Back catalogue: Studio Equipment

Notes: Use these black cables with the 1010music logo on either end of the jack to connect your 1010music eurorack modules to other modules that also use stereo minijack connections. This is a TRS cable with male 3.5mm minijacks on either end. It is available in two lengths: 30cm/11.75" and 60cm/23.5". These cables can be used for connections between any two 1010music modules, and to any other modules that use a compatible mapping of MIDI signals to stereo minijack connectors.

Weight: 0.04 lbs
Dimensions: 4 × 3.5 × 0.25 in
Length: 30 cm / 11.75"
Pack size: single

Notes: Use these black cables with the 1010music logo on either end of the jack to connect your 1010music eurorack modules to other modules that also use stereo minijack connections. This is a TRS cable with male 3.5mm minijacks on either end. It is available in two lengths: 30cm/11.75" and 60cm/23.5". These cables can be used for connections between any two 1010music modules, and to any other modules that use a compatible mapping of MIDI signals to stereo minijack connectors.

Weight: 0.04 lbs
Dimensions: 4 × 3.5 × 0.25 in
Length: 60 cm / 23.5"
Pack size: 5 Pack

Notes: You can now update your Bitbox mk1 or mk2 with a black faceplate. Now you can have an all black rack and have digital sampling capabilities. This is just the faceplate.

Give your module a facelift

These replacement faceplates are designed for use with the module in the traditional orientation with the screen on top. These are the same faceplates used when manufacturing our modules, but now in black. They are anodized aluminium with a bead blasted finish.

Swapping out a faceplate is easy to do, and requires a small wrench or pliers. Here are the steps to replace a faceplate:

Remove the module from the rack.
Use a small wrench or pliers to remove the small round nuts around each of the mini jacks. Note that these nuts have a notch on the top side of them. This notch fits into a specialized tool that can be used to remove these nuts more easily.
Gently tug on the four knobs to pull them off.
Use a small wrench or pliers to remove the hex nuts from the knob stems.
Remove the washers from the knob stems.
Gently pull up on the faceplate and it will slide off easily.
Place the new faceplate on the module.
Replace the washers on the knob stems.
Use a small wrench or pliers to replace the hex nuts on the knob stems.
Use a small wrench or pliers to replace the small round nuts around each of the mini jacks. Note that the notch should be on the top side of the nuts, the side away from the faceplate.
Look at the underside of the knobs and the post that they rest on. You will see that the knobs are keyed. Line up the flat edge of the hole in the knob with the flat edge of the post, and then push the knob onto the post. If you have the knob aligned properly, it should go on with moderate pressure. If it seems to require more force, please check the alignment.

Weight: 0.19 lbs
Dimensions: 5.5 × 5 × 0.25 in
Touchscreen product: bitbox, fxbox, synthbox, toolbox

Notes: Innovative little sampler groovebox. Works as a standalone unit or as a sequencer for other gear. A nice left-field alternative to the usual MPCs and Electribes.

Supplier's notes:
Blackbox is a portable sampler and groovebox that lets you record, save/load, apply effects and edit one-shot samples and beat-sliced loops. Create sequences with samples by tapping on pads, playing a virtual keyboard, using external MIDI controllers or by drawing-in notes using a standard Piano Roll editor on a fast touchscreen interface. Sequences can be played back to create song sections and entire compositions. Finish your song by mixing it, adding stereo effects and by saving it as a Preset for fast and easy recall.

Perform songs live and trigger samples on the fly. Blackbox makes it easy to create and perform music anywhere thanks to its compact and rock-solid hardware design. Just throw it in a backpack and hit the club.

Record hours of song ideas, jam sessions, and performances thanks to a microSD slot that enables you to expand internal memory.

Blackbox comes with gigabytes of premium samples and loops by SoundTrack Loops and Loopmasters to let you start making beats right out of the box.

Blackbox - your own personal sampler.

What Is Included:

- Blackbox compact sampling studio
- MicroSD card with blackbox firmware, about 60 presets and approximately 900 WAV files
- USB power cable and USB wall wart with 3 international adapters
- 2 MIDI Adapters - Male 3.5mm TRS to Female 5 pin DIN, MIDI Class B standard
- Quick Start guide to get you playing right away

Notes: These knobs fit all 1010music products. Replace your damaged knobs or just swap them for a different colour. These knobs will fit blackbox, bluebox, the nanoboxes, bitbox mk1, bitbox mk2, bitbox micro, bluebox Eurorack edition, and Waverazor Dual Oscillator. They are sold in single colour packs of 4.

These are the official knobs used on 1010music products since the release of the bluebox. They fit the stems of the potentiometers on all current and past 1010music products. They come in packs of 4, all one colour.

