA

Notes: This is where Storm and Monsoon meet to create the latest improvements on the original Clouds design. With Typhoon you get all of the features of Storm combined with sliders and layout of Monsoon in 16hp. Typhoon runs the SuperParasites firmware, so no more having to swap between Parasites and Kammerl firmware options. Some of the notable features are:

Dedicated blend controls for Feedback, Panning, Mix, and Reverb (similar to Monsoon)

All eight modes from Parasites and Kammerl

Stereo VCAs

input/output mutes

Exponential and linear pitch controls

Universal CV routing and random CV signals

Comes with an exclusive black and gold panel, power cable and one year warranty.

Notes: Great value multi-effects pedal based on all of Zoom's extensive experience. Chain up to nine effects including amp emulation and cabinet simulation. A proper all-rounder offering a huge range of tones.

Supplier's Notes:
Jaw dropping effects combined with powerful amp modeling, the G6 is in a class of its own.

The culmination of 30 years of Zoom's engineering know-how, passion for audio and love of guitar. The G6 is brimming with some of the best sounds you'll ever hear.

Your sounds may be complex but building them shouldn't be. With easy-to-use, application driven technology, the G6's 4.3-inch color touchscreen lets you drag, drop and swipe your way to new sounds.

All the best amps in amp history are in here (and a few new ones, too), along with 70 pre-loaded, precisely recorded impulse responses (IR) and room to add more than 100 of your own.

The G6 also delivers the ultimate collection of Zoom's legendary guitar effects and tones, including brand new Distortion and Modulation effects.

The G6 has room for 240 patches, including 100 presets so you can build patches for each song in your repertoire and easily cycle through your setlist. Create patches of up to nine effects.

The four Play Modes on the G6 will change the touchscreen and footswitch layout to give you quick access to the controls you need.

In addition to the internal 45-second looper, you can insert an SD card and record a loop up to 2 hours long. Choose the groove you want from 68 internal rhythm patterns, styles and measures.

Portable, versatile, and packed with tonal possibilities, the G6 can be tucked into a guitar bag or backpack, and off you go.

The G6 has a mono input, stereo outputs with output volume control, a mono fx loop, aux in, control in and headphone out. Using the USB port, the G6 also functions as a 2in/2out audio interface for Mac and PC.

Wirelessly connect the G6 directly to the Handy Guitar Lab app via Bluetooth. Using the optional BTA-1 adaptor, you can browse and upload/download an endless assortment of amps, effects and artists patches as provided on Guitar Lab software. Guitar Lab is also available for both PC and Mac.

What's in the Box:

G6 Multi-Effects Processor
Zoom AD-16 AC adapter
Quick guide
Steinberg Cubase LE Software

Optional Accessories:

FP02M Expression Pedal
BTA-1 Bluetooth Adapter

Specs:

MAXIMUM NUMBER OF SIMULTANEOUS EFFECTS: 7
USER PATCHES: 240
SAMPLING FREQUENCY: 44.1 kHz
A/D CONVERSION:24-bit 128x oversampling
D/A CONVERSION: 24-bit 128x oversampling
SIGNAL PROCESSING: 32-bit
FREQUENCY CHARACTERISTICS: 20 Hz - 20kHz (+0.5 db/-0.5 dB) (10k load)
DISPLAY: 4.3" TFT color LCD (480x272)

Notes: Updated version of the hugely popular MSP3, now with Yamaha's Twisted Flare Port technology for improved low-end response. Small design with big sound thanks to 4-inch woofer and precise dome tweeter.

Supplier's Notes:
MSP3A powered monitor speaker provides faithful sound reproduction in a compact form

The MSP3, a compact reference monitor speaker loved for many years, has been renewed as the MSP3A. This new reference monitor is the first in this series to include our Twisted Flare Port technology and provides an even clearer and tighter low-end while also realizing faithful sound reproduction.

The built-in 22W power amplifier is optimized for the speaker unit, which comprises a 10 cm (4") woofer and a 2.2 cm (.87") tweeter, to achieve a clear and natural reference sound.

The cabinet features a refined, simple design and weighs a mere 3.6 kilograms (7.9 pounds), making it easy to reposition and carry to different locations. Just like its predecessor, this monitor has multiple input connectors and controls, and is compatible with a variety of optional brackets, making it useful for a wide range of uses. These include serious audio and music monitoring in settings from small-scale studios to broadcast and post-production suites, as well as monitoring audio from digital musical instruments and ICT devices, and surround sound playback.

Twisted Flare Port technology, which is included in the MSP3A for the first time in this series, is an aerodynamic sound control technology that we at Yamaha have created by leveraging our extensive subwoofer development experience. Using it, we apply aerodynamic sound analysis and flow visualization measurement technologies to pinpoint and control noise generation mechanisms. Noise-generating air flow turbulence at both ends of the port is suppressed by changing how the port widens from input to output and adding a twist to it. Suppressing turbulence reduces bothersome muddiness in the sound and lowers the amount of noise generated at the port ends. This strengthens the connection between the sound and main speaker and delivers clear, tight low frequencies along with pitch and rhythm.

Compared to the air turbulence generated by the "ordinary port" shown in pink on the left, turbulence is reduced and air flows smoothly through the Twisted Flare Port shown in blue on the right.

Featuring a 22-watt built-in amplifier and Twisted Flare Port for clearer bass, the MSP3A reference monitor produces sound that is faithful to the original. With a variety of inputs, controls and optional support brackets, the MSP3A is ideal for small studios, post-production, monitoring electronic instruments and surround reproduction.

General specifications:

Speaker type: 2-way powered speaker, Bass-reflex type (Twisted Flare Port)
Frequency response: (-10dB) 67Hz - 22kHz
Components- LF: 4" (10 cm) Cone, HF: 0.8" (2.2 cm) Dome
Crossover: 4kHz
Output power: 22W
Maximum Output Level (Measured peak, IEC noise@1m): 99dB SPL
Input sensitivity- LINE 1 : -10 dBu, 10kO (RCA), LINE 2 : +4.0 dBu, 10kO (Combo)
I/O connectors- LINE 1 : RCA, LINE 2 : Combo (XLR/TRS phone)
Indicators: Power ON (Green LED)
Power requirements (May vary depending on region): 120V 50/60Hz, 110 - 120V 50/60Hz, 230V 50/60Hz, 220 - 230V 50/60Hz, 220V 50Hz, 240V 50Hz
Power consumption: 30W
Others: Level control (LINE1, LINE2); Tone control (LOW = Center, REF = 100Hz : MIN -3.0 i 2.0 dB, MAX +3.0 i 2.0 dB; HIGH = Center, REF = 10kHz : MIN -3.0 i 2.0 dB, MAX +3.0 i 2.0 dB)
Dimensions: W- 144mm (5-5/8"), H- 236mm (9-1/4"), D- 166mm (6-5/8")
Net weight: 3.6kg (7.9 lbs.)
Accessories: Power cord, Owner's manual
Packaging: Single
Flying and mounting hardware: 2 x M5 (Depth 15)
Options: Mic stand adaptor BMS-10A, Free-angle clamp BAS-10, Wall mounting bracket BWS20-120 / BWS20-190, Ceiling bracket BCS20-150 / BCS20-210

Notes: The Jumble Henge is a 16 input stereo spectral mixer with a unique patch-based mixing interface in a compact space. Each input has a carefully tuned resonant analog filter and a unique fixed pan value, providing each sound its own space within the mix. There is a Mix control to adjust the depth of the filtering and a clean external stereo input for chaining with another mixer or extra sound source. Jumble Henge is a space efficient solution for creating rich stereo mixes from a number of both mono and stereo sources.

INPUTS
Vertical and horizontal patch position determines a source's spectral and stereo placement in the mix respectively.

Aside from centred inputs, every input sits in its own unique pan position, helping to keep a separation between sounds but building a complete stereo image when combined.

The centre right inputs of the top two rows are normalised to the centre left inputs. - i.e if just a left input is patched it will be effectively panned center.

Towards the highs the panning becomes wider - as the human ear better pinpoints direction at higher frequencies, whereas the lows remain more centred for a tighter, more focused sound.

MIX CONTROL
Mix control for the overall depth of the filters applied to the inputs. Note: a slight volume increase occurs near the centre of the dial.

EXTERNAL INPUT
An additional clean stereo input pair for chaining with another mixer or additional source. Right input normalised to left input to accomodate mono sources.

OUTPUTS
Stereo mix output, the sum of all 16 inputs.

Jumble Henge was designed in collaboration with Worng Electronics and is based on the 'SoundStage'.

Technical Specifications

Supply: +12V 70mA / -12V 70mA

Size: 8HP

Depth: 38mm

Notes: Reloop's compact Serato controller gives you two decks, compact jog wheels and performance pads in a portable format. Built-in sound card and included Serato DJ Lite software to help you get started instantly.

Supplier's Notes:
Small Size, Huge Possibilities

As lightweight as it is powerful, as compact as it is versatile - the Reloop Ready balances first-rate functionality in a practical design for DJs to perform at their highest level whilst maximizing portability and minimizing space. Its impressive feature set includes dedicated controls for track navigation, loops, effects, filters, EQs, master volume, cue section, key lock, sync, key sync, slip mode, censor, jump to the beginning of the track, and user mode.

Up to 9 Performance Modes with NEW Scratch Bank Support

The highly responsive jog wheels can be used for pitch bending, scratching, and fast searching within a track and the 16 large RGB pads give access to 9 different pad modes: Hot Cue, Auto Loop, Manual Loop, Sampler, Pitch Play, Scratch Bank, Loop Roll, and Beat Grid. With so much functionality packed into such a streamlined controller, the Reloop Ready punches way above its weight class as the premier solution for the home, mobile, and travelling DJs.

Plug-and-Play at Home or Away

With the specific needs of today's DJs in mind, the Reloop Ready was conceived by our world-class artists and developed in close partnership with industry leaders Serato for the smoothest connection and software integration possible - straight out of the box. Whether you're a hobby DJ, advanced DJ or a touring professional, the Reloop Ready provides a one-stop solution, giving DJs all the tools they need to perform - and even preparing incredible performances anytime, anywhere.

Stream Millions of Tracks

Furthermore, Serato's integration with streaming services such as Tidal, Soundcloud Go+, Beatport/Beatsource Streaming gives you access to millions of tracks for instant mixing, cutting and scratching.

Compact Convenience

Not only is the Reloop Ready fully USB bus-powered, it also boasts a full headphones cue section and 3.5mm jack, together with an RCA out port for direct connection to active speakers and sound systems. And for those who are conscious of saving space and even working on DJ sets while travelling, the Reloop Ready's innovative and sturdy design allows the unit to sit comfortably above your laptop keyboard while in use, keeping the overall footprint of your setup to a satisfying minimum.

Additional Connections & Cross Platform Support

For even more versatility, the Reloop Ready is also compatible with Algoriddim's djay Pro apps on iOS and iPadOS and can control smartphones, tablets or computers. Furthermore, when in iOS mode the Reloop Ready can be powered by both, a regular USB power supply or a power bank. So there are many options to make sure you never miss a beat.