Each knob is 0.65" / 18 mm high with a base diameter of 0.65" / 18 mm.

Notes: These knobs fit all 1010music products. Replace your damaged knobs or just swap them for a different colour. These knobs will fit blackbox, bluebox, the nanoboxes, bitbox mk1, bitbox mk2, bitbox micro, bluebox Eurorack edition, and Waverazor Dual Oscillator. They are sold in single colour packs of 4.

These are the official knobs used on 1010music products since the release of the bluebox. They fit the stems of the potentiometers on all current and past 1010music products. They come in packs of 4, all one colour.

Each knob is 0.65" / 18 mm high with a base diameter of 0.65" / 18 mm.

Notes: These knobs fit all 1010music products. Replace your damaged knobs or just swap them for a different colour. These knobs will fit blackbox, bluebox, the nanoboxes, bitbox mk1, bitbox mk2, bitbox micro, bluebox Eurorack edition, and Waverazor Dual Oscillator. They are sold in single colour packs of 4.

These are the official knobs used on 1010music products since the release of the bluebox. They fit the stems of the potentiometers on all current and past 1010music products. They come in packs of 4, all one colour.

Each knob is 0.65" / 18 mm high with a base diameter of 0.65" / 18 mm.

Notes: These knobs fit all 1010music products. Replace your damaged knobs or just swap them for a different colour. These knobs will fit blackbox, bluebox, the nanoboxes, bitbox mk1, bitbox mk2, bitbox micro, bluebox Eurorack edition, and Waverazor Dual Oscillator. They are sold in single colour packs of 4.

These are the official knobs used on 1010music products since the release of the bluebox. They fit the stems of the potentiometers on all current and past 1010music products. They come in packs of 4, all one colour.

Each knob is 0.65" / 18 mm high with a base diameter of 0.65" / 18 mm.

Notes: A digital mixer at heart but so much more. 1010's unique take on mixing and recording includes built-in effects and EQ, compression, headphone/monitor mixes and output routing. Clever stuff.

Supplier's Notes:
Bluebox is the portable digital audio mixer that lets you get the most out of your electronic music gear. Connect your eurorack, sampler, drum machine and synthesizer outputs to 6 stereo, 3.5 mm TRS inputs and map them to 12 mono tracks or 6 stereo tracks, all with independent control for recording and playback. It's that keyboard mixer with live performance features that you always hoped someone would make.

Connect the output of your electronic music gear to Bluebox, and then route each track independently to the three outputs and effects sends. Each track offers control of volume, gain, 4 band parametric EQ, pan, mute and solo functions. Apply high-quality global reverb and delay effects along with 4 band EQ per track to add new depth to your sound with total control to quickly tweak incoming audio or track playback as needed.

With Bluebox you can record independent tracks or the Main mix using a standard microSD card. Capture your jam session for later review, or record the ultimate mix of the tracks for your song.

Bluebox's compact 5.5h x 5h x 2h case lets you tuck it into a crowded tabletop studio or throw it in your pack for the next gig.

Interact with the dynamic visual interface on the 3.5h touchscreen along with physical knobs, navigation buttons and transport buttons to quickly access the most important functions. MIDI input and output allow you to sync the clock with external gear for synchronized effects and metronome.

Add Some Colour to Your Mix:
Mix 12 mono/6 stereo tracks of live or prerecorded sound.
Independently route each track to any combination of three stereo TRS outputs:

Stereo Output 1 - Main mix
Stereo Output 2 - Assignable, with dedicated sub-mixer (pre or post fader)
Stereo Output 3 - Headphone output, with dedicated sub-mixer (pre or post fader)
Control one parameter for multiple tracks at once in Mixer mode.
Focus on one track at a time in Track mode.
Adjust the level or mute state of each output independently.
Use touch gestures or knobs to tweak your sound with four band EQ per track with support for Low Cut/Low Shelf, Parametric, and High Shelf/High Cut settings for each band.
Apply high-quality Reverb and Delay effects with independent effects sends for each track.
Override the headphone output with the Main mix on demand.
Maximize the loudness and unify your mix with the built-in global compressor
Sync to external clocks through the MIDI Input and Output.
Record hours of music as 48k, 24 bit WAVs directly to the microSD card as multi-track or as the main stereo mix.
Playback a previously recorded track while recording new ones.
Load firmware updates through the microSD card.
Mix electronic music gear such as the 1010music blackbox, eurorack modules, drum machines, samplers and synthesizers.
Save and recall Project settings including all parameters for tracks, outputs, EQ and effects.
Copyright 1010music LLC 2020 --- CONFIDENTIAL ---
Copyright 1010music LLC 2020 --- CONFIDENTIAL UNTIL 10/10/2020 ---
Fit it into a small spot on your desk and then tuck it in your pack for the next gig.