HIGHLIGHTS:

High-performance compact controller for Serato
Full feature set: 16 large RGB pads, 9 performance modes incl. new Scratch Bank feature1, 2 FX units
Ideal as a home DJ solution and as a professional portable preparation device

Incl. USB cable, RCA cable, and instruction manual

Weight: 1,14 kg
Dimensions: 325mm (w) x 220mm (d) x 48mm (h)

Some modes require a paid Serato DJ Pro version or Pitch'N'Time Expansion pack

Notes: What It Is

Years ago, many RNC users pined for less invisible compression and requested that FMR Audio offer a more "colourful" compressor, suitable for bass guitar, drums and other sources in need of added sonic texture. In response, the FMR designer went to the RNC archives and resurrected a version of RNC software that had been rejected for release because it wasn't invisible enough! The result: a compressor reminiscent of some classic opto compressors used to just "level" the signal rather than tame every transient. To celebrate the RNLA's sonic "colour", a bright red knob* was chosen as a visual metaphor. Although the most recent version ships with a less ostentatious red-striped knob (not shown), the RNLA's sonic colour remains bolder than ever...

How It Sounds

"Thick" and "gooey" is how some customers have described the RNLA's sound. The RNLA is, admittedly, much "gentler" and not as apt to grab'n'run with the signal. Like an old-timey photocell, the RNLA is a little resistant to responding right away, but requires the signal to be there for a while to get the photocell to act. This action yields a soft musicality to the compressor's action that adds a desirable characteristic to the source signal.

How It's Done

The RNLA and the RNC share much of the same hardware, but run different algorithms to achieve the desired effect. The RNLA exercises the well-known dictum (among dynamic processor designers) that, after the static characteristics of the signal path, the main contributors to a processor's sound are the shapes of the attack & release envelopes. The RNLA's software then transforms the sidechain signal into a drive signal for the VCA that both slows things down a bit and totally reshapes the crisp and quick action of the RNC's "normal" mode. This reshaping (and slow down) are the primary sonic drivers behind the RNLA's "thick and gooey" sound!

Notes: MG-30 is the flagship modelling effect processor in the NuX range. Dual high speed processing offers accurate modelling of 30 different amplifier options, including bias tweaking for an extra dimension of response adjustment, all using the proprietary NuX TSAC-HD algorithm. Impulse response programming presents a choice of 8 guitar cabinets, 8 bass cabinets, 8 microphones in 3 different axis positions and even 3 acoustic guitar emulation profiles. Once the main guitar tone is programmed, there are 8 effects blocks which can be assigned to different positions in the signal chain, including WAH, CMP, GATE, EFX, EQ, MOD, DLY & RVB. An expression pedal covers wah and swell effects amongst other possibilities. Each has modes and/or parameters which can be adjusted and saved within the patch as needed. Real-time editing uses rotary encoders and switches, making for a natural and organic process and all prameters and graphics are displayed on a vibrant 4" colour display. Add to this a fully functioning USB audio interface, phrase looper, PC/Mac editor/librarian/updater, aux input, effects loop, drum machine and NMP-2 footswitch control and the MG-30 covers practically all bases. This unit provides all the processing power and audio quality that could be asked from any professional guitar processor at a fraction of the price of its component features.

Specifications:

Power supply: 9Vdc, 400mA pin-negative (adaptor included)
Inputs: 6.3mm jack (guitar), 3.5mm jack (aux input)
Outputs: 2 x 6.3mm jack (L/mono + R) to amp or mixer
Sends: returns: 6.3mm jack send (1k ohm) & return (220k ohm)
Headphone output: 3.5mm stereo jack
USB port: USB type-C for audio interface, PC/Mac editing & updating
Remote control connection: EXP1 TRS 6.3mm jack
Sampling format: 48kHz, 32-bit
Frequency response: 20Hz - 20kHz (i1dB)
Input impedance: 1M ohm
Output impedance: 1k ohm
Dynamic range: 110dB
Dimensions: 313 x 166 x 54mm
Weight: 1.5kg

The box for this item contains :

MG-30 multi-effects modeler pedal
1 x 9Vdc power adaptor (UK)
1 x NMP-2 dual footswitch (173.352UK)
1 x patch cable
1 x USB cable

Notes: Dual tidal modulator with max, min & mix outs

FranKinksTides is a 18hp dual Tides (based on the Swirls pcb layout) with the max/min circuit from Kinks and some switches for sync, quadrature, pll and fm operation . It can be a double/complex oscillator, a dual function generator or any combination of oscillator, Lfo and Envelope generator with lots of cv control plus some interesting cross-modulation and sync features.

Some improvements in version 1.2:

-Mix output is now buffered, no signal bleeding on single outs.
-Mix pot controls also the balance of the signals sent to the max/min circuit.
-Uni/bi switch now also determines the signal sent to FM1.
-Clock/sync switch has now a center OFF position, no need of plugging a dummy cable in the Clock1 when using Sheeps firmware to avoid ultra fast sound bank changes.
small improvements for DIY:
-Bigger font size on the pcb.
-Parts renumbered for easy DIY.

Original design by Emilie Gillet
Available assembled and DIY (pcb+panel)
+12v
-12v

Notes: Voltage-controlled Dual VCO/LFO - two oscillators independently set as VCO or LFO.

Features in VCO mode:
V/Oct tracking over 10 octaves
Through zero and linear FM
Sub-octave output
Hard & soft synchronization
VCA control and CV algorithms selection
Quantizer with various scales
20 algorithm-based synthesis types among:
Wave shaping
Phase modulation
Phase positioning of multiple waves
Up to 5 stacked oscillators in tunable unison
Self-sync with phantom oscillator
Additive synthesis (7 waves)
Variable bit reduction (bit-crushing)
Ring modulator with its own 2nd oscillator
Noise with LPF, BPF, or resonant filter
Features in LFO mode:
Simultaneous signal and trigger outputs
External wave synchronization
Clock controlled rate with voltage controlled multiplier and divider
CV and knob control of output level
Algorithm based wave engine with a selection of:
Wave shaping
Phase modulation
Random levels and vectors (also Brownian)
Randomly spaced triggers and waves
Display with contextual icons and instant reminder help text
LEDs indicating potentiometer vs. value matching, switch settings and output levels
Automatically saved settings for instant recall at power on
Firmware update by playing an audio file via the front panel
Compact and skiff-friendly module

The driving idea behind the Twin waves voltage-controlled dual oscillator/LFO is to offer two interesting oscillators in a skiff-friendly and compact size. To achieve that challenge, Klavis built the product's architecture on the concept of pre-defined algorithms, where the most useful configurations and their matching parameter are ready to use.

This MKII evolution brings a redesigned layout, additional knobs for more hands-on fun and semi-modular cross-patching between sections.

All of the original features are present: a top selection of synthesis techniques, each with their key parameter directly at hand, enriched by a full set of complementary features.

More than ever, the Twin Waves is versatility at its best.

Dimensions:

(mm) Height: 128.40, Width: 40.40, Depth: 21.00
(Inches): Height: 5.06, Width: 1.59, Depth: 0.83
Eurorack: Height: 3HE, Width: 8HP
Depth behind panel (no supply cable inserted)- 21.00mm, 0.83 inches

Current draw
+12V: 46mA
-12V: 18mA
+5V: 0mA

Notes: Endorphin.es Cockpit² is a 4-channel stereo mixer with side-chain ducking.

Key facts:

Increased headroom
Improved sound quality
The LEDs are blue/red instead of red/green (Daltonic friendly)
No TRRS jacks anymore
New aluminium knobs on the black module version

Power consumption:
240 mA +12V
75 mA -12V
0 mA 5V

Dimensions:
6 HP
38 mm deep

Notes: For podcasters, videographers, bloggers, journalists and more, the F2 is the perfect audio solution for creators on the move.

The F2 is incredibly small, but its audio quality will amaze you.

The F2 features 32-bit float recording technology, allowing you to record the loudest audio signals without worrying about clipping. It will also record the quietest signals in beautiful detail. And the best part is you don't have to worry about setting the gain. Just plug in the lav and hit record.

Once you start your recording, use the F2's HOLD switch to ensure you don't accidentally stop recording.

Screw-lock connectors keep your lav plugged-in securely no matter the situation.

With the F2 actors can record and playback their lines to perfect their delivery.

The F2-BT comes with built-in Bluetooth. And with the free Zoom F2 Control app the F2-BT can wirelessly start/stop recordings, display battery levels, adjust output volume, control lo-cut and more.

You can also pair the F2-BT with a Bluetooth timecode synchronization device to receive and write timecode to recorded files. See Bluetooth Control features here.

The F2 Editor for PC and Mac allows you to adjust settings, format SD cards and more. Simply connect your F2 or F2-BT via a USB cable and launch the editor. The USB connection also makes it easy to transfer files to your computer. See the F2 Editor features here.

Whether a stroll through your garden, or the whispers and shouts of a dramatic reading, the F2 provides crystal clear recordings.

The F2 can record up to 15 hours (14 hours on the F2-BT) with two AAA batteries.

Record on microSD, microSDHC, and microSDXC cards up to 512GB.

The LMF-2 omnidirectional lavalier microphone has a low-profiled design, captures high-quality audio, and includes a windscreen and lapel mic clip.

The F2 Field Recorder gives you the option to choose the recording format that works best for your projects. Choose from 44.1 kHz/32-bit float or 48 kHz/32-bit float mono WAV files.

The F2 Is Perfect For Recording Interviews Anywhere.

TECHNICAL SPECIFICATIONS

LMF-2
Lavalier mic
Connector: 3,5 mm stereo mini (with screw lock)
Directionality: Omnidirectional
Sensitivity: -32 dB/Pa at 1 kHz
Maximum sound pressure input: 115 dB SPL
Cable length: 160 cm

F2 / F2-BT
Input
Connector: 3,5 mm stereo mini (with screw lock) Supports plug-in power (2.5 V)
Input impedance: 2 k? or more
Maximum input level: -5,5 dBu
Output
Connector: 3,5 mm stereo mini (with screw lock)
Maximum output level: 20 mW + 20 mW (into 32 O load)
Recording media
Cards compatible with microSD/microSDHC/microSDXC specifications (Class 4 or higher, 512 GB maximum)
Recording formats
WAV, 44.1kHz/32-bit float, 48kHz/32-bit float Mono, BWF format supported WAV
USB
USB Typ-C
Note: Use a USB cable that supports data transfer. USB bus power is supported.
Mass storage operation: USB 2.0 High Speed
PC app operation: USB 2.0 High Speed
Power
2 AAA batteries (alkaline, lithium or rechargeable NiMH batteries)
AC adaptor
Bluetooth
Bluetooth Ver4.2

The above values are approximate. Continuous battery operation times were determined using in-house testing methods. They will vary greatly according to use conditions.

External dimensions: 57,5 mm (w) x 46,4 mm (D) x 22,4 mm (H)
Weight (main unit only): 32 g

Notes: A new generation in hardware sequencing.

Create - perform - control- Step up to an unparalleled level of connectivity and control.

The SQ-64 is an incredibly powerful and compact Polyphonic Step Sequencer with amazing hands-on intuitive controls and deep editing options to give you all the flexibility and sequencing power needed for all your musical projects.