What is Included:
Bluebox digital recording mixer
A microSD card with bluebox firmware and pre-loaded project files
A USB power cable and AC adapter with 3 international adapters
2 MIDI Adapters . Male 3.5 mm TRS to Female 5 pin DIN, MIDI Class B standard
A Quick Start guide to show you the basics (full user manual available online)

Specs:
6 stereo 3.5 mm TRS inputs
12 mono tracks, 6 stereo tracks or something in between
3 independently controlled stereo 3.5 mm TRS outputs
3.5h touch screen, 4 knobs, 8 navigation buttons and 3 transport buttons
3 effects: reverb, delay and compressor
Records and plays back 48k, 24-bit audio WAV files
4 band EQ per track
MIDI In and Out for beat syncing effects
Dimensions: 5.5 x 5 x 2 (14 cm x 13 cm x 5 cm), 1 lb (450 grams)
Durable aluminum case

Notes: ***B-STOCK: Paint chip on some parts***


A digital mixer at heart but so much more. 1010's unique take on mixing and recording includes built-in effects and EQ, compression, headphone/monitor mixes and output routing. Clever stuff.

Supplier's Notes:
Bluebox is the portable digital audio mixer that lets you get the most out of your electronic music gear. Connect your eurorack, sampler, drum machine and synthesizer outputs to 6 stereo, 3.5 mm TRS inputs and map them to 12 mono tracks or 6 stereo tracks, all with independent control for recording and playback. It's that keyboard mixer with live performance features that you always hoped someone would make.

Connect the output of your electronic music gear to Bluebox, and then route each track independently to the three outputs and effects sends. Each track offers control of volume, gain, 4 band parametric EQ, pan, mute and solo functions. Apply high-quality global reverb and delay effects along with 4 band EQ per track to add new depth to your sound with total control to quickly tweak incoming audio or track playback as needed.

With Bluebox you can record independent tracks or the Main mix using a standard microSD card. Capture your jam session for later review, or record the ultimate mix of the tracks for your song.

Bluebox's compact 5.5h x 5h x 2h case lets you tuck it into a crowded tabletop studio or throw it in your pack for the next gig.

Interact with the dynamic visual interface on the 3.5h touchscreen along with physical knobs, navigation buttons and transport buttons to quickly access the most important functions. MIDI input and output allow you to sync the clock with external gear for synchronized effects and metronome.

Add Some Colour to Your Mix:
Mix 12 mono/6 stereo tracks of live or prerecorded sound.
Independently route each track to any combination of three stereo TRS outputs:

Stereo Output 1 - Main mix
Stereo Output 2 - Assignable, with dedicated sub-mixer (pre or post fader)
Stereo Output 3 - Headphone output, with dedicated sub-mixer (pre or post fader)
Control one parameter for multiple tracks at once in Mixer mode.
Focus on one track at a time in Track mode.
Adjust the level or mute state of each output independently.
Use touch gestures or knobs to tweak your sound with four band EQ per track with support for Low Cut/Low Shelf, Parametric, and High Shelf/High Cut settings for each band.
Apply high-quality Reverb and Delay effects with independent effects sends for each track.
Override the headphone output with the Main mix on demand.
Maximize the loudness and unify your mix with the built-in global compressor
Sync to external clocks through the MIDI Input and Output.
Record hours of music as 48k, 24 bit WAVs directly to the microSD card as multi-track or as the main stereo mix.
Playback a previously recorded track while recording new ones.
Load firmware updates through the microSD card.
Mix electronic music gear such as the 1010music blackbox, eurorack modules, drum machines, samplers and synthesizers.
Save and recall Project settings including all parameters for tracks, outputs, EQ and effects.
Copyright 1010music LLC 2020 --- CONFIDENTIAL ---
Copyright 1010music LLC 2020 --- CONFIDENTIAL UNTIL 10/10/2020 ---
Fit it into a small spot on your desk and then tuck it in your pack for the next gig.