With its 64 step pad Matrix, Crystal clear OLED display, sturdy and elegant aluminium body, a wealth of connections and a variety of modes and features, the SQ-64 will become the central piece of your music studio providing total and seamless control over all your instruments so you can focus on what matters most; your music!

Despite its compact size, the SQ-64 has unparalleled connectivity and will allow you to easily control, connect and make the most of all your analog and digital gear. MIDI IN (x1) and OUT (x2), micro USB type B, Sync IN & OUT, 3 Melody tracks each with MODULATION, PITCH and GATE outputs and a DRUM track with 8 individual trigger outputs for controlling analog synths, Eurorack, and drum machines.

Each of the Melody tracks (x3) has 16 Patterns of up to 64 steps each, and the Drum track (x1) has 16 Subtracks also with up to 64 steps each, that can be played, chained and edited in a variety of ways. Melody tracks and patterns can be edited in several modes (GATE, PITCH and MODULATION) so you can alter the information sent by your sequencer on each of these steps in many interesting ways. The DRUM track outputs can be fine-tuned to match the polarity and voltage of your connected device(s).

Its audio Sync In & Out connections will allow you to seamlessly control all your other KORG gear such as the volca synthesizer series, minilogue, monologue, minilogue xd, prologue and many others!

Whether you are into Analog synths, Eurorack semi-modular synths, Digital drum machines, or do everything on your DAW with digital plugins, the SQ-64 will give you instant and precise hands-on control of each and all of these.

The SQ-64 has 64 beautifully LED-lit Step button pads that not only let you see the whole picture at once, but also allow for super-fast and satisfactory editing with its encoder knobs and dedicated mode buttons that will simplify and speed up your workflow. Each step has graduated lighting; the higher the modulation value, the stronger the button lights up to give you a clear visual on what's going on in the sequence.

The OLED Display is crystal clear, bright and visible from any angle, so you can have access to all the information you need no matter whether you are making music at home, in the studio or playing live!

The 3 melody tracks include a MODULATION output, so every step on your sequence can be creating complex modulations on your gear of choice, greatly expanding your options and possibilities for sound creation.

It has never been easier to create polyphonic chords patterns, melodies, complex poly-rhythms and modulations on the fly and record them as data on each of the 64 project slots available.

The SQ-64 won't just allow you to create incredible sequences; it packs several features and modes that will let you edit on the fly and play any of your gear real-time.

The 64 pad Matrix can be also be used as a Keyboard, allowing for several layouts to be used for maximum flexibility (several scales can be assigned to any of these and a number of other parameters can be easily changed)

Keys: Your traditional piano layout.
Isomorphic: the notes are displayed symmetrically in rows, you can easily transpose the same chord pattern up and down without changing its shape
Octaves: one scale displayed in 3 different octaves on each row

Sequencer: 64 step sequencer with 3 melodic tracks with up to 8 note polyphony, and 16 monophonic rhythmic tracks

Tempo: BPM30.0 - 300.0

Inputs: MIDI IN connector (3.5mm stereo mini-phone jack, use a type-A MIDI converter cable), SYNC IN jack (3.5mm monaural mini-phone jack, 20V maximum input level)

Outputs: MIDI OUT1, 2 connector (3.5mm stereo mini-phone jack, use a type-A MIDI converter cable), SYNC OUT jack (3.5mm monaural mini-phone jack, 10V maximum input level), CV GATE output A/B/C jack (3.5mm monaural mini-phone jack, 10V maximum output level), CV PITCH output A/B/C jack (3.5mm monaural mini-phone jack, 10V maximum output level), CV MOD output A/B/C jack (3.5mm monaural mini-phone jack, 10V maximum output level), TRIG output 1~8 jack (?3.5mm monaural mini-phone jack, 10V maximum output level)

Power: USB bus power, or DC 9V AC Adapter ([- o +], separately sold)

Dimensions (W x D x H): 368 x 144 x74 mm / 14.49 x 5.67 x 2.91 inches

Weight: 1.0 kg / 2.20 lbs

Included items: Owner's Manual, USB cable

Accessories (separately sold): KA350 AC Adaptor, Patch cables MS-CABLE-18

Notes: The MCFx2 is ALM's state variable 'MCF' filter made double. It features 2 identical classic analog 3 pole state variable filter cores each with Low, High and Band Pass (or Notch) outputs. Direct and voltage control is provided for both filter cut offs and resonance. Switches allow the filters to function as one, with the 'Feed' switch internally routing audio from one filter to the other in series and the 'Link' switch linking the cut off controls for both filter cores. MCFx2 expands on the great sounding MCF filter to offer both serial and parallel functionality for stereo operation, dual peak, tighter slopes and other complex filtering set ups.

FREQUENCY CONTROLS
Sets the base frequency for the filter cut offs. The v/oct and frequency inputs are added to these.

RESONANCE CONTROL
Sets the level of resonant peaks atop the cut off frequencies. The resonance can get particularly aggressive going into self oscillation with the control past 12 o'clock.

OUTPUTS
Each filter output is 3 pole with an 18dB/oct slope.
Low - low pass filter outputs. Passes frequencies below the cut off.
High - high pass filter outputs. Passes frequencies above the cut off.
BP/Notch - band pass or notch filter outputs. Jumpers on the rear of the module select one or the other for each filter.
Passes frequencies within (BP) or outside (Notch) a narrow region around cut off frequency.

LINK BUTTON
Links the left cut off to parallel control both filters. The right controls will now set the max range of the right core. Both filters will track together when the right cut off is fully clockwise.

FEED BUTTON
Routes the output of the left filter core to the input of the right (unless patched), with the desired output filter type selected via jumper at the rear of the module.

FREQ INPUTS AND ATTENUATORS
Control voltage inputs here are combined with knob offsets to set the final cut off. Attenuversion control allows for both attenuation and inversion of the CV. Expects approx. -5V - 5V input.

RES INPUTS AND ATTENUATORS
Attenuated control voltage inputs here are combined with knob offsets to set the final resonance.
Expects approx. -5V - 5V input.

AUDIO INPUT 'In'
Signal inputs to the filter cores for processing.
Input sources may need to be attenuated, filter will drive from hotter input levels.
The Left input is normalised to the right (unless 'Feed' is enabled).

Notes: ***B-STOCK: Box damaged, product in perfect working order***


Effects masters Eventide serve up a lush bucket brigade chorus inspired by the analogue classics of the 70s and 80s. Three chorus voices plus MicroPitch detuning for stereo width and complexity.

Supplier's Notes:
Short Description: Stereo Bucket Brigade-style Tri-Chorus with Psychedelic Swirl; Eventide's lushest chorus ever! Product copy: Deep Modulation & Dreamy Textures

Inspired by the classic Tri-choruses and stompbox choruses of the 1970s and early 1980s, the TriceraChorus pedal pairs rich Bucket Brigade-style chorusing with Eventide's legendary MicroPitch detuning for a lushness that rivals the jungles of the late Cretaceous Period. TriceraChorus features three chorus voices and three unique chorus effects which can be used to create a wide stereo spread with pulsing waves of modulation. The innovative "Swirl" footswitch adds psychedelic flanging, phasing and Univibe-style tones. It has never been easier to dial in syrupy smooth deep modulation on guitar, bass, synths, strings, vocals and more.

Deep Modulation & Dreamy Textures

TriceraChorus has three chorus voices: Left, Center, and Right, which can be detuned to add even more depth. A three-phase LFO modulates the delay times for these voices, producing a dazzling movement across the stereo field. The combination of the three modulated delays creates a huge wash of chorus reminiscent of that big, dreamy '80s sound.

A Trifecta of Tone

Like the mighty three-horned Dino, TriceraChorus is a powerhouse of chorus offering three effect types complemented by detuning and Swirl. For a quintessential vintage chorus sound, set TriceraChorus to "Chorus" mode. If you need something with more complexity and movement, "Chorale" produces lush, heavenly choruses inspired by classic rackmount Tri-chorus units. For a more warbly, pulsing effect, try "Vibrato." Add detune for subtle pitch shifting sweetness. Engage the "Swirl" footswitch to get lost in a whirlpool of kaleidoscopic sound.

Notes: M-Caster Live is the ultimate portable audio solution for streaming on mobile devices. Plugin your mic, sweeten your sound with ContourFX and StreamFX, then stream in minutes. With ContourFX, your voice will reach new heights with studio-quality sound-shaping and enhancements. And with StreamFX, you can add fun voice-changing effects.

M-Caster Live is also packed with features like dedicated headset and media player inputs, USB connectivity, and user-selectable RGB lighting that looks amazing in any streaming setup.

On the go? Just plug in an external USB battery and you have an incredible mobile streaming platform. From streaming to podcasting, get pristine audio just about anywhere with M-Caster Live. Your followers will thank you.

Included accessories

USB Cable
1/8" TRS / Aux Cable
1/8" TRRS Cable (For Smartphones)
Power Supply

Notes: A tiny but powerful field recorder capable of recording two channels in extremely high resolution. Records directly to microSD via a pair of mic/line inputs, with up to 8 hours recording time from a pair of AA batteries.

Supplier's Notes:
The small and mighty field recorder

Small design, big sound

With 32-bit float recording, the F3 effortlessly captures the quietest raindrops and the loudest explosions. Its small footprint allows for this recorder to be placed anywhere, as you capture and monitor up to 192 kHz of high-quality audio.

Focus on the scene

When you're working in the field or on set, sound levels can fluctuate often and quickly. The F3 allows you to adapt to your scene without having to set the gain or worry about clipping. In post, you'll be able to work with your capture, regardless of extremely low or high levels.

Award winning audio

Featuring the dual A/D converters and low-noise preamps found in our professional F-Series recorders, the F3 guarantees high-quality recordings in any setting or situation.

Battle tested

The F3 is built with durable side bars, standard tripod mount and slide-resistant rubber feet ensuring that you can mount it on your gear or hide it in any scene. It's sturdy metal casing and locking XLR connectors is designed for use in a variety of environments.

Wav watching

Monitor your recordings with seamless accuracy as the F3 displays your audio as real-time waveforms.

Record & listen

The headphone output allows you to keep an ear on your recordings, plus a line output enables you to go to your camera or other gear.

The F3 is well-equipped for long location shoots or remote fieldwork, with a variety of power options and massive storage.

With two alkaline AA batteries, take advantage of over eight hours of battery life.

Set yourself up for an unlimited charge via the AD-17 AC adapter or USB power supply.

Use a micro SD card up to 1TB to record over 180 hours of audio at the highest possible sample rate/bit-depth.

30' of control

Versatile control options give your production more flexibility than ever. Stay out of the shot and record from a distance of up to 30-feet (10m) using the F3 control app for iOS and Android*.
*F3 control app for Android available Spring 2022.
BTA-1 Bluetooth adapter sold separately.

Audio interface & streaming

Connect your F3 to a computer or iOS device via USB as an audio interface and record or stream up to two channels in crystal-clear 24-bit/96 kHz resolution. The loopback function allows you to combine your computer's audio with the F3 inputs to complete the sound for your stream.
*Available in 32-bit float/ 96 kHz with a firmware update in Spring 2022.