What is Included:
Bluebox digital recording mixer
A microSD card with bluebox firmware and pre-loaded project files
A USB power cable and AC adapter with 3 international adapters
2 MIDI Adapters . Male 3.5 mm TRS to Female 5 pin DIN, MIDI Class B standard
A Quick Start guide to show you the basics (full user manual available online)

Specs:
6 stereo 3.5 mm TRS inputs
12 mono tracks, 6 stereo tracks or something in between
3 independently controlled stereo 3.5 mm TRS outputs
3.5h touch screen, 4 knobs, 8 navigation buttons and 3 transport buttons
3 effects: reverb, delay and compressor
Records and plays back 48k, 24-bit audio WAV files
4 band EQ per track
MIDI In and Out for beat syncing effects
Dimensions: 5.5 x 5 x 2 (14 cm x 13 cm x 5 cm), 1 lb (450 grams)
Durable aluminum case

Notes: A 4 ft Type B MIDI Adapter

This cable enables you to connect MIDI devices that use standard MIDI cables to the stereo minijacks that use the Type B standard. The adapter cable has a male stereo minijack at one end, and a male 5 pin DIN MIDI connector on the other, and is 1.42 meters/4' 8" long. It is also useful as a converter for connecting to other MIDI devices that use a different mapping of MIDI signals to the stereo minijacks.

Early 1010music music products use the Type B mapping of MIDI signals to stereo minijacks. Bitbox mk2 and bitbox micro can use mini TRS Type A or Type B for MIDI inputs. Bitbox micro uses Type B for MIDI outputs.

The diagram to the right shows the numbering of the pins on a MIDI connector and the labels of the connection components of a stereo minijack. Type B products are compatible with cables that use the following mapping of MIDI signals between female MIDI connectors and stereo minijacks.

Notes: Part of 1010's excellent Nanobox series, the Tangerine is a tiny powerhouse sampler. A fresh new approach to sampling, from one-shots to loops, all the way through to four-hour recordings.

Supplier's Notes:
Sweet and Tangy Sampling

The nanobox | tangerine delivers powerful sampling in an ultra portable form factor. With this nanobox, you can add recording, sample playback, clip launching, slicing, and musically intelligent looping capabilities to your desktop or travel rig. With an intuitive touch screen interface, nanobox | tangerine makes easy work of selecting, editing, and tweaking your samples. You can stream large samples of up to 4 GB file size straight from the microSD card. Interact with other musical components via MIDI. Load multi-sample banks with over 500 samples for amazing instrument reproduction. Tweak your configurations to get them just right, then save them to multiple presets for future reuse.

Top features

Play up to 24 stereo polyphonic notes when your samples fit in the 64 MB of internal memory or up to 8 larger stereo samples streaming directly from the microSD card

Play multi-sample banks with up to 16 velocity layers and 576 WAV files loaded in one preset

Configure 8 stereo sample pads per preset as single or multi-samples, clips, slicers, or new recordings

Stream long samples from the microSD card with a max sample size of 4 GB, which can be many hours of audio

Trigger samples with the touch screen or MIDI input as one shots or melodic notes

Control how samples start and stop by choosing from one-shot, toggle, gate and piano (New!) launch modes

Tweak playback through a variety of sample parameters, including start position, length, pitch, gain, filter, loop mode, launch quantization, ADSR, Exclusive Grouping, clip synchronization, slice placement and sequencing, and MIDI note and channel mapping

Quickly and easily use MIDI mapped controls for more tactile access to common parameters

Record up to 16 sequence layers per preset.

Get into the groove with a fast, fluid, and intuitive workflow

Make music anywhere thanks to a compact and nearly indestructible design

Recording Capabilities

Configure each pad for stereo or mono recording with the option to synchronize the start and stop times to clock inputs
Trigger recording via audio level threshold
Create perfectly sized loops by setting the recording length
Enable immediate playback after recording for live looping capabilities
Make recordings up to 4 hours in length
Resample the master output without patching
Automate recording of a multi-sample bank via MIDI
Store recorded samples as WAV files on the micro SD card then remove the card to transfer them to your computer

What is Included:
nanobox | tangerine - Compact Streaming Sampler
MicroSD card with 85 presets and over 1500 wav files
Colour matched USB power cord
Type B TRS MIDI To MIDI 5 Pin DIN adapter
Quick Start Guide

Technical Specs:

Power: USB-C connection 5V, 500mA
3.5mm audio input and output
Maximum input and output level: 2Vrms
DAC and ADC resolution: 24-bit
Internal resolution: 32-bit
Sample rate: 48kHz
MIDI Input: 3.5mm Type A/B auto sensing
MIDI Output: 3.5mm Type B
Clock Input: 1,2, 4, 8, 12 or 24 PPQ selectable
MIDI support: Note On/Off, Velocity, Pressure, Mod Wheel, Aftertouch, CC mappings to common parameters, program changes and clock
H x W x D: 1.5" x 3.75" x 3"
Weight: 0.25 lbs.
2" touch screen, 2 knobs and 4 buttons in a 3.75" x 3" x 1.5" package

Additional information

Weight: 0.65 lbs
Dimensions: 7.75 × 4.85 × 2.25 in

Notes: Just when you thought 2HP couldn't go any smaller, the Zero HP Mult has now arrived! The ZHM a 1 to 5 cable splitter, providing utility outside your case for increased patchabilty. Whether it is sending out a master clock, modulation, or simply lengthening a cable to reach the far ends of your rack, the Zero HP Mult is ready for duty!

Notes: 10-conductor ribbon cable with three 10-pin connectors and a 16-pin connector on one end (20" total length), for connecting more than 2 modules in a Pod.

Notes: 16-conductor ribbon cable with four 16-pin connectors (20" total length), for connecting more than 2 modules in a Pod.

Notes: 4ms blank panel - 1HP width. Black coloured PCB material with 4ms logo.

Notes: 4ms blank panel - 2HP width. Black coloured PCB material with 4ms logo.

Notes: Jumper cable for connecting two Listen 4, Listen 4Q, or Listen IO modules & for daisy-chaining multiple Listens to create a larger mixer. Also used for connecting a WAV Recorder to a Listen module in order to record directly from the Listen's main mix. See the Listen module manuals for details and examples.

One cable connects two modules. By adding more cables you can create a chain between multiple modules.

Specifications:

1x3 pin female header
Pin Spacing: 0.1" (2.54mm)
Total length: 4.38" (111mm)

Notes: Power brick for powering Pods. One power brick can power up to 10 typical Pods. Pods can be daisy-chained using a Barrel Cable or Long Barrel Cable.

15V/3A (45W) / 2.1mm Barrel Plug (5.5mm outer diameter) / Positive Centre.

You also may use your own power brick if it meets the following requirements:

- 15V to 20V DC
- Positive centre 2.1mm barrel plug
- Minimum 20W output power
- Low-noise output
- Compatible with an IEC C5 cable

Please note: IEC cable not supplied

Notes: 4ms blank panel - 8HP width. Black coloured PCB material with 4ms logo.

Notes: Power brick for powering Pods. One power brick can power up to 10 typical Pods. Pods can be daisy-chained using a Barrel Cable or Long Barrel Cable.

15-20V / 90W / 2.1mm Barrel Plug (5.5mm outer diameter) / Positive Centre.

Compatible power bricks are available wherever ROW POWER modules are sold. You also may use your own power brick if it meets the following requirements:

- 15V to 20V DC
- Positive centre 2.1mm barrel plug
- Minimum 30W output power
- Low-noise output
- Compatible with an IEC C5 cable

Please note: IEC cable not supplied

Notes: Bus Sticks are low-profile, small footprint power distribution boards for powering up to 13 modules using shrouded (keyed) headers. Simply connect to a Row Power module using the included cable. Attaches to your case using adhesive pads (included) or by drilling and screwing.

Notes: Low-cost, portable, compact enclosure that turns Eurorack modules into table-top instruments.

The Pod20 is 20HP with 1.34" (34mm) of available module depth. The built-in power supply has two power connectors and can be daisy-chained to other Pods. More power connectors can be added with the Multi Power Cable accessory.

Pods require a power brick. If you already have a powered Pod and power brick (or a Row Power module) you can use a barrel cable to daisy-chain powered Pods.

The Pod20 includes ten (10) M3x8mm stainless steel screws and is compatible with M3 Knurlies.

Notes: Low-cost, portable, compact enclosure that turns Eurorack modules into table-top instruments.

The Pod26 is 26HP with 1.34" (34mm) of available module depth. The built-in power supply has two power connectors and can be daisy-chained to other Pods. More power connectors can be added with the Multi Power Cable accessory.

Pods require a power brick. If you already have a powered Pod and power brick (or a Row Power module) you can use a barrel cable to daisy-chain powered Pods.

The Pod26 includes ten (10) M3x8mm stainless steel screws and is compatible with M3 Knurlies.

Notes: Low-cost, portable, compact enclosure that turns Eurorack modules into table-top instruments.

The Pod32 is 32HP with 1.34" (34mm) of available module depth. The built-in power supply has two power connectors and can be daisy-chained to other Pods. More power connectors can be added with the Multi Power Cable accessory.

Pods require a power brick. If you already have a powered Pod and power brick (or a Row Power module) you can use a barrel cable to daisy-chain powered Pods.

The Pod32 includes ten (10) M3x8mm stainless steel screws and is compatible with M3 Knurlies.

Notes: Low-cost, portable, compact enclosure that turns Eurorack modules into table-top instruments.

The Pod34X is 34HP wide and has extra room to fit even the deepest modules (2.16" / 55mm of available module depth). The built-in power supply has four power connectors and can be daisy-chained to other Pods. More power connectors can be added with the Multi Power Cable accessory.