What's in the box

F3 Field Recorder
AA Batteries (x2)
Quick Tour

Specifications

Input and output channels
Inputs - MIC/LINE (mono): 2
Outputs - LINE OUT: 1, PHONE OUT: 1
Inputs
MIC/LINE (MONO)

Connectors: 2 XLR (2: HOT)

Input gain: Adjustment unnecessary (dual AD converter circuits used)
Input impedance: MIC: 3 kO or more, LINE: 3 kO or more
Maximum input level: MIC: +4 dBu,
LINE: +24 dBu

Phantom power: +24/48 V, Combined channel total of 10 mA or less

Equivalent input noise: ?127 dBu or less (IHF-A) when waveform magnification is ×1024 with 150 ? input
Outputs

Line out

Connector: 1 stereo mini jack

Maximum output level: +1 dBu

Output impedance: 100O or less
Phone out
Connector: 1 stereo mini jack
Maximum output level: 50 mW + 50 mW (into 32 O load)

Output impedance: 15O or less
Recorder

Maximum simultaneous recording tracks: 2

Maximum simultaneous playback tracks: 2

Recording format: WAV - 44.1/48/ 88.2/96/192 kHz, , 32-bit float mono/stereo,
BWF and iXML formats supported
Recording media: 4 - 32 GB cards compatible with the microSDHC specification

64 GB - 1 TB cards compatible with the microSDXC specification

Display: LCD with backlight (96×64 resolution)

USB
Connector: USB Type-C - Use a USB cable that supports data transfer. USB bus power is supported.

Audio interface operation:
USB 2.0 High Speed, 44.1/48/88.2/96 kHz, 24-bit, 2-in/2-out
Mass storage operation: USB 2.0 High Speed
Remote

Dedicated wireless adapter (ZOOM BTA-1)

Power:
2 AA batteries (alkaline, NiMH or lithium)
AC adapter (ZOOM AD-17): DC 5 V/1 A
USB bus power is supported

Notes: Black version of Audio-Technica's entry-level DJ turntable, updated to feature an improved direct-drive motor. Built-in phono preamp and USB audio interface make it easy to connect to any mixer, powered speakers or computer.

Supplier's Notes:
AT-LP120XUSB Direct-Drive Fully Manual Turntable

This update of the AT-LP120-USB turntable features a new DC servo direct-drive motor, along with adjustable dynamic anti-skate control and selectable phono preamplifier. The fully manual turntable plays 33-1/3, 45, and 78 RPM records and is equipped with a USB output that allows direct connection to your computer. Just download the free Mac- and PC-compatible Audacity recording software (or software of your choice) and start converting your records to digital audio files.

But in addition to the USB output, the turntable also comes with a detachable dual RCA output cable and is equipped with a built-in selectable phono preamp so you can connect directly to your home stereo, whether it has a dedicated phono input or not. The turntable features an S-shaped tonearm with adjustable tracking force and an AT-HS6 universal 1/2"-mount headshell with an AT-VM95E Dual Magnet phono cartridge.

Audio-Technica has been a leader in phono cartridge design for more than 50 years, and that expertise shows in the versatile, high-performance AT-VM95E cartridge, which comes with a 0.3 x 0.7 mil elliptical stylus, but is also compatible with any VM95 Series replacement stylus, offering a wide choice of options for every budget and application. Additional features include a die-cast aluminium platter with felt mat; a start/stop button; selectable high-accuracy quartz-controlled pitch lock and pitch change slider control with +/-8% or +/-16% adjustment ranges; a stroboscopic platter with speed indicator; a removable plug-type stylus target light; external power supply; and a removable hinged dust cover.

Analogue or USB Connection

Next-Generation Analogue/USB Turntable

An update of the critically acclaimed AT-LP120-USB, this turntable features a new DC servo direct-drive motor, along with adjustable dynamic anti-skate control and selectable phono preamplifier.

Plays 33-1/3 RPM, 45 RPM and 78 RPM Records

USB and Analogue Output

Built-in Switchable Phono Pre-Amplifier

AT-VM95E Dual Magnet Phono Cartridge

Taking Your Vinyl to the Next Level

High-Fidelity Home Audio

Whether using with your home stereo system or your computer, the AT-LP120XUSB's professional controls give you the power to shape your high-fidelity listening experience.

Cartridge Assembly Line Circa 1962

Half a Century of Stunning Analogue Sound

Audio Technica was started in Tokyo in 1962, designing and manufacturing high-performance phono cartridges. That half-century's worth of analogue expertise goes into every turntable produced, ensuring you get the best listening experience from your vinyl.

Specifications

Turntable

Type: 3-speed, fully manual operation
Motor: DC servo motor
Drive Method: Direct drive
Speeds: 33-1/3 RPM, 45 RPM, 78 RPM
Turntable Platter: Die-cast aluminum
Starting Torque: >1.0 kgf.cm
Braking System: Electronic brake
Wow and Flutter: <0.2% (WTD) @ 3 kHz (JIS)
Signal-to-Noise Ratio: >50 dB
Output Level: Pre-amp "PHONO": 4 mV nominal at 1 kHz, 5 cm/sec
Pre-amp "LINE": 240 mV nominal at 1 kHz, 5 cm/sec
Phono Pre-Amp Gain: 36 dB nominal, RIAA equalized
USB Function: A/D, D/A - 16-bit/44.1 kHz or 48 kHz USB selectable;
Computer interface: USB 1.1 Compliant Windows 7 or above, or MAC OS X or above
Power Supply Requirements: 100 to 240 V, 50/60 Hz, 1.5A Max.
Dimensions: 452.0 mm (17.80") W x 352.0 mm (13.86") D x 141.6 mm (5.57") H
Weight: 8 kg (17.6 lbs.), without dust cover
Accessories Included: AT-VM95E phono cartridge; AT-HS6 headshell; 1.9 m (6.2') USB cable; dual RCA (male) to dual RCA (male) cable with ground wire; counterweight; felt mat; dust cover; 45 RPM adapter; plug-type stylus target light

Notes: Updated version of Audio-Technica's excellent entry-level DJ turntable, featuring an improved direct-drive motor. Built-in phono preamp and USB audio interface make it easy to connect to any amplifier, powered speakers or computer.