This Pod requires a power brick (not included).

Or, if you already have a Pod and power brick (or a Row Power module) you can use a barrel cable to daisy-chain power supplies.

Pods are a perfect way to get started in Eurorack, or add a couple more modules to your monster system!

Made from 100% anodized aluminum, Pods are light, tough and perfect for on-the-go set ups. The power supply can handle up to 1.4A of +12V, which is plenty of juice for even the most modern digital modules. (Or if you prefer to DIY your power supply, Pods are also available unpowered)

Each Pod typically will house one or two modules, but three or more can be accommodated using a multi-power cable accessory.

Mix and match your Pods with desktop synths, effect pedals, drum machines or any musical gear for a flexible modular system. Pods can even daisy- chain with the 4ms Row Power system making them a convenient outboard mini-skiff. Need to add another module? Just add a Pod! Need to pack light for a live set? Just grab the Pods you need and go!

Basic Features:

34 HP Eurorack modular space
Standard M3 threaded holes
100% lightweight anodized aluminum
Built-in Power supply
Red, White, and Blue LED power indicators

Includes:
34HP Pod, black anodized aluminum
Extra deep (2.16"/55mm) fits virtually every Eurorack module
Built-in power supply with four Eurorack power headers
M3 x 8mm pan-head screws, stainless steel (10)
Adhesive rubber feet (4)
Does not include barrel cable or power brick
Power Supply:
Four 16-pin Eurorack power shrouded headers
+12V max 1.4A
-12V max 0.65A
+5V max 1.0A
Power input: Two barrel jacks for daisy-chaining
15V-20VDC, 2.1mm positive tip
Exterior dimensions:
Width: 177.3mm (6.98")
Height: 159.5mm (6.28")
Depth: 57mm (2.24")
Interior dimensions:
Max module depth: 55mm (2.16")
Module width: 34HP
Weight:
0.3 kg = 10 oz

Notes: The Pod40X is 40HP with 2.00" (51mm) of available module depth. The built-in power supply has four power connectors and can be daisy-chained to other Pods. More power connectors can be added with the Multi Power Cable accessory.

Pods require a power brick. If you already have a powered Pod and power brick (or a Row Power module) you can use a barrel cable to daisy-chain powered Pods.

The Pod40 includes ten (10) M3x8mm stainless steel screws and is compatible with M3 Knurlies.

Notes: Low-cost, portable, compact enclosure that turns Eurorack modules into table-top instruments.

The Pod60 is 60HP with 1.34" (34mm) of available module depth. The built-in power supply has four power connectors and can be daisy-chained to other Pods. More power connectors can be added with the Multi Power Cable accessory.

Pods require a power brick. If you already have a powered Pod and power brick (or a Row Power module) you can use a barrel cable to daisy-chain powered Pods.

The Pod60 includes twenty (20) M3x8mm stainless steel screws and is compatible with M3 Knurlies.

Notes: Low-cost, portable, compact enclosure that turns Eurorack modules into table-top instruments.

The Pod60 Unpowered is 60HP with 1.34" (34mm) of available module depth. No power supply is included, you must supply your means of powering modules with a DIY power supply or a front-facing module such as the Row Power. Two holes on the rear face are plugged with removable plastic plugs, and can be used for DIY applications.

Notes: Low-cost, portable, compact enclosure that turns Eurorack modules into table-top instruments.

The Pod64X is 64HP with 2.16" (55mm) of available module depth. The built-in power supply has four power connectors and can be daisy-chained to other Pods. More power connectors can be added with the Multi Power Cable accessory.

Pods require a power brick, or a barrel cable to daisy-chain to a Pod or Row Power that's already powered.

Pods are a perfect way to get started in Eurorack, or add a couple more modules to your monster system!

Made from 100% anodized aluminum, Pods are light, tough and perfect for on-the-go set ups. The power supply can handle up to 1.4A of +12V, which is plenty of juice for even the most modern digital modules. (Or if you prefer to DIY your power supply, Pods are also available unpowered)

Each Pod64X typically will house up to six modules, but more can be accommodated using a multi-power cable accessory.

Mix and match your Pods with desktop synths, effect pedals, drum machines or any musical gear for a flexible modular system. Pods can even daisy- chain with the 4ms Row Power system making them a convenient outboard mini-skiff. Need to add another module? Just add a Pod! Need to pack light for a live set? Just grab the Pods you need and go!

Basic Features:

64 HP of Eurorack modular space
Extra room for deep modules
Standard M3 threaded holes
100% lightweight anodized aluminum
Built-in Power supply
Red, White, and Blue LED power indicators

Includes:

64HP Pod, black anodized aluminum
Built-in power supply with six Eurorack power headers
Extra deep (2.16"/55mm) fits virtually every Eurorack module
M3 x 8mm pan-head screws, stainless steel (20)
Adhesive rubber feet (4)
Does not include barrel cable or power brick
Power Supply:

Four 16-pin Eurorack power shrouded headers
+12V max 1.4A
-12V max 0.67A
+5V max 1.0A
Power input: Two barrel jacks for daisy-chaining
15V-20VDC, 2.1mm positive tip
Exterior dimensions:
Width: 329.7mm (12.98")
Height: 159.5mm (6.28")
Depth: 57mm (2.24")
Interior dimensions:
Max module depth: 55mm (2.16")
Module width: 64HP
Weight:
0.5 kg = 17 oz

Notes: Low-cost, portable, compact enclosure that turns Eurorack modules into table-top instruments.

The Pod64X Unpowered is 64HP with 2.16" (55mm) of available module depth. No power supply is included, you must supply your means of powering modules with a DIY power supply or a front-facing module such as the Row Power. Two holes on the rear face are plugged with removable plastic plugs, and can be used for DIY applications.

Pods are a perfect way to get started in Eurorack, or add a couple more modules to your monster system!

Made from 100% anodized aluminum, Pods are light, tough and perfect for on-the-go set ups. Mix and match your Pods with desktop synths, effect pedals, drum machines or any musical gear for a flexible modular system. Need to add another module? Just add a Pod! Need to pack light for a live set? Just grab the Pods you need and go!

Basic Features:

64 HP Eurorack modular space
Standard M3 threaded holes
100% lightweight anodized aluminum

Includes:

64HP Pod, black anodized aluminum
M3 x 8mm pan-head screws, stainless steel (20)
Adhesive rubber feet (4)
Unpowered: requires you to provide your own Eurorack power system
Exterior dimensions:
Width: 329.7mm (12.98")
Height: 159.5mm (6.28")
Depth: 57mm (2.24")
Interior dimensions:
Max module depth: 55mm (2.16")
Module width: 64HP
Weight:
0.42 kg = 14.9 oz

Notes: Right angle 2.1mm barrel plug (5.5mm outer diameter, positive tip). Short barrel to barrel cable for daisy-chaining Row Powers and/or Pods. Cable is 11" long (centre of tip to centre of tip), suitable for two Pods next to each other or in front/behind each other. Also compatible with Row Power modules.

Both ends of the cable have a right-angle plug.

Notes: Medium sized spring reverb tank, Type 8 Accutronics 8BB2C1B with 3×1 springs and medium decay (1.75 - 3 seconds).

Input impedance 190 Ohm, output impedance 2575 Ohm. Input connector insulated, output connector grounded.

Notes: Type 1 - Blue Reverb

Features:
Compact and low cost type
2 natural coil spring type
Input impedance are changeable
Length of connect wire are changeable by optional

Application:
Specially suited for small wattage amplifier
For electric organs, guitar amplifier
Ideally suited for practice amps
2 Springs Type

Notes: Introducing ADDAC's Cable Tester, a desktop utility that provides a reliable means to test the integrity of both mono jacks and ribbon cables, ensuring that every connection is secure and electrically sound.

Individual Wire Testing - Featuring the ability to test each wire within the ribbon cables independently with dedicated LEDs for every wire, providing a clear visual indication of the status of each connection, wires are also tested against their neighbouring wires to detect shorts.

Busboard monitor

The busboard monitor LEDs allows the user to check the state of the busboard power lines as well as the special CV/Gate functions. If the busboard has no +5v supply the led will be off likewise for the CV/Gate functions if not in use.

This is a desktop device, ADDAC provide a long power cable so that it can still be plugged into your rack.

As a safety precaution only power this board when you need to test a cable. Leaving it ON at all times can lead to unintended problematic misuses which, in a worst case scenario, can shorten your Eurorack PSU,

! WARNING !
DO NOT POWER MODULES FROM THE TEST SOCKETS!!

Compatible with all ADDAC System ribbon cables (power, expansions and interconnectivity: 112, 213, 807).

Also compatible with any standard Eurorack power ribbon cable (2x5 to 2x8 or 2x8 to 2x8).

! WARNING !
NOT ALL MANUFACTURERS FOLLOW THESE STANDARDS!
ALLWAYS NOTICE THE ORIENTATION OF THE HEADERS IF YOUR CABLE DO NOT FOLLOW THE STANDARD THEN MOST PROBABLY IS NOT COMPATIBLE.