Supplier's Notes:
AT-LP120XUSB Direct-Drive Fully Manual Turntable

This update of the AT-LP120-USB turntable features a new DC servo direct-drive motor, along with adjustable dynamic anti-skate control and selectable phono preamplifier. The fully manual turntable plays 33-1/3, 45, and 78 RPM records and is equipped with a USB output that allows direct connection to your computer. Just download the free Mac- and PC-compatible Audacity recording software (or software of your choice) and start converting your records to digital audio files.

But in addition to the USB output, the turntable also comes with a detachable dual RCA output cable and is equipped with a built-in selectable phono preamp so you can connect directly to your home stereo, whether it has a dedicated phono input or not. The turntable features an S-shaped tonearm with adjustable tracking force and an AT-HS6 universal 1/2"-mount headshell with an AT-VM95E Dual Magnet phono cartridge.

Audio-Technica has been a leader in phono cartridge design for more than 50 years, and that expertise shows in the versatile, high-performance AT-VM95E cartridge, which comes with a 0.3 x 0.7 mil elliptical stylus, but is also compatible with any VM95 Series replacement stylus, offering a wide choice of options for every budget and application. Additional features include a die-cast aluminium platter with felt mat; a start/stop button; selectable high-accuracy quartz-controlled pitch lock and pitch change slider control with +/-8% or +/-16% adjustment ranges; a stroboscopic platter with speed indicator; a removable plug-type stylus target light; external power supply; and a removable hinged dust cover.

Analogue or USB Connection

Next-Generation Analogue/USB Turntable

An update of the critically acclaimed AT-LP120-USB, this turntable features a new DC servo direct-drive motor, along with adjustable dynamic anti-skate control and selectable phono preamplifier.

Plays 33-1/3 RPM, 45 RPM and 78 RPM Records

USB and Analogue Output

Built-in Switchable Phono Pre-Amplifier

AT-VM95E Dual Magnet Phono Cartridge

Taking Your Vinyl to the Next Level

High-Fidelity Home Audio

Whether using with your home stereo system or your computer, the AT-LP120XUSB's professional controls give you the power to shape your high-fidelity listening experience.

Cartridge Assembly Line Circa 1962

Half a Century of Stunning Analogue Sound

Audio Technica was started in Tokyo in 1962, designing and manufacturing high-performance phono cartridges. That half-century's worth of analogue expertise goes into every turntable produced, ensuring you get the best listening experience from your vinyl.

Specifications

Turntable

Type: 3-speed, fully manual operation
Motor: DC servo motor
Drive Method: Direct drive
Speeds: 33-1/3 RPM, 45 RPM, 78 RPM
Turntable Platter: Die-cast aluminum
Starting Torque: >1.0 kgf.cm
Braking System: Electronic brake
Wow and Flutter: <0.2% (WTD) @ 3 kHz (JIS)
Signal-to-Noise Ratio: >50 dB
Output Level: Pre-amp "PHONO": 4 mV nominal at 1 kHz, 5 cm/sec
Pre-amp "LINE": 240 mV nominal at 1 kHz, 5 cm/sec
Phono Pre-Amp Gain: 36 dB nominal, RIAA equalized
USB Function: A/D, D/A - 16-bit/44.1 kHz or 48 kHz USB selectable;
Computer interface: USB 1.1 Compliant Windows 7 or above, or MAC OS X or above
Power Supply Requirements: 100 to 240 V, 50/60 Hz, 1.5A Max.
Dimensions: 452.0 mm (17.80") W x 352.0 mm (13.86") D x 141.6 mm (5.57") H
Weight: 8 kg (17.6 lbs.), without dust cover
Accessories Included: AT-VM95E phono cartridge; AT-HS6 headshell; 1.9 m (6.2') USB cable; dual RCA (male) to dual RCA (male) cable with ground wire; counterweight; felt mat; dust cover; 45 RPM adapter; plug-type stylus target light

Notes: Five-channel mixer with mutes, built-in VCA, switchable overdrive and LED level meter. Simple, straightforward, high-quality stuff from AJH.

Supplier's Notes:
The MiniMod Muting Mixer & VCA is a 10HP wide, five channel audio mixer with many useful features. It is available with either a black (Dark Edition), or a silver front panel.

The mixer section has five input channels, and each channel includes a bi-colour tactile LED switch that can instantly mute or un-mute the channel, replicating the oscillator on/off switches on the original Model D synthesiser. This arrangement is more convenient than regular switches as each illuminated switch shows the on/off status of the associated channel and multiple buttons can be pressed at once, making it very useful for live performance.

AJH have also included a four segment LED level meter so that the overall level can be seen at a glance and adjusted to prevent the output from getting too "hot" and causing distortion in other modules further downstream.

It also features a VCA that is integrated into the output section, and this can be switched from linear to exponential response - this allows it to be used as a voltage controlled sub mixer or as a stand alone VCA with five inputs.

Lastly, AJH added a wonderfully soft and warm sounding overdrive circuit that can be switched in to add smooth, tube like distortion. This works in a similar fashion to a master volume guitar amplifier, so the amount of overdrive can be varied widely with different settings of channel and master output levels.

Module Width: 10hp
Module Depth: 26mm (Including power lead)
Current Usage: 55mA Positive, 25mA Negative