Tech Specs:
30mA +12V
30mA -12V

Notes: 104hp wide with two 3U rows and a 1U row.
Powder coated aluminum construction
VESA mount compatible (100mm x 100mm)
Plastic handle for easy mobility
Metal feet can be installed to support multiple angles of jamming.
Secure latching lid with enough depth to keep your patches patched

Expandable

Lid - when you're ready to add more space, the lid can be expanded to be another 104hp x 7U. You can add another set of rails, power supply and power jack and double your available space. (Kit available)
Metal feet - The metal feet can have a pair of rails and rack mounted power added to support another 3U row of 104hp. (Kit available in future)

Connectivity

Audio jacks - set of four jacks for stereo in and stereo out.
MIDI jacks - DIN jacks to support IN, OUT, and THRU MIDI.
USB power - can be used for a lamp to light your case or to charge your phone while recording your set.

Dimensions
557mm x 334mm x 169mm
74mm depth for 1U and bottom 3U row
52mm depth for middle 3U row

Power
+12V - 3A (with plenty of allowance for in-rush current)
-12V - 3A
+5V - 3A (shared with USB power)
36 shrouded power headers

In The Box
Main case
Lid
Metal feet
Power adapter 20V at 6A

Notes: Save space in your rack with stackable cables.

These are the newer shorter stackable Eurorack Patch Cables. Patching is more stable and makes it easier to get a lid on that performance case.

Each end of the cable has a male and female jack. They come in sets of 5 cables.

Available in 6in (15cm), 12in (30cm), 18in (45cm), 24in (60cm).

Notes: After Later Audio Braided Patch Cables for Eurorack in Gold and Black. One size per pack of five cables. Packs come in 15, 30, 45, and 60 centimeters, or 6, 12, 18, and 24 inches.

Notes: These are 6" (15cm) right angle patch cables for Eurorack. Colour is pink, pack of 5 cables.

Notes: Save space in your rack with stackable cables.

These are the newer shorter stackable Eurorack Patch Cables. Patching is more stable and makes it easier to get a lid on that performance case.

One end of the cable has a male and female jack, the other end as just a male connector. They come in sets of 5 cables.

Available in 6in (15cm), 12in (30cm), 18in (45cm), and 24in (60cm).

Notes: These are skinny (sometimes called noodle) patch cables for Eurorack. This is a pack of five cables, size 6", pink in colour.

Notes: Save space in your rack with stackable cables.

These are the newer shorter stackable Eurorack Patch Cables. Patching is more stable and makes it easier to get a lid on that performance case.

Each end of the cable has a male and female jack. They come in sets of 5 cables.

Available in 6in (15cm), 12in (30cm), 18in (45cm), 24in (60cm).

Notes: After Later Audio Braided Patch Cables for Eurorack in Gold and Black. One size per pack of five cables. Packs come in 15, 30, 45, and 60 centimeters, or 6, 12, 18, and 24 inches.

Notes: These are right angle patch cables for Eurorack. Size is 12 inch (30cm), colour is green.

Notes: Save space in your rack with stackable cables.

These are the newer shorter stackable Eurorack Patch Cables. Patching is more stable and makes it easier to get a lid on that performance case.

One end of the cable has a male and female jack, the other end as just a male connector. They come in sets of 5 cables.

Available in 6in (15cm), 12in (30cm), 18in (45cm), and 24in (60cm).

Notes: This is a pack of five, 12" skinny patch cable for Eurorack. Colour is green.

Notes: Save space in your rack with stackable cables.

These are the newer shorter stackable Eurorack Patch Cables. Patching is more stable and makes it easier to get a lid on that performance case.

Each end of the cable has a male and female jack. They come in sets of 5 cables.

Available in 6in (15cm), 12in (30cm), 18in (45cm), 24in (60cm).

Notes: After Later Audio Braided Patch Cables for Eurorack in Gold and Black. One size per pack of five cables. Packs come in 15, 30, 45, and 60 centimeters, or 6, 12, 18, and 24 inches.

Notes: Save space in your rack with stackable cables.

These are the newer shorter stackable Eurorack Patch Cables. Patching is more stable and makes it easier to get a lid on that performance case.

One end of the cable has a male and female jack, the other end as just a male connector. They come in sets of 5 cables.

Available in 6in (15cm), 12in (30cm), 18in (45cm), and 24in (60cm).

Notes: Save space in your rack with stackable cables.

These are the newer shorter stackable Eurorack Patch Cables. Patching is more stable and makes it easier to get a lid on that performance case.

Each end of the cable has a male and female jack. They come in sets of 5 cables.

Available in 6in (15cm), 12in (30cm), 18in (45cm), 24in (60cm).
